Remote Keyless Entry Systems: Other Dodge Ram Van B2500

PROGRAMMING

Note. Following procedures require a functional transmitter. If a functional transmitter is not available, program RKE receiver using scan tool. See appropriate BODY CONTROL COMPUTER TESTS article.

Note. For more information, see TSB REMOTE KEYLESS ENTRY (RKE) PROGRAMMING PROCEDURES .

CENTRAL TIMER MODULE PROGRAMMING

Note. This procedure applies to models with anti-theft system.

This procedure requires the use of a scan tool. Using scan tool, select CENTRAL TIMER MODULE. If scan tool displays NO RESPONSE or CCD BUS FAILURE, go to appropriate VEHICLE COMMUNICATIONS article. If scan tool does not display NO RESPONSE or CCD BUS FAILURE, use scan tool to select MISCELLANEOUS, then PROGRAM RKE. Follow scan tool prompts to program transmitter.

POWER LOCK/REMOTE KEYLESS ENTRY MODULE

Note. This procedure applies to models without anti-theft system.

1. Locate Dark Green program enable wire, connected to Data Link Connector (DLC) terminal No. 1. DLC is located under left side of instrument panel, to left of steering column. End of enable wire has a Black rubber cap.
2. Connect program enable wire to ground. Turn ignition on. Power door locks will cycle. Depress either button on transmitter. Doors locks will cycle to confirm signal was received. Depress either button on second transmitter if needed. Doors locks will again cycle to confirm signal was received.
3. Disconnect enable from ground. Secure wire to harness. Turn ignition off. Verify transmitter(s) operation.

HORN CHIRP ENABLE/DISABLE PROGRAMMING

Turn ignition on, with engine off. Press and hold UNLOCK button for at least 4 seconds. While holding UNLOCK button, press LOCK button, then release both buttons. Horn will chirp once when programming is completed.

POWER LOCKS DO NOT WORK WITH RKE OR LOCK SWITCHES

Check fuses.

POWER LOCKS DO NOT WORK WITH RKE, BUT WORK WITH LOCK SWITCHES

Check RKE transmitter batteries. Program RKE transmitter. See PROGRAMMING .

POWER LOCKS WORK WITH RKE, BUT DO NOT WORK WITH LOCK SWITCHES

Check power lock switches. See appropriate POWER DOOR LOCKS & LIFTGATE RELEASE article.

ONE POWER LOCK DOES NOT WORK WITH RKE TRANSMITTER OR LOCK SWITCHES

Check power lock motor. See appropriate POWER DOOR LOCKS & LIFTGATE RELEASE article.

ANTI-THEFT FEATURES DO NOT WORK

If horn chirp does not work, check horn relay. See HORN RELAY under COMPONENT TESTS. If relay is okay or any other feature does not work, check CTM. See CENTRAL TIMER MODULE (CTM) under SYSTEM TESTS.

COMPONENT TESTS

Note. For power door lock component tests, see appropriate POWER DOOR LOCKS & LIFTGATE RELEASE article.

TRANSMITTER

Replace transmitter batteries. Reprogram suspect transmitter and a known-good transmitter. See appropriate procedure under PROGRAMMING . Test system with both transmitters. If both transmitters do not operate system, diagnose system using scan tool. See appropriate BODY CONTROL COMPUTER TESTS article. If known-good transmitter operates system but suspect transmitter does not, replace faulty transmitter. Repeat transmitter programming.

Scheme 29

1. Remove horn relay from junction block. Using an ohmmeter, check for continuity between relay terminals No. 87A and 30. (Scheme 29) If continuity does not exist, replace relay. If continuity exists, go to next step.
2. Check for continuity between relay terminals No. 30 and 87. If continuity exists, replace relay. If continuity does not exist, check resistance between relay terminals No. 85 and 86. If resistance is not 70-80 ohms, replace relay. If resistance is 70-80 ohms, go to next step.
3. Using jumper wires, connect battery voltage to relay terminal No. 86 and ground to relay terminal No. 85. Continuity should exist between terminals No. 30 and 87. Continuity should not exist between relay terminals No. 87A and 30. If continuity is not as specified, replace relay. If continuity is as specified, relay is okay.

SYSTEM TESTS

Note. For wire color and circuit identification, see WIRING DIAGRAMS .

CENTRAL TIMER MODULE (CTM)

Note. This test applies to vehicles with anti-theft system. The following procedure may be inconclusive. Using the Chrysler Diagnostic Readout Box (DRB) scan tool or generic scan tool to check all circuits connected to the Central Timer Module (CTM) is recommended. See appropriate BODY CONTROL COMPUTER TESTS article.

Scheme 30

Scheme 31

1. If horn chirp feature is not only problem being diagnosed, go to next step. If horn chirp feature is only problem being diagnosed, check horn enable/disable feature. See «HORN CHIRP ENABLE/DISABLE PROGRAMMING»(ref-139368-S28485532602002043000000) under PROGRAMMING. If horn enable/disable feature is enabled, check horn relay. See «HORN RELAY»(ref-139368-S33805048452002043000000) under COMPONENT TESTS. If relay checks okay, or problem is speed triggered locking, door lock inhibit or accident response feature, scan tool diagnosis is recommended. See appropriate BODY CONTROL COMPUTER TESTS article.
2. Check fuse No. 4 (20-amp) in junction block. If fuse is okay, go to next step. If fuse is blown, repair shorted circuit and replace fuse.
3. Check for voltage at fuse No. 4 (20-amp) in junction block. If voltage exists, go to next step. If voltage does not exist, repair open circuit Between Power Distribution Center (PDC) and junction block.
4. Check fuse No. 17 (10-amp) in junction block. If fuse is okay, go to next step. If fuse is blown, repair shorted circuit and replace fuse.
5. Turn ignition on. Check for voltage at fuse No. 17 (10-amp) in junction block. If voltage exists, turn ignition off and go to next step. If voltage does not exist, repair open circuit between junction block and ignition switch.
6. Disconnect negative battery cable. Locate and disconnect CTM connectors. See «CENTRAL TIMER MODULE (CTM)»(ref-139368-S02591072982002043000000) under REMOVAL & INSTALLATION. Check harness connectors and CTM receptacles for loose, damaged or corroded terminals and pins. If terminals and pins are not okay, repair as necessary. If terminals and pins are okay, go to next step.
7. Check continuity between CTM connector C1 terminal No. 6 and ground. Check continuity between CTM connector C2 terminal No. 3 and ground. (Scheme 30)and (Scheme 31). If continuity exists, go to next step. If continuity does not exist, repair open circuit(s) as necessary.
8. Reconnect negative battery cable. Check for battery voltage at CTM connector C1 terminal No. 14. If voltage exists, go to next step. If voltage does not exist, repair open circuit to junction block.
9. Check for battery voltage at CTM connector C2 terminal No. 4 while pressing each door lock switch to LOCK position. If battery voltage exists, go to next step. If voltage does not exist, repair open circuit(s) between lock switch(es) and CTM.
10. Check for battery voltage at CTM connector C2 terminal No. 13 while pressing each door lock switch to UNLOCK position. If battery voltage exists, go to next step. If voltage does not exist, repair open circuit(s) between lock switch(es) and CTM.
11. Disconnect negative battery cable. Reconnect CTM connectors. Reconnect negative battery cable. Check for battery voltage by backprobing CTM connector C2 terminal No. 1 while pressing each door lock switch to LOCK position. Repeat test, pressing RKE transmitter LOCK button. If battery voltage exists using both procedures, go to next step. If voltage does not exist using lock switch, check power lock switch. See appropriate POWER DOOR LOCKS & LIFTGATE RELEASE article. If voltage does not exist using RKE transmitter, check RKE transmitter. See «TRANSMITTER»(ref-139368-S40464500042002043000000) under COMPONENT TESTS. If voltage does not exist using both RKE and lock switch, replace CTM. See «CENTRAL TIMER MODULE (CTM)»(ref-139368-S02591072982002043000000) under REMOVAL & INSTALLATION. Go to next step.
12. Open side or rear door. Press lock switch to LOCK or press LOCK button on RKE transmitter. Check for battery voltage by backprobing CTM connector C2 terminal No. 1. Close all doors. If battery voltage exists within 5 seconds after closing last door, circuit is okay. Go to next step. If voltage does not exist as described, replace CTM. See «CENTRAL TIMER MODULE (CTM)»(ref-139368-S02591072982002043000000) under REMOVAL & INSTALLATION.
13. Check for battery voltage by backprobing CTM connector C2 terminal No. 9 while pressing lock switch to UNLOCK position. Repeat test, pressing UNLOCK button on RKE transmitter. If battery voltage exists using both procedures, check power lock motor. See appropriate POWER DOOR LOCKS & LIFTGATE RELEASE article. If voltage does not exist using RKE transmitter, check RKE transmitter. See «TRANSMITTER»(ref-139368-S40464500042002043000000) under COMPONENT TESTS. If voltage does not exist using unlock switch, check power lock switch. See appropriate POWER DOOR LOCKS & LIFTGATE RELEASE article. If voltage does not exist using both RKE transmitter and lock switch, replace CTM. See «CENTRAL TIMER MODULE (CTM)»(ref-139368-S02591072982002043000000) under REMOVAL & INSTALLATION.

POWER LOCK/REMOTE KEYLESS ENTRY (RKE) MODULE

Note. This test applies to vehicles without anti-theft system.

Scheme 32

1. Check fuse No. 4 (20-amp) in junction block. If fuse is okay, go to next step. If fuse is blown, repair shorted circuit and replace fuse.
2. Check for battery voltage at fuse No. 4 (20-amp) in junction block. If battery voltage exists, go to next step. If battery voltage does not exist, repair open circuit between Power Distribution Center (PDC) and junction block.
3. Check fuse No. 17 (10-amp) in junction block. If fuse is okay, go to next step. If fuse is blown, repair shorted circuit and replace fuse.
4. Turn ignition on. Check for battery voltage at fuse No. 17 (10-amp) in junction block. If battery voltage exists, turn ignition off and go to next step. If battery voltage does not exist, repair open circuit between ignition switch and junction block.
5. Disconnect negative battery cable. Locate and disconnect power lock/RKE module connectors. See «POWER LOCK/REMOTE KEYLESS ENTRY (RKE) MODULE»(ref-139368-S06102810182002043000000) under REMOVAL & INSTALLATION. Go to next step.
6. Inspect power lock/RKE module connectors and receptacles. If terminals are loose, corroded or damaged, repair as necessary. If terminals are okay, go to next step.
7. Check continuity between ground and Black power lock/RKE module connector C2 terminal "H". (Scheme 32) If continuity exists, go to next step. If continuity does not exist, repair open circuit as necessary.
8. Connect negative battery cable. Check for battery voltage at Black power lock/RKE module connector C2 terminal "A". If battery voltage exists, go to next step. If battery voltage does not exist, repair open circuit between power lock/RKE module connector.
9. Check for battery voltage at Black power lock/RKE module connector C2 terminal "C" while pressing each door lock switch to LOCK. If battery voltage exists, go to next step. If battery voltage does not exist, repair open circuit between module and lock switch(es).
10. Check for battery voltage at Black power lock/RKE module connector C2 terminal "B" while pressing each door lock switch to UNLOCK. If battery voltage exists, go to next step. If battery voltage does not exist, repair open circuit between module and lock switch(es).
11. Check continuity between ground and Black power lock/RKE module connector C2 terminal "E" with side and rear door closed. Continuity should not exist. Open each door, one at a time. As each door is opened, continuity should exist. If continuity is as specified, go to next step. If continuity is not as specified, repair circuit(s) or replace switch(es) as needed.
12. Turn ignition on. Check for battery voltage at Blue power lock/RKE module connector C1 terminal "G". If battery voltage exists, turn ignition off and go to next step. If battery voltage does not exist, repair open circuit between power lock/RKE module and junction block.
13. Reconnect power lock/RKE module connectors. Backprobe Black power lock/RKE module connector C2 terminal "F". Check continuity between ground and Black power lock/RKE module connector C2 terminal "F". Continuity should not exist. Press UNLOCK button on RKE transmitter. Continuity should exist for about 30 seconds. If continuity is as specified, go to next step. If continuity is not as specified, replace power door lock and RKE module. See «POWER LOCK/REMOTE KEYLESS ENTRY (RKE) MODULE»(ref-139368-S06102810182002043000000) under REMOVAL & INSTALLATION.
14. Check for battery voltage at Black power lock/RKE module connector C2 terminal "F" while pressing lock switch to LOCK position. Repeat test, pressing LOCK button on RKE transmitter. If battery voltage exists using both procedures, go to next step. If voltage does not exist using RKE transmitter, check RKE transmitter. See «TRANSMITTER»(ref-139368-S40464500042002043000000) under COMPONENT TESTS. If voltage does not exist using lock switch, check power lock switch. See appropriate POWER DOOR LOCKS & LIFTGATE RELEASE article. If voltage does not exist using both RKE transmitter and lock switch, replace power lock switch and RKE module. See «POWER LOCK/REMOTE KEYLESS ENTRY (RKE) MODULE»(ref-139368-S06102810182002043000000) under REMOVAL & INSTALLATION.
15. Open side or rear door. Press lock switch to LOCK position or press LOCK button on RKE transmitter. Check for battery voltage by backprobing Black power lock/RKE module connector C2 terminal "F". Close all doors. If battery voltage exists within 5 seconds after closing last doors go to next step. If voltage does not exist as described, replace power lock switch and RKE module. See «POWER LOCK/REMOTE KEYLESS ENTRY (RKE) MODULE»(ref-139368-S06102810182002043000000) under REMOVAL & INSTALLATION.
16. Check for battery voltage by backprobing Black power lock/RKE module connector C2 terminal "G" while pressing lock switch to UNLOCK position. Repeat test, pressing UNLOCK button on RKE transmitter. If battery voltage exists using both procedures, check power lock motor. See appropriate POWER DOOR LOCKS & LIFTGATE RELEASE article. If voltage does not exist using RKE transmitter, check RKE transmitter. See «TRANSMITTER»(ref-139368-S40464500042002043000000) under COMPONENT TESTS. If voltage does not exist using unlock switch, check power lock switch. See appropriate POWER DOOR LOCKS & LIFTGATE RELEASE article. If voltage does not exist using both RKE and lock switch, replace power lock switch and RKE module. See «POWER LOCK/REMOTE KEYLESS ENTRY (RKE) MODULE»(ref-139368-S06102810182002043000000) under REMOVAL & INSTALLATION.
