Transfer Case - NV243: Specifications Dodge Pickup R1500

Transfer Case 13 illustrations

TORQUE SPECIFICATIONS

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Plug, Detent16-2412-18
Plug, Drain/Fill40-4530-40
Bolt, Extension Housing16-2412-18
Bolt, Case Half20-2715-24
Screw, Oil Pump12-168-12
Nuts, Mounting30-4120-30
Bolts, Shift Motor and Mode Sensor Assembly16-2412-18

TRANSFER CASE (NV243) TORQUE SPECIFICATIONS

Scheme 220

Scheme 220: TRANSFER CASE - NV241/NV243
