LEFT SIDE Dodge Pickup R1500

4.7L V8 Engine 2 illustrations ~290 words

LEFT SIDE

  1. Disconnect negative cable from battery.
  2. Remove the resonator assemble and air inlet hose.
  3. Disconnect injector connectors and un-clip the injector harness.
  4. Route injector harness in front of cylinder head cover.
  5. Disconnect the left side breather tube and remove the breather tube.
  6. Remove the cylinder head cover mounting bolts.
  7. Remove cylinder head cover and gasket. NOTE: The gasket may be used again, provided no cuts, tears, or deformation has occurred.

Clean cylinder head cover gasket surface.

Clean head rail, if necessary.

CAUTIONDo not use harsh cleaners to clean the cylinder head covers. Severe damage to covers may occur
CAUTIONDO NOT allow other components including the wire harness to rest on or against the engine cylinder head cover. Prolonged contact with other objects may wear a hole in the cylinder head cover

Scheme 403

Scheme 403
Scheme 403
  1. Clean cylinder head cover and both sealing surfaces. Inspect and replace gasket as necessary.
  2. Install cylinder head cover and hand start all fasteners. Verify that all double ended studs are in the correct location shown in (Scheme 403)
  3. Tighten cylinder head cover bolts and double ended studs to 12 N.m (105 in. lbs).
  4. Install right rear breather tube and filter assembly.
  5. Connect injector, ignition coil electrical connectors and harness retaining clips.
  6. Install the oil fill tube.
  7. Install PCV hose.
  8. Install heater hoses.
  9. Install air conditioning compressor retaining bolts.
  10. Install accessory drive belt (Refer to «DRIVE BELTS -- 3.7L / 4.7L»(ref-189655-S16761653102005091200000) ).
  11. Fill Cooling system (Refer to «COOLING»(ref-189654) ).
  12. Install air cleaner assembly, resonator assembly and air inlet hose.
  13. Connect battery negative cable.
CAUTIONDo not use harsh cleaners to clean the cylinder head covers. Severe damage to covers may occur
CAUTIONDO NOT allow other components including the wire harness to rest on or against the cylinder head cover. Prolonged contact with other objects may wear a hole in the engine cylinder head cover

Scheme 404

Scheme 404
Scheme 404
  1. Clean cylinder head cover and both sealing surfaces. Inspect and replace gasket as necessary.
  2. Install cylinder head cover and hand start all fasteners. Verify that all studs are in the correct location shown in (Scheme 404)
  3. Tighten cylinder head cover bolts and double ended studs to 12 N.m (105 in. lbs.).
  4. Install left side breather and connect breather tube.
  5. Connect injector electrical connectors and injector harness retaining clips.
  6. Install the resonator and air inlet hose.
  7. Connect negative cable to battery.
