Filter Element Only Dodge Pickup R1500

4.7L V8 Engine 1 illustration

Filter Element Only

Housing removal is not necessary for element (filter) replacement.

Scheme 386

Scheme 386: Filter Element Only
Scheme 386: Filter Element Only
  1. Loosen clamp (Scheme 386) and disconnect air duct at air cleaner cover.
  2. Pry over 4 spring clips (Scheme 386) from housing cover (spring clips retain cover to housing).
  3. Release housing cover from locating tabs on housing (Scheme 386) and remove cover.
  4. Remove air cleaner element (filter) from housing.
  5. Clean inside of housing before replacing element.
