5.7L Engine - Service Information: Specifications Dodge Magnum I рестайлинг

Mechanical 23 illustrations ~422 words

SPECIFICATIONS-5.7L ENGINE

DESCRIPTIONSPECIFICATION
Engine Type90° V-8 OHV
Displacement5.7 Liters
345 ( Cubic Inches)
Bore99.5 mm (3.91 in.)
Stroke90.9 mm (3.58 in.)
Compression Ratio9.6:1
Max. Variation Between Cylinders25%
Firing Order1-8-4-3-6-5-7-2
LubricationPressure Feed - Full Flow
Filtration
Cooling SystemLiquid Cooled - Forced
Circulation
Cylinder BlockCast Iron
Cylinder HeadAluminum
CrankshaftNodular Iron
CamshaftHollow Assembled Camshaft
PistonsAluminum Alloy
Connecting RodsPowdered Metal

GENERAL DESCRIPTION

DESCRIPTIONSPECIFICATION
MetricStandard
Cylinder Bore Diameter99.50 mm3.917 in.
Out of Round (MAX)0.0076 mm0003 in.
Taper (MAX)0.0127 mm0.0005 in.
Lifter Bore Diameter21.45 - 21.425 mm0.8444 - 0.8435 in.

CYLINDER BLOCK

DESCRIPTIONSPECIFICATION
MetricStandard
Clearance0.0215 - 0.0485 mm0.0008 - 0.0019 in.
Measured at 38.0 mm ( 1.5 in.) Below Deck
Ring Groove Diameter
Groove #189.6 - 89.8 mm3.527 - 3.535 in.
Groove #288.1 - 88.3 mm3.468 - 3.476 in.
Weight414.5 grams14.62 oz.
Piston Length54.70 - 55.302.153 - 2.177 in.
Ring Groove Width
No. 11.51 - 1.54 mm0.0594 - 0.0606 in
No. 21.51 - 1.53 mm0.0594 - 0.0602 in.
No. 33.030 - 3.055 mm0.1192 - 0.1202 in.

PISTONS

DESCRIPTIONSPECIFICATION
MetricStandard
Clearance In Piston0.009 - 0.018 mm0.00035 - 0.0007 in.
Diameter24.0 - 24.003 mm0.9448 - 0.9449 in.
Length70.53 - 71.03 mm2.78 - 2.80 in.

PISTON PINS

DESCRIPTIONSPECIFICATION
MetricStandard
Ring Gap
Top Compression Ring0.23 - 0.38 mm0.0090 - 0.0149 in.
Second Compression Ring0.35 - 0.60 mm0.0137 - 0.0236 in.
Oil Control (Steel Rails)0.15 - 0.66 mm0.0059 - 0.0259 in.
Side Clearance
Top Compression Ring.02 -.068 mm0.0007 - 0.0026 in.
Second Compression Ring0.02 - 0.058 mm0.0007 - 0.0022 in.
Oil Ring (Steel Ring).019 -.229 mm.0007 -.0091 in.
Ring Width
Top Compression Ring1.472 - 1.490 mm0.0579 - 0.0586 in.
Second Compression Ring1.472 - 1.490 mm0.0579 - 0.0586 in.
Oil Ring (Steel Rails)0.447 - 0.473 mm0.0175 - 0.0186 in.

PISTON RINGS

DESCRIPTIONSPECIFICATION
MetricStandard
Piston Pin Bore Diameter23.955 - 23.975 mm0.9431 - 0.9438 in.
Side Clearance0.10 - 0.35 mm0.003 - 0.0137 in.

CONNECTING RODS

DESCRIPTIONSPECIFICATION
MetricStandard
Main Bearing Journal Diameter64.988 - 65.012 mm2.5585 - 2.5595 in.
Bearing Clearance0.023 - 0.051 mm0.0009 - 0.002 in.
Out of Round (MAX)0.005 mm0.0002 in.
Taper (MAX)0.003 mm0.0001 in.
End Play0.052 - 0.282 mm0.002 - 0.011 in.
End Play (MAX)0.282 mm0.011 in.
Connecting Rod Journal Diameter53.992 - 54.008 mm2.125 - 2.126 in.
Bearing Clearance0.020 - 0.060 mm0.0007 - 0.0023 in.
Out of Round (MAX)0.005 mm0.0002 in.
Taper (MAX)0.003 mm0.0001 in.

CRANKSHAFT

DESCRIPTIONSPECIFICATION
MetricStandard
Bearing Journal Diameter
No. 158.2 mm2.29 in.
No. 257.8 mm2.27 in.
No. 357.4 mm2.26 in.
No. 457.0 mm2.24 in.
No. 543.633 mm1.72 in.
Bearing To Journal Clearance Standard
No. 10.040 - 0.080 mm.0015 -.003 in.
No. 20.050 -0.090 mm0.0019 -.0035 in.
No. 30.040 - 0.080 mm.0015 -.003 in.
No. 40.050 - 0.090 mm0.0019 -.0035 in.
No. 50.040 - 0.080 mm.0015 -.003 in.
Camshaft End Play.080 - 0.290 mm0.0031 - 0.0114 in.

CAMSHAFT

DESCRIPTIONSPECIFICATION
Intake
Opens (BTDC)5.0°
Closes (ATDC)255.0°
Exhaust
Opens (BTDC)236°
Closes (ATDC)32°
Duration269.3°
Valve Overlap37°

VALVE TIMING

DESCRIPTIONSPECIFICATION
Valve Seat Angle44.5° - 45.0°
Valve Seat Runout (MAX)0.05 mm (0.0019 in.)
Valve Seat Width (Finish)
Intake1.18 - 1.62 mm
(0.0464 - 0.0637 in.)
Exhaust1.48 - 1.92 mm
(0.0582 - 0.0755 in.)
Guide Bore Diameter (Std.)7.975 - 8.00 mm
(0.313 - 0.314 in.)

CYLINDER HEAD

DESCRIPTIONSPECIFICATION
MetricStandard
Body Diameter21.387 - 21.405 mm0.8420 - 0.8427 in.
Clearance (To Bore)0.020 - 0.063 mm0.0007 - 0.0024 in.
Dry Lash3.0 mm (at the valve)0.1181 in.

HYDRAULIC TAPPETS

DESCRIPTIONSPECIFICATION
Face Angle45.0° - 45.5°
Head Diameter
Intake50.67 - 50.93 mm
(1.99 - 2.00 in.)
Exhaust39.27 - 39.53 mm
(1.54 - 1.55 in.)
Length (Overall)
Intake123.38 - 123.76 mm
(4.857 - 4.872 in.)
Exhaust120.475 - 120.855 mm
(4.743 - 4.758 in.)
Stem Diameter
Intake7.935 - 7.953 mm
(0.312 - 0.313 in.)
Exhaust7.932 - 7.950 mm
(0.312 - 0.313 in.)
Stem - to - Guide Clearance
Intake0.022 - 0.065 mm
(0.0008 - 0.0025 in.)
Exhaust0.025 - 0.065 mm
(0.0009 - 0.0025 in.)
Valve Lift ( @ Zero Lash)
Intake12.0 mm (0.472 in.)
Exhaust11.70 mm (0.460 in.)

VALVES

DESCRIPTIONSPECIFICATION
Spring Force (Valve Closed)
Intake and Exhaust435.0 N +/- 22.0 N @ 45 mm (97.8 lbs +/- 5.0 lbs. @ 1.771 in.)
Spring Force (Valve Open)1077.0 N +/- 48.0 N @ 32.6 mm.
Intake and Exhaust( 242.0 lbs. +/- 11 lbs. @ 1.283 in. )
Free Length (approx)55.6 mm (2.189 in.)
Number of Coils
Intake and Exhaust7.95
Wire Diameter
Intake and Exhaust4.95 x 4.1 mm
(0.194 - 0.161 in.)
Installed Height (Spring Seat to Bottom of Retainer)
Intake and Exhaust46.0 mm (1.81 in.)

VALVE SPRING

DESCRIPTIONSPECIFICATION
Clearance Over Rotors (MAX)0.095 mm (0.0038 in.)
Outer Rotor to Pump Body Clearance (MAX).235 mm (.009 in.)
Tip Clearance Between Rotors (MAX)0.150 mm (0.006 in.)

OIL PUMP

SPECIFICATIONSPECIFICATION
At Curb Idle Speed (MIN)*25 kPa (4 psi)
@ 3000 rpm170 - 758 kPa (25 - 110 psi)
* CAUTION: If pressure is zero at curb idle, DO NOT run engine

OIL PRESSURE

TORQUE SPECIFICATIONS

DESCRIPTIONN.mFt.In.
Lbs.Lbs.
Block Pipe Plugs (1/4 NPT)20177
(3/8 NPT)27240
Camshaft Sprocket Bolt12290
Camshaft Tensioner Plate Bolts28250
Coil to Cylinder Head Cover Bolts762
Timing Chain Case Cover Bolts28250
Lifting Stud5540
Connecting Rod Cap Bolts21 plus 90° Turn15 plus 90° Turn
Main Bearing Cap Bolts M-1227 plus 90° Turn
Crossbolts M-828
Cylinder Head Bolts M-12 Bolts
Step 13425
Step 25440
Step 3Turn 90°Turn 90°
M-8 Bolts
Step 12015
Step 23425
Cylinder Head Cover Bolts870
Exhaust Manifold to Cylinder Head25220
Flexplate to crankshaft Bolts9570
Flywheel to crankshaft Bolts7555
Front Insulator Through bolt/nut9570
Front Insulator to Block Bolts9570
Generator Mounting Bolt5540
Intake Manifold BoltsRefer to Procedure
Lifter Guide Holder12106
Oil Pan Bolts12105
Oil Dipstick Tube12105
Oil Pan Drain Plug2720
Oil Pump Attaching Bolts28250
Oil Pump Pickup Tube Bolt and Nut28250
Rear Seal Retainer Attaching Bolts15132
Rear Insulator to Bracket6850
Rear Insulator to Crossmember4130
Rear Insulator to Transmission6850
Rear Insulator Bracket Bolts6850
Rocker Arm Bolts22195
Spark Plugs
Thermostat Housing Bolts28250
Throttle Body Bolts12105
Vibration Damper Bolt176129
Water Pump to Timing Chain28250
Case Cover Bolts

TORQUE CHART 5.7L ENGINE

Scheme 376

Scheme 376: 5.7L ENGINE
Scheme 376: 5.7L ENGINE

Scheme 377

Scheme 377
Scheme 377

Scheme 378

Scheme 378
Scheme 378

Scheme 379

Scheme 379
Scheme 379

Scheme 380

Scheme 380
Scheme 380

Scheme 381

Scheme 381
Scheme 381

Scheme 382

Scheme 382
Scheme 382

Scheme 383

Scheme 383
Scheme 383

Scheme 384

Scheme 384
Scheme 384

Scheme 385

Scheme 385
Scheme 385

Scheme 386

Scheme 386
Scheme 386

Scheme 387

Scheme 387
Scheme 387

Scheme 388

Scheme 388
Scheme 388

Scheme 389

Scheme 389
Scheme 389

Scheme 390

Scheme 390
Scheme 390

Scheme 391

Scheme 391
Scheme 391

Scheme 392

Scheme 392
Scheme 392

Scheme 393

Scheme 393
Scheme 393

Scheme 394

Scheme 394
Scheme 394

Scheme 395

Scheme 395
Scheme 395

Scheme 396

Scheme 396
Scheme 396

Scheme 397

Scheme 397: MDS SYSTEM
Scheme 397: MDS SYSTEM
1 - DEACTIVATING LIFTERS
2 - SOLENOIDS
3 - LIFTER OIL GALLERY
4 - MAIN OIL GALLERY

The Multiple Displacement System (MDS) provides cylinder deactivation during steady-speed, low-acceleration and shallow grade climbing conditions to increase fuel economy.

MDS can provide a 5-20 percent fuel economy benefit when operating in four-cylinder mode, depending on driving habits and vehicle usage. For EPA rating purposes, fuel economy is 8-15 percent higher than if the engine was operating on eight cylinders at all times.

MDS is integrated into the basic engine architecture, requiring a minimum of additional parts - four additional solenoids, an oil temperature sensor and a wire harness. Eight unique valve lifters and a modified camshaft are also required.

Scheme 398

Scheme 398: MDS SYSTEM
Scheme 398: MDS SYSTEM
1 - LATCHING PIN

The Multiple Displacement System (MDS) provides cylinder deactivation during steady-speed, low-acceleration and shallow grade climbing conditions to increase fuel economy. Both four- and eight-cylinder configurations have even firing intervals, providing smooth operation. Two cylinders on each bank are active when the engine is in four-cylinder mode - every other cylinder in the firing order. All of the cylinders that are deactivated have unique hydraulic valve lifters that collapse when deactivated to prevent the valves from opening. Engine oil pressure is used to activate and deactivate the valves. It is delivered through special oil passages drilled into the cylinder block. Solenoid valves control the flow. When activated, pressurized oil pushes a latching pin on each valve lifter, which then becomes a "lost motion" link. Its base follows the camshaft, but its top remains stationary, held in place against the pushrod by light spring pressure but unable to move because of the much higher force of the valve spring.

Note. It is critical to use the recommended oil viscosity in 5.7L engines that use MDS.

Deactivation occurs during the compression stroke of each cylinder, after air and fuel enter the cylinder. Ignition then occurs, but the combustion products remain trapped in the cylinder under high pressure, because the valves no longer open. No air enters or leaves. During subsequent piston strokes, this high-pressure gas is repeatedly compressed and expanded like an air spring, but fuel is not injected.

More articles — 5.7L Engine - Service Information
