TORQUE SPECIFICATIONS

DESCRIPTION	N.m	Ft. Lbs.	In. Lbs.
A/C Compressor to Engine - Bolts	28	21
Camshaft Sprocket - Bolts	28		250
Camshaft Chain Tensioner (Secondary) - Bolts	12		105
Camshaft Bearing Cap - Bolts	12		105
Connecting Rod Cap - Bolts	27 +1/4 Turn	20 +1/4 Turn
Cooling System Bleed Screw	12		110
Crankshaft Main Bearing Cap - Tie Bolts	28		250
Crankshaft Main Bearing Cap - Outer Cap Bolts	27 +1/4 Turn	20 +1/4 Turn
Crankshaft Main Bearing Cap - Inner Cap Bolts	20 +1/4 Turn	15 +1/4 Turn
Crankshaft Damper - Bolt	170	125
Crankshaft Rear Seal Retainer - Bolts	12		105
Cylinder Head - Bolts	See INSTALLATION .
Cylinder Head Cover - Bolts	12		105
Exhaust Manifold - Bolts	23		200
Exhaust Manifold Heat Shield - Bolts	12		105
Engine Mount Bracket to Block - Bolts	61	45
Engine Mount Isolator - Nuts	61	45
Intake Manifold (Upper and Lower) - Bolts	12		105
Generator Bracket-Bolts	41	30
Oil Pan - m8 Bolts	28		250
Oil Pan - m6 Nuts	12		105
Oil Pan Drain - Plug	27	20
Oil Cooler - Stud	61	45
Oil Filter	16	12
Oil Pump to Block - Bolts	28		250
Oil Pump Cover - Bolts	12		105
Oil Pump Pick Up Tube - Bolt	28		250
PCV Valve	7		60
Spark Plugs	20	15
Starter Mounting - Bolts	41	30
Structural Collar	See INSTALLATION .
Thermostat Housing/Water Inlet Connector - Bolts	12		105
Throttle Body - Bolts	12		105
Timing Chain Cover - M6 Bolts	12		105
Timing Chain Cover - M10 Bolts	54	40
Timing Chain Tensioner (Primary)	12		105
Timing Chain Guide Access Plug	20	15
Torque Converter	75	55
Water Pump - Bolts	12		105
Water Outlet Housing - Bolts	12		105

Scheme 1

Scheme 1: 2.7L ENGINE

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 35: REMOVAL

1 - AIR INLET DUCT TO THROTTLE BODY
2 - AIR CLEANER HOUSING COVER
3 - LOCKING TABS
4 - CCV HOSE

Scheme 36

Disconnect the CCV hose (4) at the housing cover (2). (Scheme 35)
Release the housing cover tabs (3). (Scheme 35)1 - AIR CLEANER COVER 2 - ELEMENT 3 - CCV HOSE
Lift the cover (1) and pull toward the front of the vehicle to release the rear cover to housing alignment tabs. (Scheme 36)
Remove the element (2).
Remove any dirt or debris from the bottom of the air filter housing. Cover the air inlet to the throttle body, or do not use compressed air. Otherwise, dirt or foreign objects can enter the intake manifold.

Scheme 37

Scheme 37: INSTALLATION

1 - AIR CLEANER COVER
2 - ELEMENT
3 - CCV HOSE

Install the air filter element (2) into air box. (Scheme 37)
Position the cover (1) so that the rear locking tabs insert into the lower housing.
Seat cover (1) onto element housing and assure that the front locking tabs engage.
Reconnect the CCV hose (3).

Scheme 38

Scheme 38: REMOVAL

1 - THROTTLE BODY
2 - CHARGE AIR TEMPERATURE SENSOR ELECTRICAL CONNECTOR
3 - CLEAN AIR DUCT
4 - AIR FILTER HOUSING ASSEMBLY
5 - BOLT
6 - VENT TUBE

Disconnect negative battery cable.
Disconnect the charge air temperature sensor electrical connector (2).
Disconnect the clean air duct between throttle body and air filter housing (3).
Disconnect the makeup air (MUA) tube.
Remove mounting bolt (5).
Remove air filter housing (4).
Raise vehicle.
Partially remove front fascia to gain access to air filter resonator. Refer to «REMOVAL»(ref-304467-S42157050482008111000000) .
Remove mounting bolt.
Remove air cleaner resonator.

OIL FILTER SPECIFICATION

All engines are equipped with a high quality full-flow, disposable type oil filter. When replacing oil filter, use a Mopar® filter or equivalent.
