TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Balance Shaft Module | Refer to Procedure | ||
| Bell Housing-Bolts | 48 | 35 | |
| Camshaft Bearing Cap-Bolts | |||
| M6 Bolts | 12 | 106 | |
| M8 Bolts | 30 | 22 | |
| Coils | 8 | 71 | |
| Connecting Rod Cap-Bolts | 20 + 90° | 15 + 90° | |
| Coolant Temperature Sender | 18 | 13 | |
| Crankshaft Main Bearing Cap-Bolts | Refer to Procedure | ||
| Crankshaft Damper-Bolt | 210 | 155 | |
| Cylinder Head-Bolts | Refer to Procedure | ||
| Cylinder Head Cover-Bolts | Refer to Procedure | ||
| Engine Support Bracket-Bolts | 40 | 30 | |
| Exhaust Manifold-Bolts | 34 | 25 | |
| Exhaust Manifold Heat Shield-Bolts | |||
| M6x25mm Bolts | 7 | 62 | |
| M6x70mm Bolts | 9 | 80 | |
| Flex Plate to Crankshaft-Bolts | 29 + 51° | 22 + 51° | |
| Intake Manifold-Bolts | 24 | 18 | |
| Ladder Frame | 22 | 16 | |
| Oil Cooler Connector Bolt | 49 | 36 | |
| Oil Filter | 14 | 10 | |
| Oil Filter Nipple | 49 | 36 | |
| Oil Jet Fastener | 12 | 106 | |
| Oil Pan-Bolts | |||
| M6 Bolts | 9 | 80 | |
| M8 Bolts | 24 | 18 | |
| Oil Pan Drain-Plug | 40 | 30 | |
| Oil Pressure Switch | 8 | 71 | |
| PCV Valve | 5 | 44 | |
| Phaser to Camshaft-Bolt | 59 | 44 | |
| Spark Plugs | 27 | 20 | 239 |
| Timing Chain Cover | |||
| M6 Bolts | 9 | 80 | |
| M8 Bolts | 26 | 19 | |
| Timing Chain Tensioner Assembly-Bolts | 12 | 106 | |
| Timing Chain Guides | 12 | 106 | |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
The engine serial number (1) is located between the oil pan and the bellhousing. The serial number contains engine build date, build location, and displacement.
Example: 8CAP1339710217
| GAS ENGINE | |||||||
|---|---|---|---|---|---|---|---|
| 8 | C | A | P1 | 339 | 7 | 1 | 0217 |
| Model Year | Engine Displacement | Engine Build Variation (with oil cooler, turbo, for MMNA) | Engine Plant | Julian Day of Year | Julian Year 2007 | Shift | Build Sequence Number |
| 2008 | A = 1.8L | P1 = GEMA North | |||||
| B = 2.0L | P2 = GEMA South | ||||||
| C = 2.4L | |||||||
Scheme 12
- Lift air cleaner housing cover (1).
- Remove filter element (2).
- If necessary, clean the inside of the air cleaner housing.
Scheme 13
- Install new filter element (2).
- Lower cover (1) and snap in place.
Scheme 14
- Remove air cleaner housing retaining bolt (2).
- Remove clean air hose from air cleaner housing.
- Lift air cleaner housing (1) upwards and remove.
Scheme 15
- Position air cleaner housing (1) in place.
- Install retaining bolt (2).
- Install clean air hose.
OIL FILTER SPECIFICATION
All engines are equipped with a high quality full-flow, disposable type oil filter. Replace oil filter with a Mopar® or the equivalent.
