CONTAINER IDENTIFICATION
The Engine Oil Certification Mark was developed and trademarked by the API to refer customers to those engine oils preferred by the automobile manufacturers. This symbol means that the oil has been certified and licensed by the American Petroleum Institute (API). This certification mark will only be found on the front of the oil containers . Those oils that do not display the "Mark" on the front of the container should not be used.
Chrysler only recommends API Certified engine oils that meet the requirements of Material Standard MS-6395. Use Mopar or an equivalent oil meeting the specification MS-6395.
DESCRIPTION
The fluid check/fill point locations are located in each applicable service information part.
Scheme 3
| 1 - RELAY - PCM |
|---|
| 2 - SPARE |
| 3 - RELAY - AUTO SHUT DOWN |
| 4 - SPARE |
| 5 - RELAY - RADIATOR FAN CONTROL |
| 6 - RELAY - REAR BLOWER MOTOR (3 ZONE HVAC) |
| 7 - RELAY - RUN/ACCESSORY |
| 8 - RELAY - RUN/START |
| 9 - RELAY - RUN |
| 10 - RELAY - REAR WINDOW DEFOGGER |
| 11 - RELAY - STARTER MOTOR |
The Totally Integrated Power Module (TIPM) is located in the engine compartment near the air cleaner assembly. This center contains fuses and relays.
| CAUTION | When installing the power module cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the TIPM, and possibly result in an electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
| Cavity | Description |
|---|---|
| 1 | PCM |
| 2 | SPARE |
| 3 | AUTO SHUT DOWN |
| 4 | SPARE |
| 5 | RADIATOR FAN CONTROL |
| 6 | REAR BLOWER MOTOR (3 ZONE HVAC) |
| 7 | RUN/ACCESSORY |
| 8 | RUN/START |
| 9 | RUN |
| 10 | REAR WINDOW DEFOGGER |
| 11 | STARTER MOTOR |
Relays
| TOTALLY INTEGRATED POWER MODULE (TIPM) | |||
|---|---|---|---|
| Cavity | Cartridge Fuse | Mini-Fuse | Description |
| J1 | 40 Amp Green | Power Folding Seat | |
| J2 | 30 Amp Pink | Transfer Case Module - if equipped | |
| J3 | 40 Amp Green | Rear Door Module | |
| J4 | 25 Amp White | Driver Door Node | |
| J5 | 25 Amp White | Passenger Door Node | |
| J6 | 40 Amp Green | Anti-Lock Brake System (ABS) Pump/Electronic Stability Program (ESP) | |
| J7 | 30 Amp Pink | Anti-Lock Brake System (ABS) Pump/Electronic Stability Program (ESP) | |
| J8 | 40 Amp Green | Power Seat - if equipped | |
| J9 | 40 Amp Green | Flex Fuel/PZEV Motor - if equipped | |
| J10 | 30 Amp Pink | Headlight Washer - if equipped | |
| J11 | 30 Amp Pink | THATCHM Relay Lock Feed | |
| J13 | 60 Amp Yellow | Ignition Off Draw (IOD) | |
| J14 | 40 Amp Green | Rear Window Defogger | |
| J15 | 30 Amp Pink | Rear Blower - if equipped | |
| J17 | 40 Amp Green | Starter Solenoid | |
| J18 | 20 Amp Yellow | Powertrain Control Module (PCM) | |
| J19 | 60 Amp Yellow | Radiator Fan Motor | |
| J20 | 30 Amp Pink | Windshield Wiper | |
| J21 | 20 Amp Blue | Front/Rear Washer | |
| J22 | 25 Amp White | Sunroof Module - if equipped | |
| M1 | 15 Amp Blue | Center High Mounted Stop Light (CHMSL) | |
| M2 | 20 Amp Yellow | (If Equipped) Trailer Lights | |
| M3 | 20 Amp Yellow | Front/Rear Axle | |
| M4 | 10 Amp Red | Trailer Tow - if equipped | |
| M5 | 25 Amp Natural | Power Inverter - if equipped | |
| M6 | 20 Amp Yellow | Power Outlet #1 | |
| M7 | 20 Amp Yellow | Power Outlet #2 (Battery/Ignition Select) | |
| M8 | 20 Amp Yellow | Front Heated Seats - if equipped | |
| M9 | 20 Amp Yellow | (If Equipped) Rear Heated Seats | |
| M10 | 15 Amp Blue | Vanity Lamps/Hands-Free Module (HFM) - if equipped, Remote Display - if equipped, Satellite Digital Audio Receiver (SDARS) - if equipped, Universal Garage Door Opener (UGDO) - if equipped, Vanity Light, Video Entertainment System (VES)® - if equipped | |
| M11 | 10 Amp Red | Automatic Temperature Control (ATC) - if equipped, Underhood Light, Microwave Sensor | |
| M12 | 30 Amp Green | Radio, Amplifier (AMP) | |
| M13 | 20 Amp Yellow | Cabin Compartment Node (CCN), Intrusion Module, Siren, Multifunction Switch | |
| M14 | 20 Amp Yellow | Trailer Tow - if equipped | |
| M15 | 20 Amp Yellow | Auto Dim Rearview Mirror - if equipped, Infrared Sensor (IR) - if equipped, Multifunction Switch, Tire Pressure Monitor System (TPMS) - if equipped | |
| M16 | 10 Amp Red | Occupant Restraint Controller (ORC) | |
| M17 | 15 Amp Blue | Left Park/Side Marker/Tail/Running Lights, License Lights | |
| M18 | 15 Amp Blue | Right Park/Side Marker/Tail/Running Lights | |
| M19 | 25 Amp Natural | Auto Shut Down (ASD) #1 and #2 | |
| M20 | 15 Amp Blue | Electronic Vehicle Information Center (EVIC) - if equipped, Interior Lighting, Steering Wheel Switches - if equipped, Switch Bank | |
| M21 | 20 Amp Yellow | Auto Shut Down (ASD) #3 | |
| M22 | 10 Amp Red | Right Horn | |
| M23 | 10 Amp Red | Left Horn | |
| M24 | 25 Amp Natural | Rear Wiper | |
| M25 | 20 Amp Yellow | Fuel Pump/Diesel Lift Pump - if equipped | |
| M26 | 10 Amp Red | Power MIRRORS Switch | |
| M27 | 10 Amp Red | Steering Column Lock, Wireless Ignition Node (WIN) | |
| M28 | 10 Amp Red | Powertrain Control Module (PCM) | |
| M29 | 10 Amp Red | Occupant Classification Module (OCM) | |
| M30 | 15 Amp Blue | Diagnostic Feed | |
| M31 | 20 Amp Yellow | Back-Up Lights | |
| M32 | 10 Amp Red | Trailer Tow - if equipped/Occupant Restraint Controller (ORC) | |
| M33 | 10 Amp Red | Powertrain Control Module (PCM) | |
| M34 | 10 Amp Red | Climate Control Module, Compass Module - if equipped, Flashlight - if equipped, Headlight Washer - if equipped, Diesel Radiator Fan - if equipped | |
| M35 | 10 Amp Red | Heated Mirrors - if equipped | |
| M36 | 20 Amp Yellow | Power Outlet | |
| M37 | 10 Amp Red | Anti-Lock Brake System (ABS) , Electronic Stability Program (ESP), STOP LIGHT Switch | |
| M38 | 25 Amp Natural | Lock/Unlock Motors | |
FUSE LOCATIONS AND TYPES
Scheme 4
| 1 - RELAY - CABIN HEATER 1 |
|---|
| 2 - RELAY - AUTO SHUT DOWN 2 |
| 3 - RELAY - CABIN HEATER 3 |
| 4 - RELAY - CABIN HEATER 2 |
Lubrication point locations are located in each applicable parts.
