Vehicle Quick Reference: Maintenance Dodge Journey I

AUTOMATIC/MANUAL TRANSAXLE FLUID

Note. All transaxles have a common transmission and differential sump. Filling the transaxle accommodates the differential as well.

Mopar ® ATF+4 (Automatic Transmission Fluid) is required in the automatic and T355/BG6 manual transaxles. Substitute fluids can induce torque converter clutch shudder, or premature geartrain failure.

Mopar ® ATF+4 (Automatic Transmission Fluid) when new is red in color. The ATF is dyed red so it can be identified from other fluids used in the vehicle such as engine oil or antifreeze. The red color is not permanent and is not an indicator of fluid condition. As the vehicle is driven, the ATF will begin to look darker in color and may eventually become brown. This is normal. ATF+4 also has a unique odor that may change with age. Consequently, odor and color cannot be used to indicate the fluid condition or the need for a fluid change.

FLUID ADDITIVES

Chrysler strongly recommends against the addition of any fluids to the transmission, other than those automatic transmission fluids listed above. Exceptions to this policy are the use of special dyes to aid in detecting fluid leaks.

Various "special" additives and supplements exist that claim to improve shift feel and/or quality. These additives and others also claim to improve converter clutch operation and inhibit overheating, oxidation, varnish, and sludge. These claims have not been supported to the satisfaction of Chrysler and these additives must not be used. The use of transmission "sealers" should also be avoided, since they may adversely affect the integrity of transmission seals.

BRAKE FLUID

The brake fluid used in this vehicle must conform to DOT 3 specifications and SAE J1703 standards. No other type of brake fluid is recommended or approved for usage in the vehicle brake system. Use only Mopar® Brake Fluid or equivalent from a tightly sealed container.

FLUID TYPES

When service is required, Chrysler recommends that only Mopar® brand parts, lubricants and chemicals be used. Mopar® provides the best engineered products for servicing Chrysler vehicles.

Only lubricants bearing designations defined by the following organization should be used to service a Chrysler vehicle

1. Society of Automotive Engineers (SAE)
2. American Petroleum Institute (API)
3. National Lubricating Grease Institute (NLGI)
4. European Automobile Manufacturers Association (ACEA)

Scheme 5

This symbol on the front of an oil container means that the oil has been certified by the American Petroleum Institute (API) to meet all the lubrication requirements specified by Chrysler.

POWER STEERING FLUID

The recommended fluid for the power steering system is Mopar® Power Steering fluid + 4 or Mopar® ATF+4 Automatic Transmission Fluid. Both Fluids have the same material standard specifications (MS-9602).

Mopar® ATF+4 (and Mopar® Power Steering fluid + 4), when new, is red in color. ATF+4 is dyed red so it can be identified from other fluids used in the vehicle such as engine oil or antifreeze. The red color is not permanent and is not an indicator of fluid condition. As the vehicle is driven, ATF+4 will begin to look darker in color and may eventually become brown. THIS IS NORMAL . ATF+4 also has a unique odor that may change with age. Consequently, odor and color cannot be used to indicate the fluid condition or the need for a fluid change.

The power steering system is filled-for-life at the factory and requires no regular maintenance. Although not required at specific intervals, the fluid level may be checked periodically. Check the fluid level anytime there is a system noise or fluid leak suspected. Refer to Steering/Pump/FLUID - Standard Procedure

FLUIDS, LUBRICANTS AND GENUINE PARTS

ENGINE

SPARK PLUGS

TRANSMISSION

TRANSFER CASE

CHASSIS

MAINTENANCE SCHEDULES - NAFTA - KOREAN GAS

The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.

On Electronic Vehicle Information Center (EVIC) equipped vehicles, "Oil Change Required" will be displayed in the EVIC and a single chime will sound, indicating that an oil change is necessary.

On Non-EVIC equipped vehicles, "Change Oil" will flash in the instrument cluster odometer and a single chime will sound, indicating that an oil change is necessary.

Based on engine operation conditions, the oil change indicator message will illuminate. This means that service is required for your vehicle. Have your vehicle serviced as soon as possible, within the next 500 mi (805 km).

Note. The oil change indicator message will not monitor the time since the last oil change. Change your vehicles oil if it has been six months since your last oil change, even if the oil change indicator message is NOT illuminated. Change your engine oil more often if you drive your vehicle off-road for an extended period of time. Under no circumstances should oil change intervals exceed 6,000 mi (10,000 km) or six months, whichever comes first.

The dealer will reset the engine oil change indicator message after completing the scheduled oil change. However, if a scheduled oil change is performed by someone other than your dealer, the message can be reset by performing the following procedure.

OIL CHANGE INDICATOR - RESET

Your vehicle is equipped with an engine oil change indicator system. The "Oil Change Required" message will flash in the EVIC display for approximately 10 seconds after a single chime has sounded to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate dependent upon your personal driving style.

Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the Menu button. To reset the oil change indicator system (after performing the scheduled maintenance) perform the following procedure

1. Turn the ignition switch to the "ON" position (Do not start the engine).
2. Fully depress the accelerator pedal slowly three times within 10 seconds.
3. Turn the ignition switch to the "LOCK" position.

Note. If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary repeat this procedure.

At Each Stop for Fuel

1. Check the engine oil level. See «Vehicle Quick Reference/Capacities and Recommended Fluids - Specifications»(ref-353564-S22108138092010011200000)
2. Check the windshield washer solvent and add if required.

Once a Month

1. Check tire pressure and look for unusual wear or damage.
2. Inspect the battery, and clean and tighten the terminals as required.
3. Check the fluid levels of coolant reservoir, brake master cylinder, power steering, and transaxle, and add as needed.
4. Check all lights and other electrical items for correct operation.

At Each Oil Change

1. Change the engine oil filter.
2. Inspect the brake hoses and lines.

Required Maintenance Intervals

** This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.

MAINTENANCE SCHEDULES - EXPORT - GAS - 2.0/2.4L ENGINES - EUROPE, MIDDLE EAST.

To help have the best driving experience possible, the manufacturer has identified the specific vehicle maintenance service intervals that are required to keep your vehicle operating properly and safely.

Chrysler recommends that these maintenance intervals be performed at your selling dealer. The technicians at your authorized dealership know your vehicle best, and have access to factory-trained information, genuine Mopar ® parts, and specially designed electronic and mechanical tools that can help prevent future costly repairs.

The maintenance intervals shown should be performed as indicated in this part.

Note. Under no circumstances should oil change intervals exceed 7,500 miles (12 000 km) or 12 months, whichever comes first.

At Each Stop for Fuel

1. Check the engine oil level about 5 minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accuracy of the oil level reading. Add oil only when the level is at or below the ADD or MIN mark.
2. Check the windshield washer solvent and add if required.

Once a Month

1. Check tire pressure and look for unusual wear or damage.
2. Inspect the battery and clean and tighten the terminals as required.
3. Check the fluid levels of coolant reservoir, brake master cylinder, power steering and transmission and add as needed.
4. Check all lights and other electrical items for correct operation.

At Each Oil Change

1. Change the engine oil filter.
2. Inspect the brake hoses and lines.

MAINTENANCE SCHEDULES - EXPORT - GAS - 2.0/2.4L ENGINES - (REST OF WORLD).

To help have the best driving experience possible, the manufacturer has identified the specific vehicle maintenance service intervals that are required to keep your vehicle operating properly and safely.

Chrysler recommends that these maintenance intervals be performed at your selling dealer. The technicians at your authorized dealership know your vehicle best, and have access to factory-trained information, genuine Mopar ® parts, and specially designed electronic and mechanical tools that can help prevent future costly repairs.

The maintenance intervals shown should be performed as indicated in this part.

Note. Under no circumstances should oil change intervals exceed 7,500 mi (12 000 km) or six months, whichever comes first.

At Each Stop for Fuel

1. Check the engine oil level about 5 minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accuracy of the oil level reading. Add oil only when the level is at or below the ADD or MIN mark.
2. Check the windshield washer solvent and add if required.

Once a Month

1. Check tire pressure and look for unusual wear or damage.
2. Inspect the battery, and clean and tighten the terminals as required.
3. Check the fluid levels of coolant reservoir, brake master cylinder, and transaxle, and add as needed.
4. Check all lights and other electrical items for correct operation.

At Each Oil Change

1. Change the engine oil filter.
2. Inspect the brake hoses and lines.

** This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.

MAINTENANCE SCHEDULES - EXPORT - GAS - 2.7L/3.5L ENGINES

To help have the best driving experience possible, the manufacturer has identified the specific vehicle maintenance service intervals that are required to keep your vehicle operating properly and safely.

Chrysler recommends that these maintenance intervals be performed at your selling dealer. The technicians at your authorized dealership know your vehicle best, and have access to factory-trained information, genuine Mopar ® parts, and specially designed electronic and mechanical tools that can help prevent future costly repairs.

The maintenance intervals shown should be performed as indicated in this part.

Note. Under no circumstances should oil change intervals exceed 7,500 miles (12 000 km) or 6 months, whichever comes first.

At Each Stop for Fuel

1. Check the engine oil level about 5 minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accuracy of the oil level reading. Add oil only when the level is at or below the ADD or MIN mark.
2. Check the windshield washer solvent and add if required.

Once a Month

1. Check tire pressure and look for unusual wear or damage.
2. Inspect the battery and clean and tighten the terminals as required.
3. Check the fluid levels of coolant reservoir, brake master cylinder, power steering and transmission and add as needed.
4. Check all lights and other electrical items for correct operation.

At Each Oil Change

1. Change the engine oil filter.
2. Inspect the brake hoses and lines.

Your vehicle may be equipped with an engine oil change indicator system. If so equipped, the "Oil Change Required" message will flash in the EVIC display for approximately 10 seconds after a single chime has sounded to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate dependent upon your personal driving style.

Unless reset, this message will continue to display each time you turn the ignition switch to the "ON" position. To turn off the message temporarily, press and release the Menu button. To reset the oil change indicator system (after performing the scheduled maintenance) perform the following procedure

1. Turn the ignition switch to the "ON" position (Do not start the engine).
2. Fully depress the accelerator pedal slowly three times within 10 seconds.
3. Turn the ignition switch to the "LOCK" position.

Note. If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary, repeat this procedure. Performing reset procedure Steps 1 through 3 allows for a 15 000 km service interval for engine oil and filter changes.

At Each Stop for Fuel

1. Check the engine oil level and add as required. Refer to «Engine/Lubrication/OIL - Standard Procedure»(ref-353574-S05970210532010011200000)
2. Check the windshield washer solvent and add if required.

Once a Month

1. Check the tire pressure and look for unusual wear or damage.
2. Inspect the battery and clean and tighten the terminals as required.
3. Check the fluid levels of coolant reservoir, brake master cylinder, power steering, and transaxle, and add as needed.
4. Check all lights and all other electrical items for correct operation.

At Each Oil Change

1. Replace the engine oil filter at each oil change.
2. Inspect the exhaust system.
3. Inspect brake linings, hoses, and calipers.
4. Inspect the CV joints and suspension components.
5. Check the coolant level, hoses, and clamps.
6. Inspect engine accessory drive belt(s).

MAINTENANCE SCHEDULE
