OPERATION
The power distribution system for this vehicle is designed to provide safe, reliable, centralized and convenient access to distribution of the electrical current required to operate all of the many standard and optional factory-installed electrical and electronic powertrain, chassis, safety, comfort and convenience systems. At the same time, these systems were designed to provide centralized locations for conducting diagnosis of faulty circuits and for sourcing the additional current requirements of many aftermarket vehicle accessory and convenience items.
These power distribution systems also incorporate various types of circuit control and protection features, including
- Automatic resetting circuit breakers
- Cartridge fuses
- Fusible links
- Mini and standard fuses
- Relays
The power distribution system for this vehicle may consist of the following components
- Accessory power outlet
- Junction Block (JB)
- Power Distribution Center (PDC)
- Totally Integrated Power Module (TIPM)
Scheme 1
| 1. RETAINING TABS | 3. POWER OUTLET |
|---|---|
| 2. ELECTRICAL CONNECTOR | 4. POWER OUTLET REMOVER |
DESCRIPTION
All vehicles are equipped with an Ignition-Off Draw (IOD) fuse that is disconnected within the Totally Integrated Power Module (TIPM) when the vehicle is shipped from the factory. Dealer personnel are to reconnect the IOD fuse in the TIPM as part of the preparation procedures performed just prior to new vehicle delivery.
The term ignition-off draw identifies a normal condition where power is being drained from the battery with the ignition switch in the Off position. The IOD fuse feeds the memory and sleep mode functions for some of the electronic modules in the vehicle as well as various other accessories that require battery current when the ignition switch is in the OFF position, including the clock. The only reason the IOD fuse is disconnected is to reduce the normal IOD of the vehicle electrical system during new vehicle transportation and pre-delivery storage to reduce battery depletion, while still allowing vehicle operation so that the vehicle can be loaded, unloaded and moved as needed by both vehicle transportation company and dealer personnel.
Dealer personnel must reconnect the IOD fuse when the vehicle is being prepared for delivery in order to restore full electrical system operation. Once the vehicle is prepared for delivery, the IOD function of this fuse becomes transparent and the fuse that has been assigned the IOD designation becomes only another Fused B(+) circuit fuse. The IOD fuse serves no useful purpose to the dealer technician in the service or diagnosis of any vehicle system or condition, other than the same purpose as that of any other standard circuit protection device.
The IOD fuse can be used by the vehicle owner as a convenient means of reducing battery depletion when a vehicle is to be stored for periods not to exceed about thirty days. However, it must be remembered that disconnecting the IOD fuse will not eliminate IOD, but only reduce this normal condition. If a vehicle will be stored for more than about thirty days, the battery negative cable should be disconnected to eliminate normal IOD; and, the battery should be tested and recharged at regular intervals during the vehicle storage period to prevent the battery from becoming discharged or damaged.
An electrical Junction Block (JB) is located next to the Totally Integrated Power Module (TIPM). The JB combines the functions previously provided by a separate relay center. It also serves to simplify and centralize numerous electrical components, as well as to distribute electrical current to many of the accessory systems in the vehicle. It eliminates the need for numerous splice connections and serves in place of a bulkhead connector between many of the engine compartment, instrument panel, and body wire harnesses. The junction block is replaced as part of the engine harness.
All of the electrical current distributed throughout this vehicle is directed through the standard equipment Totally Integrated Power Module (TIPM). The molded plastic TIPM housing is located on the right side of the engine compartment. The TIPM housing has a molded plastic cover. The TIPM cover is easily removed for service access and has a convenient fuse layout label affixed to the inside surface of the cover to ensure proper component identification.
The TIPM housing is secured to the TIPM mounting bracket by four clips integral to the TIPM housing. All of the TIPM outputs are through the integral engine compartment wire harness.
All of the current to the Totally Integrated Power Module (TIPM) comes directly from the positive battery cable to a stud located on the bottom of the TIPM. The cable is secured to the TIPM stud with a nut. Internal connection of all the TIPM circuits is accomplished by an intricate network of hard wiring and bus bars. Refer to appropriate wiring information for complete circuit diagrams.
The fuses, relays and TIPM housing assembly are available for service replacement.
