INVERTER MODULE

For complete circuit diagrams, refer to the appropriate wiring information.

WARNINGDisable the airbag system before attempting any steering wheel, steering column, seat belt tensioner, side airbag or instrument panel component diagnosis or service. Disconnect and isolate the negative battery (ground) cable. Wait two minutes for the airbag system capacitor to discharge before performing further diagnosis or service. This is the only sure way to disable the airbag system. Failure to follow these instructions may result in accidental airbag deployment and possible serious or fatal injury.
CONDITIONPOSSIBLE CAUSESCORRECTION
NO POWER AT THE 110 VOLT POWER OUTLET1. Fuse inoperative.1. Check Totally Integrated Power Module (TIPM) fuse number 37. Replace fuse, if required.
2. Power outlet connector damaged.2. Check for loose or corroded power outlet connector. Repair, if required.
3. Inverter module connector damaged.3. Check for loose or corroded inverter module connector. Repair, if required.
4. Wiring damaged.4. Check for shorted or open wires. Repair wiring, if required.
5. Inverter module ground damaged.5. Check for continuity between the inverter module and a known good ground. There should be continuity. Repair ground, if required.
6. Power outlet inoperative.6. Replace the power outlet.
7. Inverter module inoperative.7. Replace the inverter module.

110 VOLT POWER OUTLET DIAGNOSIS

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL
  1. Disconnect and isolate the battery negative cable.
  2. Position the front drivers seat to the full rearward position.
  3. Remove the power inverter (2) mounting retainers (1) located under the carpet.
  4. Disconnect the electrical connectors.
  5. Remove the power inverter module from the vehicle.

PROGRAMMING

  1. Install a battery charger.
  2. Verify that the charging rate provides approximately 13.5 volts. NOTE: Do not allow the charger to time out during the reconfiguration process. Set the battery charger timer (if so equipped) to continuous charge.
  3. Connect the CH9410 StarSCAN ethernet cable to the StarSCAN and the dealer's network drop.
  4. Connect the CH9404 StarSCAN vehicle cable to the StarSCAN and the vehicle.
  5. Place the Ignition in the "RUN" position, then Power "ON" the StarSCAN.
  6. Select "ECU View".
  7. Select "TIPMCGW" or "FCMCGW".
  8. Select "MISC".
  9. Select "Restore Vehicle Configuration".
  10. Follow prompts on StarSCAN to complete the reconfigure procedure.
  11. Once complete, Wait one minute and turn the ignition key to the "OFF" position.
  12. Remove the StarSCAN unit, cable and charger from the vehicle.
  13. Verify proper operation.
