Wiring diagram: Radio — Radio circuit Dodge Durango III

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• 1 2 Am/Fm Coax Am/Fm Coax Shld
• 1 Input
• 1 Rtn
• 2 Input
• 2 Rtn
• Am/Fm Coax
• Am/Fm Coax Shld
• Aud Aux Rtn 2 Right Aux Aud 2
• Aud Left 1
• Aud Left 2
• Aud Left 3
• Aud Right 1
• Aud Right 2
• Aud Right 3
• Aud Rtn 1
• Aud Rtn 2
• Aud Rtn 3
• Aud Sig Lf +
• Aud Sig Rt
• Audio Left 1 Audio Return 1 Audio Right 1 Audio Left 2 Audio Right 2
• Aux Audio Rtn 2 Aux Audio Rh Sig 2
• Auxiliary Audio Video Port
• Camera
• Center Instrument Panel Speaker
• Comp Fd
• Console Overhead Assembly
• Hands Free Module
• Hf Audo Output Com Hnds Free Mic In - Hf Mic Ref
• Hf Mic Hsd Fd
• Inside Rearview Mirror
• Iod Fd2
• Left D Pillar Speaker
• Left Front Door Speaker
• Left Front Door Tweeter Speaker
• Left Rear Door Speaker
• Left Remote Radio Switch
• License Plate Lamp/ Rear Camera Assembly
• Rad Lt Rr Rad Rt Rr
• Radio Antenna2
• Radio, Amplifier
• Rem Rad Ctrl Sw Sig
• Rem Rad Sw Snse Rtn
• Return
• Right D Pillar Speaker
• Right Front Door Speaker
• Right Front Door Tweeter Speaker
• Right Rear Door Speaker
• Right Remote Radio Switch
• Satellite Radio Antenna
• Satellite Video Antenna
• Satellite Video Module
• Sdar Coax Sat Shld Sdar Coax Sat Sig 2 1 1 2
• Sdar Coax Sat Sig Sdar Coax Sat Shld 1 2
• Shield
• Speed Control Switch
• Steering Control Module
• Subwoofer
• Subwoofer Speaker
• USB 2 Port
• Vaux Sig 2
• Video Screen Module3
