Wiring diagram: Anti-theft — Forced entry circuit Dodge Durango III

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• 1 2 Lgate Ajar Sig Gnd
• 15 Assy Pdc
• 3.6L Heat, Express
• 5.7L, Except 3.6L Heat, Express
• Abmt Temp/Fcm Ssr Rtn 1
• Ambient Air Temperature Sensor
• Can-Bus
• Dr Ajar Lt Rr Sig
• Dr Ajar Rt Rr Sig
• Driver Door Latch
• Driver Door Module
• Driver Door Unlock Relay
• Driver Window/ Door Lock Switch
• Drv Ft Dr Ajar Sw In
• Eatx Batt Fd
• Front Washer Fluid Level Sensor
• Ft Drv Dr Lk
• Ft Drv Dr Ulk
• Ft Pass Dr Lk
• Ft Pass Dr Lk Sw Sig
• Ft Pass Dr Ulk
• Ft Pass Sw Illm/Sns Rtn
• Ft Pass Up Sw Snse
• Hood Ajar Switch
• Left Rear Power Window Switch
• Lifegate Unlock Relay Power Distribution Center
• Liftgate Door Latch
• Lin Dcm Dr
• Lt Rr Lk
• Lt Rr Ulk
• Pass Dr Dr Lock Ajar Rly Sw In Ctrl
• Pass Ft Dr Ajar Sw In
• Pass Ft Lr, Rr Unlk Ctrl
• Passenger Door Latch
• Passenger Door Module
• Passenger Door Unlock Relay
• Passenger Window/ Door Lock Switch
• Right Rear Power Window Switch
• Rr Dr Ulk Rly Ctrl
• Rt Rr Lk
• Rt Rr Lt Rr Dr Dr Ajar Ajar Sig Sig
• Rt Rr Ulk
• Sw Illm Ft Pass
• Sw Pwr Lk Out Fd Rr Lt
• Sw Pwr Lk Out Fd Rr Lt Lin Slve Rtn Lin Dcm Dr Gnd 1 9 10 11
• Sw Pwr Lk Out Fd Rr Tt
• Totally Integrated Power Module
