Starting - Service Information: Specifications Dodge Durango III

Starter 10 illustrations ~325 words

TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Battery Cable Eyelet Nut at Solenoid (large nut)2519221
Starter Mounting Bolts6850

Scheme 1

Scheme 1: DESCRIPTION

The Remote Start Antenna Module Assembly consists of an electrical connection to the Wireless Ignition Node (WIN) (1), a length of coax cable (2), mounting clips, or tie wraps (3) and (4), and a control module/antenna (5).

Scheme 2

Scheme 2: REMOVAL

The Remote Start Antenna Module Assembly consists of an electrical connection to the Wireless Ignition Node (WIN) (1), a length of coax cable (2), mounting clips or tie wraps (3) and (4), and a control module/antenna (5).

The control module is located between the passenger side air bag and the glove box liner. The module electrical connector plugs into the WIN attached to the ignition switch located near the right side of the steering column.

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10
  1. Disconnect and isolate negative cable from battery.
  2. Remove the drivers scuff plate. Refer to «PLATE, SCUFF, DOOR, REMOVAL»(ref-465921-S01157018472012042300000) . NOTE: Passenger side shown in illustration, drivers side similar.
  3. Remove the drivers cowl trim panel. Refer to «PANEL, COWL TRIM, SIDE, REMOVAL»(ref-465921-S36276791172012042300000) .
  4. Remove the drivers side silencer pad.
  5. Remove the steering column opening cover. Refer to «COVER, STEERING COLUMN OPENING, REMOVAL»(ref-465921-S13011093802012042300000) .
  6. Remove the right side knee blocker support bracket.
  7. Remove the glovebox. Refer to «GLOVE BOX, INSTRUMENT PANEL, REMOVAL»(ref-465921-S37826842652012042300000) .
  8. Remove the glovebox liner.
  9. Remove the instrument panel center bezel. Refer to «BEZEL, INSTRUMENT PANEL, CENTER, REMOVAL»(ref-465921-S12753781422012042300000) .
  10. Through the steering column opening disconnect the Wireless Ignition Node (WIN) antenna connector (1) from the WIN (2).
  11. Unclip the two WIN antenna (2) harness clips (1) from the support.
  12. Through the glove box opening (2) release the two antenna harness clips (1) from the back of the instrument panel. NOTE: The antenna is located between the passenger side airbag (3) and the glove box opening support (4).
  13. Remove the retainers (1) from the remote start antenna (2).
  14. Gently pull the cable out from behind the instrument panel.
