Memory Seat Module (Msmd) - Electrical Diagnostics: Other Dodge Durango III

WHEN MONITORED

Continuously.

SET CONDITION

The MSMD detects an open in either driver seat switch mux circuit.

POSSIBLE CAUSES

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Cycle the Driver Seat Switch in all directions several times. Wait one minute. With the scan tool, read the active DTCs. Does the scan tool display B1D5E-13-POWER SEAT SWITCH-CIRCUIT OPEN? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
2. CHECKING THE (P28) DRIVER SEAT SWITCH MUX RETURN CIRCUIT Turn the ignition off. Disconnect the Driver Seat Switch harness connector. Measure the resistance between ground and the (P28) Driver Seat Switch Mux Return circuit. Is the resistance below 40 Ohms? Yes Go To 3 . No Go To 5 .
3. CHECKING THE (P311) DRIVER SEAT FRONT VERTICAL/RECLINER SWITCH MUX CIRCUIT Connect the Driver Seat Switch harness connector. Disconnect the MSMD C4 harness connector. Measure the resistance between the (P311) Driver Seat Front Vertical/Recliner Switch Mux circuit and the (P28) Driver Seat Switch Mux Return circuit. Is the resistance between 40 and 60 Ohms? Yes Go To 4 . No Go To 6 .
4. CHECKING THE (P309) DRIVER SEAT REAR VERTICAL/HORIZONTAL SWITCH MUX CIRCUIT Measure the resistance between the (P309) Driver Seat Rear Vertical/Horizontal Switch Mux circuit and the (P28) Driver Seat Switch Mux Return circuit. Is the resistance between 40 and 60 Ohms? Yes Go To 8 . No Go To 7 .
5. CHECKING THE (P28) DRIVER SEAT SWITCH MUX RETURN CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Disconnect the MSMD C4 harness connector. Measure the resistance of the (P28) Driver Seat Switch Mux Return circuit between the Driver Seat Switch harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (P28) Driver Seat Switch Mux Return circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 8 .
6. CHECKING THE (P311) DRIVER SEAT FRONT VERTICAL/RECLINER SWITCH MUX CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Disconnect the Driver Seat Switch harness connector. Measure the resistance of the (P311) Driver Seat Front Vertical/Recliner Switch Mux circuit between the Driver Seat Switch harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (P311) Driver Seat Front Vertical/Recliner Switch Mux circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the Driver Seat Switch in accordance with the Service Information. Refer to «SWITCH, SEAT , REMOVAL»(ref-465977-S00547374242012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
7. CHECKING THE (P309) DRIVER SEAT REAR VERTICAL/HORIZONTAL SWITCH MUX CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Disconnect the Driver Seat Switch harness connector. Measure the resistance of the (P309) Driver Seat Rear Vertical/Horizontal Switch Mux circuit between the Driver Seat Switch harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (P309) Driver Seat Rear Vertical/Horizontal Switch Mux circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the Driver Seat Switch in accordance with the Service Information. Refer to «SWITCH, SEAT , REMOVAL»(ref-465977-S00547374242012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
8. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Switch and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Switch and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

B1D62-2A-POWER SEAT SWITCH STUCK-STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

The Memory Seat Module (MSM) detects that the Driver Seat Switch is in an active position for longer than 50 seconds.

The seat motor is activated.

If sensor voltage is not within a specified range. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

Scheme 110

Scheme 111

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Move the Seat Switch in the horizontal position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D6B-11-SEAT HORIZONTAL POSITION SENSOR - CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
2. CHECKING THE (G401) DRIVER SEAT HORIZONTAL POSITION SENSE CIRCUIT Disconnect the Driver Horizontal Seat Adjuster Motor harness connector. Measure the voltage between the (G401) Driver Seat Horizontal Position Sense circuit and ground. Is the voltage above 11 volts? Yes Replace the Seat Adjuster Horizontal Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 3 .
3. CHECKING THE (G401) DRIVER SEAT HORIZONTAL POSITION SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance between ground and the (G401) Driver Seat Horizontal Position Sense circuit. Is the resistance below 1K Ohms. Yes Repair the short to ground in the (G401) Driver Seat Horizontal Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Horizontal Seat Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Horizontal Seat Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST.

B1D6B-12-SEAT HORIZONTAL POSITION SENSOR - CIRCUIT SHORT TO BATTERY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

If sensor voltage is not within a specified range. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

B1D6F-11-SEAT FRONT VERTICAL POSITION SENSOR - CIRCUIT SHORT TO GROUND

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

If sensor voltage is not within a specified range. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

B1D6F-12-SEAT FRONT VERTICAL POSITION SENSOR - CIRCUIT SHORT TO BATTERY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

If sensor voltage is not within a specified range. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

B1D73-11-SEAT REAR VERTICAL POSITION SENSOR - CIRCUIT SHORT TO GROUND

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

If sensor voltage is not within a specified range. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

B1D73-12-SEAT REAR VERTICAL POSITION SENSOR - CIRCUIT SHORT TO BATTERY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

If sensor voltage is not within a specified range. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

B1D77-11-SEAT RECLINER POSITION SENSOR - CIRCUIT SHORT TO GROUND

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

If sensor voltage is not within a specified range. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

B1D77-12-SEAT RECLINER POSITION SENSOR - CIRCUIT SHORT TO BATTERY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

If sensor voltage is not within a specified range. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

B1D7B-00-SEAT HORIZONTAL MOTOR CONTROL CIRCUIT PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

The MSMD does not detect seat motor activation. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

1. CHECK FOR RELATED DIAGNOSTIC TROUBLE CODES Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display any seat position sensor DTCs? Yes Diagnose and repair the other DTC(s) first. Refer to «DIAGNOSIS AND TESTING»(ref-465956-S42505359132012042300000) . No Go To 2 .
2. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the horizontal position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D7B-00-SEAT HORIZONTAL MOTOR CONTROL CIRCUIT PERFORMANCE? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECKING THE (G401) DRIVER SEAT HORIZONTAL POSITION SENSE CIRCUIT Disconnect the Driver Horizontal Seat Adjuster Motor harness connector. Measure the voltage between the (G401) Driver Seat Horizontal Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 4 . No Go To 11 .
4. CHECKING THE (G491) DRIVER SEAT HORIZONTAL SENSOR GROUND CIRCUIT Measure the voltage between the (G401) Driver Seat Horizontal Position Sense circuit and the (G491) Driver Seat Horizontal Sensor Ground circuit. Is the voltage above 11 volts? Yes Go To 5 . No Go To 12 .
5. CHECKING THE (P115) DRIVER SEAT HORIZONTAL FORWARD DRIVER CIRCUIT Measure the voltage between the (P115) Driver Seat Horizontal Forward Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 13 . No Go To 6 .
6. CHECKING THE (P117) DRIVER SEAT HORIZONTAL REARWARD DRIVER CIRCUIT Measure the voltage between the (P117) Driver Seat Horizontal Rearward Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 14 . No Go To 7 .
7. CHECKING THE (P115) DRIVER SEAT HORIZONTAL FORWARD DRIVER CIRCUIT Connect a 12-volt test light between the (P115) Driver Seat Horizontal Forward Driver circuit and ground. While observing the test light, move the Driver Seat Horizontal Switch in the forward position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 8 . No Go To 15 .
8. CHECKING THE (P117) DRIVER SEAT HORIZONTAL REARWARD DRIVER CIRCUIT Connect a 12-volt test light between the (P117) Driver Seat Horizontal Rearward Driver circuit and ground. While observing the test light, move the Driver Seat Horizontal Switch in the rearward position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 9 . No Go To 17 .
9. CHECKING THE DRIVER SEAT HORIZONTAL REARWARD DRIVER Connect a 12-volt test light between the (P115) Driver Seat Horizontal Forward Driver circuit and the (P117) Driver Seat Horizontal Rearward Driver circuit. While observing the test light, move the Driver Seat Horizontal Switch in the forward position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 10 . No Go To 19 .
10. CHECKING THE DRIVER SEAT HORIZONTAL FORWARD DRIVER While observing the test light, move the Driver Seat Horizontal Switch in the rearward position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Replace the Seat Adjuster Horizontal Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
11. CHECKING THE (G401) DRIVER SEAT HORIZONTAL POSITION SENSE CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance of the (G401) Driver Seat Horizontal Position Sense circuit between the Driver Seat Horizontal Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (G401) Driver Seat Horizontal Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
12. CHECKING THE (G491) DRIVER SEAT HORIZONTAL SENSOR GROUND CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance of the (G491) Driver Seat Horizontal Sensor Ground circuit between the Driver Seat Horizontal Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (G491) Driver Seat Horizontal Sensor Ground circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
13. CHECKING THE (P115) DRIVER SEAT HORIZONTAL FORWARD DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C3 harness connector. Measure the voltage between the (P115) Driver Seat Horizontal Forward Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P115) Driver Seat Horizontal Forward Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
14. CHECKING THE (P117) DRIVER SEAT HORIZONTAL REARWARD DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C3 harness connector. Measure the voltage between the (P117) Driver Seat Horizontal Rearward Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P117) Driver Seat Horizontal Rearward Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
15. CHECKING THE (P115) DRIVER SEAT HORIZONTAL FORWARD DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance between ground and the (P115) Driver Seat Horizontal Forward Driver circuit. Is the resistance below 1K Ohms? Yes Repair the short to ground in the (P115) Driver Seat Horizontal Forward Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 16 .
16. CHECKING THE (P115) DRIVER SEAT HORIZONTAL FORWARD DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P115) Driver Seat Horizontal Forward Driver circuit between the Driver Seat Horizontal Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (P115) Driver Seat Horizontal Forward Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
17. CHECKING THE (P117) DRIVER SEAT HORIZONTAL REARWARD DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance between ground and the (P117) Driver Seat Horizontal Rearward Driver circuit. Is the resistance below 1K Ohms? Yes Repair the short to ground in the (P117) Driver Seat Horizontal Rearward Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 18 .
18. CHECKING THE (P117) DRIVER SEAT HORIZONTAL REARWARD DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P117) Driver Seat Horizontal Rearward Driver circuit between the Driver Seat Horizontal Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (P117) Driver Seat Horizontal Rearward Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
19. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Horizontal Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Horizontal Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

B1D7F-00-SEAT FRONT VERTICAL MOTOR CONTROL CIRCUIT PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

The MSMD does not detect seat motor activation. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

Scheme 124

Scheme 125

Scheme 126

Scheme 127

1. CHECK FOR RELATED DIAGNOSTIC TROUBLE CODES Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display any seat position sensor DTCs? Yes Diagnose and repair the other DTC(s) first. Refer to «DIAGNOSIS AND TESTING»(ref-465956-S42505359132012042300000) . No Go To 2 .
2. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the front vertical position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D7F-00-SEAT FRONT VERTICAL MOTOR CONTROL CIRCUIT PERFORMANCE? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECKING THE (G404) DRIVER SEAT FRONT VERTICAL POSITION SENSE CIRCUIT Disconnect the Driver Front Vertical Seat Adjuster Motor harness connector. Measure the voltage between the (G404) Driver Seat Front Vertical Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 4 . No Go To 11 .
4. CHECKING THE (G494) DRIVER SEAT FRONT VERTICAL SENSOR GROUND CIRCUIT Measure the voltage between the (G404) Driver Seat Front Vertical Position Sense circuit and the (G494) Driver Seat Front Vertical Sensor Ground circuit. Is the voltage above 11 volts? Yes Go To 5 . No Go To 12 .
5. CHECKING THE (P119) DRIVER SEAT FRONT VERTICAL UP DRIVER CIRCUIT Measure the voltage between the (P119) Driver Seat Front Vertical Up Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 13 . No Go To 6 .
6. CHECKING THE (P121) DRIVER SEAT FRONT VERTICAL DOWN DRIVER CIRCUIT Measure the voltage between the (P121) Driver Seat Front Vertical Down Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 14 . No Go To 7 .
7. CHECKING THE (P119) DRIVER SEAT FRONT VERTICAL UP DRIVER CIRCUIT Connect a 12-volt test light between the (P119) Driver Seat Front Vertical Up Driver circuit and ground. While observing the test light, move the Driver Seat Front Vertical Switch in the up position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 8 . No Go To 15 .
8. CHECKING THE (P121) DRIVER SEAT FRONT VERTICAL DOWN DRIVER CIRCUIT Connect a 12-volt test light between the (P121) Driver Seat Front Vertical Down Driver circuit and ground. While observing the test light, move the Driver Seat Front Vertical Switch in the down position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 9 . No Go To 17 .
9. CHECKING THE DRIVER SEAT FRONT VERTICAL DOWN DRIVER Connect a 12-volt test light between the (P119) Driver Seat Front Vertical Up Driver circuit and the (P121) Driver Seat Front Vertical Down Driver circuit. While observing the test light, move the Driver Seat Front Vertical Switch in the up position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 10 . No Go To 19 .
10. CHECKING THE DRIVER SEAT FRONT VERTICAL UP DRIVER While observing the test light, move the Driver Seat Front Vertical Switch in the down position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Replace the Seat Adjuster Front Vertical Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
11. CHECKING THE (G404) DRIVER SEAT FRONT VERTICAL POSITION SENSE CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance of the (G404) Driver Seat Front Vertical Position Sense circuit between the Driver Seat Front Vertical Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (G404) Driver Seat Front Vertical Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
12. CHECKING THE (G494) DRIVER SEAT FRONT VERTICAL SENSOR GROUND CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance of the (G494) Driver Seat Front Vertical Sensor Ground circuit between the Driver Seat Front Vertical Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (G494) Driver Seat Front Vertical Sensor Ground circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
13. CHECKING THE (P119) DRIVER SEAT FRONT VERTICAL UP DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C3 harness connector. Measure the voltage between the (P119) Driver Seat Front Vertical Up Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P119) Driver Seat Front Vertical Up Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
14. CHECKING THE (P121) DRIVER SEAT FRONT VERTICAL DOWN DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C3 harness connector. Measure the voltage between the (P121) Driver Seat Front Vertical Down Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P121) Driver Seat Front Vertical Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
15. CHECKING THE (P119) DRIVER SEAT FRONT VERTICAL UP DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance between ground and the (P119) Driver Seat Front Vertical Up Driver circuit. Is the resistance below 1K Ohms? Yes Repair the short to ground in the (P119) Driver Seat Front Vertical Up Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 16 .
16. CHECKING THE (P119) DRIVER SEAT FRONT VERTICAL UP DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P119) Driver Seat Front Vertical Up Driver circuit between the Driver Seat Front Vertical Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (P119) Driver Seat Front Vertical Up Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
17. CHECKING THE (P121) DRIVER SEAT FRONT VERTICAL DOWN DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance between ground and the (P121) Driver Seat Front Vertical Down Driver circuit. Is the resistance below 1K Ohms? Yes Repair the short to ground in the (P121) Driver Seat Front Vertical Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 18 .
18. CHECKING THE (P121) DRIVER SEAT FRONT VERTICAL DOWN DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P121) Driver Seat Front Vertical Down Driver circuit between the Driver Seat Front Vertical Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (P121) Driver Seat Front Vertical Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
19. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Front Vertical Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Front Vertical Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

B1D83-00-SEAT REAR VERTICAL MOTOR CONTROL CIRCUIT PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

The MSMD does not detect seat motor activation. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

Scheme 128

Scheme 129

Scheme 130

Scheme 131

1. CHECK FOR RELATED DIAGNOSTIC TROUBLE CODES Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display any seat position sensor DTCs? Yes Diagnose and repair the other DTC(s) first. Refer to «DIAGNOSIS AND TESTING»(ref-465956-S42505359132012042300000) . No Go To 2 .
2. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the rear vertical position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D83-00-SEAT REAR VERTICAL MOTOR CONTROL CIRCUIT PERFORMANCE? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECKING THE (G402) DRIVER SEAT REAR VERTICAL POSITION SENSE CIRCUIT Disconnect the Driver Rear Vertical Seat Adjuster Motor harness connector. Measure the voltage between the (G402) Driver Seat Rear Vertical Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 4 . No Go To 11 .
4. CHECKING THE (G492) DRIVER SEAT REAR VERTICAL SENSOR GROUND CIRCUIT Measure the voltage between the (G402) Driver Seat Rear Vertical Position Sense circuit and the (G492) Driver Seat Rear Vertical Sensor Ground circuit. Is the voltage above 11 volts? Yes Go To 5 . No Go To 12 .
5. CHECKING THE (P111) DRIVER SEAT REAR VERTICAL DOWN DRIVER CIRCUIT Measure the voltage between the (P111) Driver Seat Rear Vertical Down Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 13 . No Go To 6 .
6. CHECKING THE (P113) DRIVER SEAT REAR VERTICAL UP DRIVER CIRCUIT Measure the voltage between the (P113) Driver Seat Rear Vertical Up Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 14 . No Go To 7 .
7. CHECKING THE (P111) DRIVER SEAT REAR VERTICAL DOWN DRIVER CIRCUIT Connect a 12-volt test light between the (P111) Driver Seat Rear Vertical Down Driver circuit and ground. While observing the test light, move the Driver Seat Rear Vertical Switch in the down position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 8 . No Go To 15 .
8. CHECKING THE (P113) DRIVER SEAT REAR VERTICAL UP DRIVER CIRCUIT Connect a 12-volt test light between the (P113) Driver Seat Rear Vertical Up Driver circuit and ground. While observing the test light, move the Driver Seat Rear Vertical Switch in the up position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 9 . No Go To 17 .
9. CHECKING THE DRIVER SEAT REAR VERTICAL DOWN DRIVER Connect a 12-volt test light between the (P111) Driver Seat Rear Vertical Down Driver circuit and the (P113) Driver Seat Rear Vertical Up Driver circuit. While observing the test light, move the Driver Seat Rear Vertical Switch in the down position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 10 . No Go To 19 .
10. CHECKING THE DRIVER SEAT REAR VERTICAL UP DRIVER While observing the test light, move the Driver Seat Rear Vertical Switch in the up position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Replace the Seat Adjuster Rear Vertical Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
11. CHECKING THE (G402) DRIVER SEAT REAR VERTICAL POSITION SENSE CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance of the (G402) Driver Seat Rear Vertical Position Sense circuit between the Driver Seat Rear Vertical Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (G402) Driver Seat Rear Vertical Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
12. CHECKING THE (G492) DRIVER SEAT REAR VERTICAL SENSOR GROUND CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance of the (G492) Driver Seat Rear Vertical Sensor Ground circuit between the Driver Seat Rear Vertical Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (G492) Driver Seat Rear Vertical Sensor Ground circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
13. CHECKING THE (P111) DRIVER SEAT REAR VERTICAL DOWN DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C3 harness connector. Measure the voltage between the (P111) Driver Seat Rear Vertical Down Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P111) Driver Seat Rear Vertical Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
14. CHECKING THE (P113) DRIVER SEAT REAR VERTICAL UP DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C3 harness connector. Measure the voltage between the (P113) Driver Seat Rear Vertical Up Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P113) Driver Seat Rear Vertical Up Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
15. CHECKING THE (P111) DRIVER SEAT REAR VERTICAL DOWN DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance between ground and the (P111) Driver Seat Rear Vertical Down Driver circuit. Is the resistance below 1K Ohms? Yes Repair the short to ground in the (P111) Driver Seat Rear Vertical Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 16 .
16. CHECKING THE (P111) DRIVER SEAT REAR VERTICAL DOWN DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P111) Driver Seat Rear Vertical Down Driver circuit between the Driver Seat Rear Vertical Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (P111) Driver Seat Rear Vertical Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
17. CHECKING THE (P113) DRIVER SEAT REAR VERTICAL UP DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance between ground and the (P113) Driver Seat Rear Vertical Up Driver circuit. Is the resistance below 1K Ohms? Yes Repair the short to ground in the (P113) Driver Seat Rear Vertical Up Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST. No Go To 18 .
18. CHECKING THE (P113) DRIVER SEAT REAR VERTICAL UP DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P113) Driver Seat Rear Vertical Up Driver circuit between the Driver Seat Rear Vertical Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (P113) Driver Seat Rear Vertical Up Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
19. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Rear Vertical Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Rear Vertical Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

B1D87-00-SEAT BACKREST MOTOR CONTROL - CIRCUIT PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The seat motor is activated.

The MSMD does not detect seat motor activation. The DTC will only set when the seat switch is moved in the same direction three consecutive times.

Scheme 132

Scheme 133

Scheme 134

Scheme 135

1. CHECK FOR RELATED DIAGNOSTIC TROUBLE CODES Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display any seat position sensor DTCs? Yes Diagnose and repair the other DTC(s) first. Refer to «DIAGNOSIS AND TESTING»(ref-465956-S42505359132012042300000) . No Go To 2 .
2. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Move the Seat Switch in the recline position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D87-00-SEAT BACKREST MOTOR CONTROL - CIRCUIT PERFORMANCE? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECKING THE (G403) DRIVER SEAT RECLINER POSITION SENSE CIRCUIT Disconnect the Driver Recliner Seat Adjuster Motor harness connector. Measure the voltage between the (G403) Driver Seat Recliner Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 4 . No Go To 11 .
4. CHECKING THE (G493) DRIVER SEAT RECLINER POSITION SENSOR GROUND CIRCUIT Measure the voltage between the (G403) Driver Seat Recliner Position Sense circuit and the (G493) Driver Seat Recliner Position Sensor Ground circuit. Is the voltage above 11 volts? Yes Go To 5 . No Go To 12 .
5. CHECKING THE (P141) DRIVER SEAT RECLINER UP DRIVER CIRCUIT Measure the voltage between the (P141) Driver Seat Recliner Up Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 13 . No Go To 6 .
6. CHECKING THE (P143) DRIVER SEAT RECLINER DOWN DRIVER CIRCUIT Measure the voltage between the (P143) Driver Seat Recliner Down Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 14 . No Go To 7 .
7. CHECKING THE (P141) DRIVER SEAT RECLINER UP DRIVER CIRCUIT Connect a 12-volt test light between the (P141) Driver Seat Recliner Up Driver circuit and ground. While observing the test light, move the Driver Seat Recliner Switch in the up position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 8 . No Go To 15 .
8. CHECKING THE (P143) DRIVER SEAT RECLINER DOWN DRIVER CIRCUIT Connect a 12-volt test light between the (P143) Driver Seat Recliner Down Driver circuit and ground. While observing the test light, move the Driver Seat Recliner Switch in the down position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 9 . No Go To 17 .
9. CHECKING THE DRIVER SEAT RECLINER DOWN DRIVER Connect a 12-volt test light between the (P141) Driver Seat Recliner Up Driver circuit and the (P143) Driver Seat Recliner Down Driver circuit. While observing the test light, move the Driver Seat Recliner Switch in the up position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 10 . No Go To 19 .
10. CHECKING THE DRIVER SEAT RECLINER UP DRIVER While observing the test light, move the Driver Seat Recliner Switch in the down position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Replace the Seat Adjuster Recliner Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
11. CHECKING THE (G403) DRIVER SEAT RECLINER POSITION SENSE CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C2 harness connector. Measure the resistance of the (G403) Driver Seat Recliner Position Sense circuit between the Driver Seat Recliner Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (G403) Driver Seat Recliner Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
12. CHECKING THE (G493) DRIVER SEAT RECLINER POSITION SENSOR GROUND CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C2 harness connector. Measure the resistance of the (G493) Driver Seat Recliner Position Sensor Ground circuit between the Driver Seat Recliner Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (G493) Driver Seat Recliner Position Sensor Ground circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
13. CHECKING THE (P141) DRIVER SEAT RECLINER UP DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C2 harness connector. Measure the voltage between the (P141) Driver Seat Recliner Up Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P141) Driver Seat Recliner Up Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
14. CHECKING THE (P143) DRIVER SEAT RECLINER DOWN DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C2 harness connector. Measure the voltage between the (P143) Driver Seat Recliner Down Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P143) Driver Seat Recliner Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
15. CHECKING THE (P141) DRIVER SEAT RECLINER UP DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C2 harness connector. Measure the resistance between ground and the (P141) Driver Seat Recliner Up Driver circuit. Is the resistance below 1K Ohms? Yes Repair the short to ground in the (P141) Driver Seat Recliner Up Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 16 .
16. CHECKING THE (P141) DRIVER SEAT RECLINER UP DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P141) Driver Seat Recliner Up Driver circuit between the Driver Seat Recliner Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (P141) Driver Seat Recliner Up Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
17. CHECKING THE (P143) DRIVER SEAT RECLINER DOWN DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C2 harness connector. Measure the resistance between ground and the (P143) Driver Seat Recliner Down Driver circuit. Is the resistance below 1K Ohms? Yes Repair the short to ground in the (P143) Driver Seat Recliner Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 18 .
18. CHECKING THE (P143) DRIVER SEAT RECLINER DOWN DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P143) Driver Seat Recliner Down Driver circuit between the Driver Seat Recliner Adjuster Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms? Yes Repair the open or excessive resistance in the (P143) Driver Seat Recliner Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 19 .
19. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Recliner Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Recliner Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

Scheme 136

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The telescope motor is activated.

The position sensor input is less than 1.7 volts or more than 14 ms.

Scheme 137

Scheme 138

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Move the Telescope Switch in the forward/rearward position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D8B-11-STEERING COLUMN TELESCOPE POSITION SENSOR-CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
2. CHECKING THE (P152) TELESCOPE STEERING FORWARD/REARWARD POSITION SENSE CIRCUIT Disconnect the Steering Wheel Tilt Motor and Steering Wheel Telescope Motor harness connectors. Measure the voltage between the (P152) Telescope Steering Forward/Rearward Position Sense circuit and ground. Is the voltage above 11 volts? Yes Replace the Steering Column Telescope Motor Assembly in accordance with the Service Information. Refer to «COLUMN , REMOVAL»(ref-465942-S01622085462012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. CHECKING THE (P152) TELESCOPE STEERING FORWARD/REARWARD POSITION SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance between ground and the (P152) Telescope Steering Forward/Rearward Position Sense circuit. Is the resistance below 1K Ohms. Yes Repair the short to ground in the (P152) Telescope Steering Forward/Rearward Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Steering Wheel Telescope Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Steering Wheel Telescope Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.

B1D8B-12-STEERING COLUMN TELESCOPE POSITION SENSOR-CIRCUIT SHORT TO BATTERY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The telescope motor is activated.

The position sensor input is above the maximum value for more than 14 ms.

B1D8F-11-STEERING COLUMN TILT POSITION SENSOR-CIRCUIT SHORT TO GROUND

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The tilt motor is activated.

The position sensor input is less than 1.7 volts or more than 14 ms.

Scheme 139

Scheme 140

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Move the Telescope Switch in the up/down position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D8F-11-STEERING COLUMN TILT POSITION SENSOR-CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
2. CHECKING THE (P151) TILT STEERING UP/DOWN POSITION SENSE CIRCUIT Disconnect the Steering Wheel Tilt Motor and Steering Wheel Telescope Motor harness connectors. Measure the voltage between the (P151) Tilt Steering Up/Down Position Sense circuit and ground. Is the voltage above 11 volts? Yes Replace the Steering Column Tilt Motor Assembly in accordance with the Service Information. Refer to «COLUMN , REMOVAL»(ref-465942-S01622085462012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 3 .
3. CHECKING THE (P151) TILT STEERING UP/DOWN POSITION SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance between ground and the (P151) Tilt Steering Up/Down Position Sense circuit. Is the resistance below 1K Ohms. Yes Repair the short to ground in the (P151) Tilt Steering Up/Down Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Steering Wheel Tilt Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Steering Wheel Tilt Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.

B1D8F-12-STEERING COLUMN TILT POSITION SENSOR-CIRCUIT SHORT TO BATTERY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The tilt motor is activated.

The position sensor input is above the maximum value for more than 14 ms.

B1D93-00-STEERING COLUMN TELESCOPE MOTOR CONTROL CIRCUIT PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The telescope motor is activated.

The MSMD does not detect telescope motor activation.

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

1. CHECK FOR RELATED DIAGNOSTIC TROUBLE CODES Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display any tile/telescope position sensor DTCs? Yes Diagnose and repair the other DTC(s) first. Refer to «DIAGNOSIS AND TESTING»(ref-465956-S42505359132012042300000) . No Go To 2 .
2. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Telescope Switch in the forward/rearward position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D93-00-STEERING COLUMN TELESCOPE MOTOR CONTROL CIRCUIT PERFORMANCE? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
3. CHECKING THE (P152) TELESCOPE STEERING FORWARD/REARWARD POSITION SENSE CIRCUIT Disconnect the Steering Column Telescope Motor harness connector. Measure the voltage between the (P152) Telescope Steering Forward/Rearward Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 4 . No Go To 11 .
4. CHECKING THE (G914) SENSOR GROUND CIRCUIT Measure the voltage between the (P152) Telescope Steering Forward/Rearward Position Sense circuit and the (G914) Sensor Ground circuit. Is the voltage above 11 volts? Yes Go To 5 . No Go To 12 .
5. CHECKING THE (P157) TELESCOPE STEERING MOTOR FORWARD/REARWARD DRIVER CIRCUIT Measure the voltage between the (P157) Telescope Steering Motor Forward/Rearward Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 13 . No Go To 6 .
6. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT Measure the voltage between the (P953) Steering Motor Common circuit and ground. Is the voltage above 1 volt? Yes Go To 14 . No Go To 7 .
7. CHECKING THE (P157) TELESCOPE STEERING MOTOR FORWARD/REARWARD DRIVER CIRCUIT Connect a 12-volt test light between the (P157) Telescope Steering Motor Forward/Rearward Driver circuit and ground. While observing the test light, move the Telescope Switch in the forward position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 8 . No Go To 15 .
8. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT Connect a 12-volt test light between the (P953) Steering Motor Common circuit and ground. While observing the test light, move the Telescope Switch in the rearward position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 9 . No Go To 17 .
9. CHECKING THE TELESCOPE REARWARD DRIVER Connect a 12-volt test light between the (P157) Telescope Steering Motor Forward/Rearward Driver circuit and the (P953) Steering Motor Common circuit. While observing the test light, move the Telescope Switch in the forward position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 10 . No Go To 19 .
10. CHECKING THE TELESCOPE FORWARD DRIVER While observing the test light, move the Telescope Switch in the rearward position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Replace the Steering Column Telescope Motor Assembly in accordance with the Service Information. Refer to «COLUMN , REMOVAL»(ref-465942-S01622085462012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
11. CHECKING THE (P152) TELESCOPE STEERING FORWARD/REARWARD POSITION SENSE CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance of the (P152) Telescope Steering Forward/Rearward Position Sense circuit between the Steering Column Telescope Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (P152) Telescope Steering Forward/Rearward Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
12. CHECKING THE (G914) SENSOR GROUND CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance of the (G914) Sensor Ground circuit between the Steering Column Telescope Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (G914) Sensor Ground circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
13. CHECKING THE (P157) TELESCOPE STEERING MOTOR FORWARD/REARWARD DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C1 harness connector. Measure the voltage between the (P157) Telescope Steering Motor Forward/Rearward Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P157) Telescope Steering Motor Forward/Rearward Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
14. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C1 harness connector. Measure the voltage between the (P953) Steering Motor Common circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P953) Steering Motor Common circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
15. CHECKING THE (P157) TELESCOPE STEERING MOTOR FORWARD/REARWARD DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance between ground and the (P157) Telescope Steering Motor Forward/Rearward Driver circuit. Is the resistance below 1K Ohms. Yes Repair the short to ground in the (P157) Telescope Steering Motor Forward/Rearward Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 16 .
16. CHECKING THE (P157) TELESCOPE STEERING MOTOR FORWARD/REARWARD DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P157) Telescope Steering Motor Forward/Rearward Driver circuit between the Steering Column Telescope Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (P157) Telescope Steering Motor Forward/Rearward Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
17. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance between ground and the (P953) Steering Motor Common circuit. Is the resistance below 1K Ohms. Yes Repair the short to ground in the (P953) Steering Motor Common circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 18 .
18. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P953) Steering Motor Common circuit between the Steering Column Telescope Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (P953) Steering Motor Common circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
19. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Steering Wheel Telescope Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Steering Wheel Telescope Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.

B1D97-00-STEERING COLUMN TILT MOTOR CONTROL CIRCUIT PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The tilt motor is activated.

The MSMD does not detect tilt motor activation.

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

1. CHECK FOR RELATED DIAGNOSTIC TROUBLE CODES Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display any tile/tilt position sensor DTCs? Yes Diagnose and repair the other DTC(s) first. Refer to «DIAGNOSIS AND TESTING»(ref-465956-S42505359132012042300000) . No Go To 2 .
2. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Move the Tilt Switch in the up/down position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D97-00-STEERING COLUMN TILT MOTOR CONTROL CIRCUIT PERFORMANCE? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
3. CHECKING THE (P151) TILT STEERING UP/DOWN POSITION SENSE CIRCUIT Disconnect the Steering Wheel Tilt Motor and Steering Wheel Tilt Motor harness connectors. Measure the voltage between the (P151) Tilt Steering Up/Down Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 4 . No Go To 11 .
4. CHECKING THE (G914) SENSOR GROUND CIRCUIT Measure the voltage between the (P151) Tilt Steering Up/Down Position Sense circuit and the (G914) Sensor Ground circuit. Is the voltage above 11 volts? Yes Go To 5 . No Go To 12 .
5. CHECKING THE (P153) TILT STEERING MOTOR UP/DOWN DRIVER CIRCUIT Measure the voltage between the (P153) Tilt Steering Motor Up/Down Driver circuit and ground. Is the voltage above 1 volt? Yes Go To 13 . No Go To 6 .
6. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT Measure the voltage between the (P953) Steering Motor Common circuit and ground. Is the voltage above 1 volt? Yes Go To 14 . No Go To 7 .
7. CHECKING THE (P153) TILT STEERING MOTOR UP/DOWN DRIVER CIRCUIT Connect a 12-volt test light between the (P153) Tilt Steering Motor Up/Down Driver circuit and ground. While observing the test light, move the Tilt Switch in the up position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 8 . No Go To 15 .
8. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT Connect a 12-volt test light between the (P953) Steering Motor Common circuit and ground. While observing the test light, move the Tilt Switch in the down position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 9 . No Go To 17 .
9. CHECKING THE TILT UP DRIVER Connect a 12-volt test light between the (P153) Tilt Steering Motor Up/Down Driver circuit and the (P953) Steering Motor Common circuit. While observing the test light, move the Tilt Switch in the up position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Go To 10 . No Go To 19 .
10. CHECKING THE TILT DOWN DRIVER While observing the test light, move the Tilt Switch in the down position. NOTE: The test lamp must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test lamp illuminate brightly? Yes Replace the Steering Column Tilt Motor Assembly in accordance with the Service Information. Refer to «COLUMN , REMOVAL»(ref-465942-S01622085462012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
11. CHECKING THE (P151) TILT STEERING UP/DOWN POSITION SENSE CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance of the (P151) Tilt Steering Up/Down Position Sense circuit between the Steering Wheel Tilt Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (P151) Tilt Steering Up/Down Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
12. CHECKING THE (G914) SENSOR GROUND CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance of the (G914) Sensor Ground circuit between the Steering Wheel Tilt Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (G914) Sensor Ground circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
13. CHECKING THE (P153) TILT STEERING MOTOR UP/DOWN DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C1 harness connector. Measure the voltage between the (P153) Tilt Steering Motor Up/Down Driver circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P153) Tilt Steering Motor Up/Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
14. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C1 harness connector. Measure the voltage between the (P953) Steering Motor Common circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (P953) Steering Motor Common circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
15. CHECKING THE (P153) TILT STEERING MOTOR UP/DOWN DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance between ground and the (P153) Tilt Steering Motor Up/Down Driver circuit. Is the resistance below 1K Ohms. Yes Repair the short to ground in the (P153) Tilt Steering Motor Up/Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 16 .
16. CHECKING THE (P153) TILT STEERING MOTOR UP/DOWN DRIVER CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P153) Tilt Steering Motor Up/Down Driver circuit between the Steering Wheel Tilt Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (P153) Tilt Steering Motor Up/Down Driver circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
17. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C1 harness connector. Measure the resistance between ground and the (P953) Steering Motor Common circuit. Is the resistance below 1K Ohms. Yes Repair the short to ground in the (P953) Steering Motor Common circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 18 .
18. CHECKING THE (P953) STEERING MOTOR COMMON CIRCUIT FOR AN OPEN OR EXCESSIVE RESISTANCE Measure the resistance of the (P953) Steering Motor Common circuit between the Steering Wheel Tilt Motor harness connector and the MSMD harness connector. Is the resistance above 10 Ohms. Yes Repair the open or excessive resistance in the (P953) Steering Motor Common circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 19 .
19. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Steering Wheel Tilt Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Steering Wheel Tilt Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.

The seat motor is activated.

Seat becomes de-standardized. The seat horizontal motor is 5% past the expected soft stop position.

Engine running, during seat motor operation.

The Memory Seat Module receives a low charging system voltage message over the CAN B Bus or detects voltage under 9.5 volts on the (A210) Fused B(+) circuit.

Scheme 166

1. CHECK PCM FOR CHARGING SYSTEM DTC With the scan tool, read the PCM DTCs. Are there any Charging System DTCs set in the PCM? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) and perform the Charging System diagnostic procedures. No Go To 2 .
2. VERIFY THE DTC IS ACTIVE With the scan tool, record and erase DTCs. Turn the ignition off. Start the engine and operate the driver power seat. With the scan tool, read the active DTCs. Does the scan tool display DTC B210A-84-SYSTEM VOLTAGE LOW-SIGNAL BELOW ALLOWABLE RANGE? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECK THE VOLTAGE AT THE (A210) FUSED B(+) CIRCUIT Disconnect the Memory Seat Module C1 harness connector. Start the engine and let idle. Measure the voltage between the (A210) Fused B(+) circuit and ground. Compare this value to the voltage measured at the vehicle battery. Is the voltage measured at the Memory Seat Module harness connector the same as measured at the battery? Yes Replace the Memory Seat Module in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Repair the (A210) Fused B(+) circuit as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

B210B-85-SYSTEM VOLTAGE LOW-SIGNAL ABOVE ALLOWABLE RANGE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Engine running, during seat motor operation.

The Memory Seat Module receives a high charging system voltage message over the CAN B Bus or detects voltage over 16.5 volts on the (A210) Fused B(+) circuit.

B210D-21-SYSTEM VOLTAGE LOW-SIGNAL AMPLITUDE LESS THAN MINIMUM

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Engine running, during seat motor operation.

The Memory Seat Module receives a low charging system voltage message over the CAN B Bus or detects voltage under 9.5 volts on the (A210) Fused B(+) circuit.

B210E-22-SYSTEM VOLTAGE LOW-SIGNAL AMPLITUDE GREATER THAN MAXIMUM

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Engine running, during seat motor operation.

The Memory Seat Module receives a high charging system voltage message over the CAN B Bus or detects voltage over 16.5 volts on the (A210) Fused B(+) circuit.

B221C-42-(MSM) MEMORY SEAT MODULE INTERNAL-GENERAL MEMORY FAILURE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on.

The Memory Seat Module (MSM) internal self test has failed.

Continuously.

The Memory Seat Module detects the (D265) CAN IHS BUS (125K) (+) circuit or (D264) CAN IHS BUS (125K) (-) circuit open.

Scheme 167

Scheme 168

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase MSMD DTCs Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active MSMD DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
2. (D265) CAN IHS BUS (125K) (+) CIRCUIT OPEN Turn the ignition off. Disconnect the Memory Seat Module C1 harness connector. Measure the voltage between the (D265) CAN IHS BUS (125K) (+) circuit and ground. Is there any voltage present? Yes Go To 3 . No Repair the (D265) CAN IHS BUS (125K) (+) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
3. (D264) CAN IHS BUS (125K) (-) CIRCUIT OPEN Turn the ignition off. Disconnect the Memory Seat Module C1 harness connector. Measure the voltage between the (D264) CAN IHS BUS (125K) (-) circuit and ground. Is there any voltage present? Yes Inspect the wiring and connectors for damage or shorted circuits. If ok, replace the Memory Seat Module in accordance with the service information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Repair the (D264) CAN IHS BUS (125K) (-) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.

Continuously when the ignition is on.

The battery voltage between 10 volts and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

A short to ground is detected on the CAN Interior Bus (125K) (+) circuit.

Continuously when the ignition is on.

The battery voltage between 10 volts and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

A short to voltage is detected on the CAN Interior Bus (125K) (+) circuit.

Continuously when the ignition is on.

The battery voltage between 10 volts and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

A short to ground is detected on the CAN Interior Bus (125K) (-) circuit.

Continuously when the ignition is on.

The battery voltage between 10 volts and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

A short to voltage on the CAN Interior Bus (125K) (-) circuit.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Integrated Power Module (TIPM) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Instrument Cluster (CCN) for approximately two to five seconds.

Continuously when the ignition is on.

The battery voltage between 10 volts and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Door Module Front Left (DMFL) for approximately two to five seconds.

Continuously when the ignition is on.

The battery voltage between 10 volts and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Door Module Front Right (DMFR) for approximately two to five seconds.
