Memory Seat Module (Msmd) - Electrical Diagnostics: Diagnosis Dodge Durango III

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Scheme 101

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

DIAGNOSTIC TEST

1. TEST FOR AN INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Cycle the Driver Seat Switch in all directions several times. Wait one minute. With the scan tool, read the active DTCs. Does the scan tool display B1D62-2A-POWER SEAT SWITCH STUCK-STUCK? Yes Replace the Driver Seat Switch in accordance with the Service Information. Refer to «SWITCH, SEAT , REMOVAL»(ref-465977-S00547374242012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagram as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST.

Scheme 102

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the horizontal position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D6B-11-SEAT HORIZONTAL POSITION SENSOR - CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
2. CHECKING THE (G401) DRIVER SEAT HORIZONTAL POSITION SENSE CIRCUIT Disconnect the Driver Horizontal Seat Adjuster Motor harness connector. Measure the voltage between the (G401) Driver Seat Horizontal Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 3 . No Replace the Seat Adjuster Horizontal Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECKING THE (G401) DRIVER SEAT HORIZONTAL POSITION SENSE CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C3 harness connector. Measure the voltage between the (G401) Driver Seat Horizontal Position Sense circuit and ground. Is the voltage above 1 volt? Yes Repair the short to voltage in the (G401) Driver Seat Horizontal Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Horizontal Seat Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Horizontal Seat Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the front vertical position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D6F-11-SEAT FRONT VERTICAL POSITION SENSOR - CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
2. CHECKING THE (G404) DRIVER SEAT FRONT VERTICAL POSITION SENSE CIRCUIT Disconnect the Driver Seat Front Vertical Adjuster Motor harness connector. Measure the voltage between the (G404) Driver Seat Front Vertical Position Sense circuit and ground. Is the voltage above 11 volts? Yes Replace the Seat Adjuster Front Vertical Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 3 .
3. CHECKING THE (G404) DRIVER SEAT FRONT VERTICAL POSITION SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance between ground and the (G404) Driver Seat Front Vertical Position Sense circuit. Is the resistance below 1K Ohms? Yes Repair the short to ground in the (G404) Driver Seat Front Vertical Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Front Vertical Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Front Vertical Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the front vertical position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D6F-11-SEAT FRONT VERTICAL POSITION SENSOR - CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
2. CHECKING THE (G404) DRIVER SEAT FRONT VERTICAL POSITION SENSE CIRCUIT Disconnect the Driver Seat Front Vertical Adjuster Motor harness connector. Measure the voltage between the (G404) Driver Seat Front Vertical Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 3 . No Replace the Seat Adjuster Front Vertical Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECKING THE (G404) DRIVER SEAT FRONT VERTICAL POSITION SENSE CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C3 harness connector. Measure the voltage between the (G404) Driver Seat Front Vertical Position Sense circuit and ground. Is the voltage above 11 volts? Yes Repair the short to voltage in the (G404) Driver Seat Front Vertical Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Front Vertical Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Front Vertical Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the rear vertical position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D73-11-SEAT REAR VERTICAL POSITION SENSOR - CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
2. CHECKING THE (G402) DRIVER SEAT REAR VERTICAL POSITION SENSE CIRCUIT Disconnect the Driver Seat Rear Vertical Adjuster Motor harness connector. Measure the voltage between the (G402) Driver Seat Rear Vertical Position Sense circuit and ground. Is the voltage above 11 volts? Yes Replace the Seat Adjuster Rear Vertical Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 3 .
3. CHECKING THE (G402) DRIVER SEAT REAR VERTICAL POSITION SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C3 harness connector. Measure the resistance between ground and the (G402) Driver Seat Rear Vertical Position Sense circuit. Is the resistance below 1K Ohms. Yes Repair the short to ground in the (G402) Driver Seat Rear Vertical Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Rear Vertical Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Rear Vertical Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the rear vertical position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D73-11-SEAT REAR VERTICAL POSITION SENSOR - CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
2. CHECKING THE (G402) DRIVER SEAT REAR VERTICAL POSITION SENSE CIRCUIT Disconnect the Driver Seat Rear Vertical Adjuster Motor harness connector. Measure the voltage between the (G402) Driver Seat Rear Vertical Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 3 . No Replace the Seat Adjuster Rear Vertical Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECKING THE (G402) DRIVER SEAT REAR VERTICAL POSITION SENSE CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C3 harness connector. Measure the voltage between the (G402) Driver Seat Rear Vertical Position Sense circuit and ground. Is the voltage above 11 volts? Yes Repair the short to voltage in the (G402) Driver Seat Rear Vertical Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Rear Vertical Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Rear Vertical Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the recliner position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D77-11-SEAT RECLINER POSITION SENSOR - CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
2. CHECKING THE (G403) DRIVER SEAT RECLINER POSITION SENSE CIRCUIT Disconnect the Driver Seat Recliner Adjuster Motor harness connector. Measure the voltage between the (G403) Driver Seat Recliner Position Sense circuit and ground. Is the voltage above 11 volts? Yes Replace the Seat Adjuster Recliner Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 3 .
3. CHECKING THE (G403) DRIVER SEAT RECLINER POSITION SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the MSMD C2 harness connector. Measure the resistance between ground and the (G403) Driver Seat Recliner Position Sense circuit. Is the resistance below 1K Ohms. Yes Repair the short to ground in the (G403) Driver Seat Recliner Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Recliner Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Recliner Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the Seat Switch in the recliner position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D77-12-SEAT RECLINER POSITION SENSOR - CIRCUIT SHORT TO BATTERY? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
2. CHECKING THE (G403) DRIVER SEAT RECLINER POSITION SENSE CIRCUIT Disconnect the Driver Seat Recliner Adjuster Motor harness connector. Measure the voltage between the (G403) Driver Seat Recliner Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 3 . No Replace the Seat Adjuster Recliner Motor Assembly in accordance with the Service Information. Refer to «MOTOR, SEAT ADJUSTER , REMOVAL»(ref-465977-S38416982162012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECKING THE (G403) DRIVER SEAT RECLINER POSITION SENSE CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C4 harness connector. Measure the voltage between the (G403) Driver Seat Recliner Position Sense circuit and ground. Is the voltage above 11 volts? Yes Repair the short to voltage in the (G403) Driver Seat Recliner Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Driver Seat Recliner Adjuster Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Driver Seat Recliner Adjuster Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Move the Telescope Switch in the forward/rearward position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D8B-11-STEERING COLUMN TELESCOPE POSITION SENSOR-CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
2. CHECKING THE (P152) TELESCOPE STEERING FORWARD/REARWARD POSITION SENSE CIRCUIT Disconnect the Steering Wheel Tilt Motor and Steering Wheel Telescope Motor harness connectors. Measure the voltage between the (P152) Telescope Steering Forward/Rearward Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 3 . No Replace the Steering Column Telescope Motor Assembly in accordance with the Service Information. Refer to «COLUMN , REMOVAL»(ref-465942-S01622085462012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
3. CHECKING THE (P152) TELESCOPE STEERING FORWARD/REARWARD POSITION SENSE CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C1 harness connector. Measure the voltage between the (P152) Telescope Steering Forward/Rearward Position Sense circuit and ground. Is the voltage above 11 volts? Yes Repair the short to voltage in the (P152) Telescope Steering Forward/Rearward Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Steering Wheel Telescope Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Steering Wheel Telescope Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Move the Tilt Switch in the up/down position three times. With the scan tool, read the active DTCs. Does the scan tool display B1D8F-11-STEERING COLUMN TILT POSITION SENSOR-CIRCUIT SHORT TO GROUND? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
2. CHECKING THE (P151) TILT STEERING UP/DOWN POSITION SENSE CIRCUIT Disconnect the Steering Wheel Tilt Motor and Steering Wheel Tilt Motor harness connectors. Measure the voltage between the (P151) Tilt Steering Up/Down Position Sense circuit and ground. Is the voltage above 11 volts? Yes Go To 3 . No Replace the Steering Column Tilt Motor Assembly in accordance with the Service Information. Refer to «COLUMN , REMOVAL»(ref-465942-S01622085462012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.
3. CHECKING THE (P151) TILT STEERING UP/DOWN POSITION SENSE CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the MSMD C1 harness connector. Measure the voltage between the (P151) Tilt Steering Up/Down Position Sense circuit and ground. Is the voltage above 11 volts? Yes Repair the short to voltage in the (P151) Tilt Steering Up/Down Position Sense circuit. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
4. MEMORY SEAT MODULE (MSMD) Using the wiring diagram/schematic as a guide, inspect the wiring and harness connectors between the Steering Wheel Tilt Motor and the MSMD. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Steering Wheel Tilt Motor and MSMD harness connectors. Perform any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST. No Replace the MSMD in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR RELATED DTCS Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display any seat position sensor or circuit performance DTCs? Yes Diagnose and repair the other DTCs first. Refer to «DIAGNOSIS AND TESTING»(ref-465956-S42505359132012042300000) . No Go To 2 .
2. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Move the seat in the full forward horizontal position. With the scan tool, read the active DTCs. Does the scan tool display B1D9B-54-SEAT HORIZONTAL FRONT STOP NOT LEARNED-MISSING CALIBRATION? Yes With the scan tool, perform the MSMD Standardization Routine. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST.

Scheme 103

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. CHECK PCM FOR CHARGING SYSTEM DTC With the scan tool, read the PCM DTCs. Are there any Charging System DTCs set in the PCM? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) and perform the Charging System diagnostic procedures. No Go To 2 .
2. VERIFY THE DTC IS ACTIVE With the scan tool, record and erase DTCs. Turn the ignition off. Start the engine and operate the driver power seat. With the scan tool, read the active DTCs. Does the scan tool display DTC B210B-85-SYSTEM VOLTAGE LOW-SIGNAL ABOVE ALLOWABLE RANGE? Yes Replace the Memory Seat Module in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. CHECK PCM FOR CHARGING SYSTEM DTC With the scan tool, read the PCM DTCs. Are there any Charging System DTCs set in the PCM? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) and perform the Charging System diagnostic procedures. No Go To 2 .
2. VERIFY THE DTC IS ACTIVE With the scan tool, record and erase DTCs. Turn the ignition off. Start the engine and operate the driver power seat. With the scan tool, read the active DTCs. Does the scan tool display B210D-21-SYSTEM VOLTAGE LOW-SIGNAL AMPLITUDE LESS THAN MINIMUM? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.
3. CHECK THE VOLTAGE AT THE (A210) FUSED B(+) CIRCUIT Disconnect the Memory Seat Module harness connector. Start the engine and let idle. Measure the voltage between the (A210) Fused B(+) circuit and ground. Compare this value to the voltage measured at the vehicle battery. Is the voltage measured at the Memory Seat Module harness connector the same as measured at the battery? Yes Replace the Memory Seat Module in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Repair the (A210) Fused B(+) circuit as necessary. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. CHECK PCM FOR CHARGING SYSTEM DTC With the scan tool, read the PCM DTCs. Are there any Charging System DTCs set in the PCM? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) and perform the Charging System diagnostic procedures. No Go To 2 .
2. VERIFY THE DTC IS ACTIVE With the scan tool, record and erase DTCs. Turn the ignition off. Start the engine and operate the driver power seat. With the scan tool, read the active DTCs. Does the scan tool display DTC B210E-22-SYSTEM VOLTAGE LOW-SIGNAL AMPLITUDE GREATER THAN MAXIMUM? Yes Replace the Memory Seat Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform the POWER SEAT SYSTEM VERIFICATION TEST.

1. VERIFY THE IS ACTIVE With the scan tool, record and erase DTCs Turn the ignition off. Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display DTC B221C-42-(MSM) MEMORY SEAT MODULE INTERNAL-GENERAL MEMORY FAILURE? Yes Replace the Memory Seat Module in accordance with the Service Information. Refer to «MODULE, MEMORY, SEAT , REMOVAL»(ref-465939-S05664184682012042300000) . Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) and perform POWER SEAT SYSTEM VERIFICATION TEST.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-466035-S30208619332012042300000) and perform the diagnostic test procedure for DTC U0010-CAN INTERIOR BUS. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-466035-S30208619332012042300000) and perform the diagnostic test procedure for DTC U0010-CAN INTERIOR BUS. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-466035-S30208619332012042300000) and perform the diagnostic test procedure for DTC U0010-CAN INTERIOR BUS. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-466035-S30208619332012042300000) and perform the diagnostic test procedure for DTC U0010-CAN INTERIOR BUS. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is the DTC active at this time? Yes Refer to «DIAGNOSIS AND TESTING»(ref-466035-S30208619332012042300000) and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-466035-S30208619332012042300000) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-466035-S30208619332012042300000) and perform the U0203-Lost Communication with Door Module Front Left diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-466035-S30208619332012042300000) and perform the U0204-Lost Communication with Door Module Front Right diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. Perform Power Seat System Verification Test Disconnect all jumper wires and reconnect all previously disconnected components and connectors. Make sure that all accessories are turned off. Make sure that the battery is fully charged. Turn the ignition on. If either the Memory Seat Module or the Driver Horizontal Seat Adjuster Motor/Seat Track was replaced, the MSM Standardization Routine must be performed using the scan tool. With the scan tool, record and erase DTCs from all modules. Operate the driver seat in all positions. With the Memory Switch on the Driver's Door, program the Driver's Seat No. 1 Button to a desired position and Driver No. 2 Button to a different position. Verify that both Memory positions can be recalled from the RKE transmitter and the Memory Switch on the Driver's Door. Turn the ignition off, wait 10 seconds, and then turn the ignition on. With the scan tool, select ECU View. Check for DTCs in the modules. Are DTCs present in any of the modules or is the original condition still present? Yes The repair is not complete. Refer to the related DTC list for the DTC that is still present. No The repair is complete.
