INSPECTION
The fluid fill/check locations and lubrication points are located in each applicable group.
Scheme 1
The totally integrated power module (TIPM) is located in the engine compartment. This center contains cartridge fuses and mini fuses. A description of each fuse and component may be stamped on the inside cover, otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
| Cavity | Cartridge Fuse | Mini Fuse | Description |
|---|---|---|---|
| J01 | 40 Amp Green | Air Suspension | |
| J02 | 30 Amp Pink | Power Liftgate Module | |
| J03 | 30 Amp Pink | Trailer Tow | |
| J04 | 25 Amp Natural | Driver Door Node | |
| J05 | 25 Amp Natural | Passenger Door Node | |
| J06 | 40 Amp Green | Antilock Brakes Pump/Stability Control System | |
| J07 | 30 Amp Pink | Antilock Brakes Valve/Stability Control System | |
| J08 | 40 Amp Green | Power Seat | |
| J09 | 30 Amp Pink | E-Brake | |
| J10 | 30 Amp Pink | Headlamp Wash Relay Contact | |
| J11 | 30 Amp Pink | Drive Train Control Module | |
| J13 | 60 Amp Yellow | Streaming Video Module/ Video System 3 Module/Video System 2 Module/DISP/DVD | |
| J14 | 20 Amp Blue | Trailer Tow Lamps/Park Lamps | |
| J15 | 30 Amp Pink | Rear Window Defroster | |
| J17 | 40 Amp Green | Starter Motor Solenoid | |
| J18 | 20 Amp Blue | Powertrain Control Module/Powertrain Control Module Transmission Range | |
| J19 | 60 Amp Yellow | Radiator Fan Motor HI/Radiator Fan Motor Low | |
| J20 | 30 Amp Pink | Front Wiper Ground | |
| J21 | 20 Amp Blue | Front Washer Control/Rear Washer Control | |
| J22 | 25 Amp Natural | PWR Batt - Sunroof Module | |
| M1 | 15 Amp Blue | Sw Stop Switch Lamp | |
| M2 | 20 Amp Yellow | Electronic Limit Slip Differential/Air Suspension | |
| M3 | 20 Amp Yellow | Liftgate Unlock/DRL Relay | |
| M5 | 25 Amp Natural | 115V AC Power Inverter | |
| M6 | 20 Amp Yellow | Power Outlet #1 (Cigar Lighter)/Rain Snsr | |
| M7 | 20 Amp Yellow | Power Outlet #2 (Switchable) | |
| M8 | 20 Amp Yellow | Front Heated Seat & Steering Wheel | |
| M9 | 20 Amp Yellow | Rear Heated Seats | |
| M10 | 20 Amp Yellow | Hands Free Module/Vanity Lamp/Universal Garage Door Opener | |
| M11 | 10 Amp Red | Heating, Ventilation & Air Conditioning (Climate Control System) | |
| M12 | 30 Amp Green | Radio/Amplifier | |
| M13 | 20 Amp Yellow | Main #2 Instrument Cluster/Wireless Control Module/ITM/Siren/Multifunction Switch (Steering Control Module) | |
| M14 | 20 Amp Yellow | Back Up Camera | |
| M15 | 20 Amp Yellow | Power Seat Module(s)/Adaptive Cruise Control/Audio Telematics/Daytime Running Lights Relay/Air Suspension Module/Instrument Cluster | |
| M16 | 10 Amp Red | Occupant Restraint Controller | |
| M19 | 25 Amp Natural | Automatic Shutdown 1 and 2 | |
| M20 | 15 Amp Blue | Instrument Cluster Interior Lighting Feed/Sw Steering Wheel/ Sw Bank/Steering Control Module (Temperature/Compass Display) | |
| M21 | 20 Amp Yellow | Automatic Shutdown 3 | |
| M22 | 10 Amp Red | Horns (Low/High) - Right | |
| M23 | 10 Amp Red | Horns (Low/High) - Left | |
| M24 | 25 Amp Natural | Rear Wiper On | |
| M25 | 20 Amp Yellow | Fuel Pump Motor Output/Diesel Lift Pump (Export Only) | |
| M26 | Spare | ||
| M27 | 10 Amp Red | Ignition Switch/Wireless Control Module/Keyless Entry Module | |
| M28 | 15 Amp Blue | Powertrain Controller/Transmission Controller | |
| M29 | 10 Amp Red | Tire Pressure Monitor | |
| M30 | 15 Amp Blue | J1962 Diag Connector | |
| M32 | 10 Amp Red | Occupant Restraint Controller | |
| M33 | 10 Amp Red | Powertrain Controller/Transmission Controller | |
| M34 | 10 Amp Red | Park Assist Module/Climate Control System Module/IR Sensor/Compass Module | |
| M35 | 15 Amp Blue | LH Rear Parklamps | |
| M36 | 20 Amp Yellow | Power Outlet | |
| M37 | 10 Amp Red | Antilock Brakes/Stability Control System Module/Stoplamp Switch Sensor | |
| M38 | 25 Amp Natural | All Door Lock &Unlock | |
| Relays | |||
| Cavity | Description | ||
| K1 | Run/Accessory | ||
| K2 | Run | ||
| K3 | Starter Solenoid | ||
| K4 | Run/Start | ||
| K5 | Powertrain Control Module (PCM) | ||
| K6 | Trailer Tow Lamps/Park Lamps | ||
| K7 | Not Used | ||
| K8 | Not Used | ||
| K9 | Electrical Back Light (EBL) | ||
| K10 | Automatic Shut Down (ASD) | ||
| K11 | Radiator Fan Low | ||
Scheme 2
| 1 - FLOOR JACK, VEHICLE EMERGENCY JACK |
|---|
| 1 - CHASSIS LIFT (DUAL POST) |
| 1 - OUTBOARD LIFT (DUAL LIFT) |
| 2 - DRIVE ON HOIST |
Refer to Owner's Manual provided with vehicle for proper emergency jacking procedures.
| WARNING | The hoisting and jack lifting points provided are for a complete vehicle. When the engine or rear suspension is removed from a vehicle, the center of gravity is altered making some hoisting conditions unstable. Properly support or secure vehicle to hoisting device when these conditions exist. Failure to follow these instructions may result in personal injury or death. |
| WARNING | Support the vehicle by supplemental means before performing any work on the air suspension system to prevent the vehicle from changing height. Before any given component is to be serviced it must be deflated. Servicing the air suspension system without supplemental support, or with pressure in the specific component, can cause personal injury or death. |
Note. The air suspension system will auto-disable when lifted on a frame hoist, or when jacking one corner of the vehicle. The air suspension may attempt to change height slightly prior to switching to auto-disable. A manual disable is also available by pressing the "Up" and "Down" switches of the terrain select switch simultaneously for more that 5 seconds. The air suspension system will return to normal operation when the vehicle speed reaches 25 kph (15 mph).
When properly positioned, a floor jack can be used to lift the vehicle and support the raised vehicle with jack stands.
A floor jack or any lifting device, must never be used on any part of the underbody other then the described areas.
| CAUTION | Do not attempt to lift a vehicle with a floor jack positioned under: Aluminum differential. A body side sill. A steering linkage component. A drive shaft. The engine or transmission oil pan. The fuel tank. |
The following steps outline the dealer inspection procedure required every 5 years for vehicles covered under the terms of the Lifetime Powertrain Warranty. Refer to the appropriate warranty information for additional terms and coverages applicable to the Lifetime Powertrain Warranty.
- Lift the vehicle on a suitable hoist.
- Check all Powertrain components for leaks or physical damage. Note any concerns.
- Lower the vehicle and check the level and condition of the engine oil.
- Connect a diagnostic scan tool and check for any Diagnostic Trouble Codes (DTC).
