SPECIAL TOOLS
C-4755 - Trim Stick (Originally Shipped In Kit Number(s) 9299, 9299CC, 9299CC, 9300A-CAN.)
Scheme 1
| CALL OUT | DESCRIPTION | QUANTITY |
|---|---|---|
| 1 | RHR Radio (AM/FM/CD/DVD/HDD/MP3/NAV) | 1 |
| 2 | RHR Owner Manual DVD | 1 |
| TOOLS REQUIRED | |||
|---|---|---|---|
| Phillips Head Screw Driver | Fiber Trim Stick | Scan Tool | T25 Torx Screw Driver |
PROCEDURE STEPS
Scheme 2
Scheme 3
Scheme 4
- Disconnect and isolate the battery negative cable.
- Using a trim stick C-4755 or equivalent, work around the perimeter of the bezel, and across the middle releasing the retaining clips (1) and separate the bezel from the instrument panel.
- Disconnect the electrical connectors (1) and remove the bezel.
- Remove the radio mounting fasteners. CAUTION: Pulling the antenna cable straight out of the radio without pulling on the locking antenna connector could damage the cable or radio.
- Pull the radio out far enough to access the back of the radio.
- Disconnect the AM/FM antenna (2) and electrical connectors (1).
- If equipped, disconnect the navigation antenna (3).
- If equipped, disconnect the USB connectors (4).
- Remove the radio from the instrument panel.
- Position the new radio to the instrument panel.
- Connect the AM/FM antenna (2) and electrical connectors (1).
- Connect the satellite/navigation antenna (3).
- If equipped, connect the USB connectors (4).
- Install the radio mounting fasteners.
- Position the instrument panel center bezel over the instrument panel and connect the electrical connectors (1).
- Press firmly and evenly around the perimeter and across the middle of the bezel to seat the retaining clips (1) and install the center bezel.
- Connect the negative battery cable.
