Body Control Modules: Overview Dodge Durango I

DESCRIPTION

Two versions of Central Timer Module (CTM) are available on Dakota & Durango models, a base-line version and a high-line version. On base-line versions, body controls for lighting, chime indicator, warning buzzer and intermittent wipers are hard wired to base-line CTM. Base-line CTM does not communicate with any other module. If a fault exists, locate and repair switch, wiring, or buzzer as necessary. This article covers base-line models, but mainly applies to high-line models. High-line models are those equipped with optional factory equipment or factory added extra equipment such as Power Door Locks (PDL) and Remote Keyless Entry (RKE), illuminated entry or Vehicle Theft Security System (VTSS) systems. The Central Timer Module (CTM) manages most all body related system electrical functions.

On high-line models, body control module functions are incorporated into the CTM, which may be referred to as a Body Control Module (BCM). CTM communicates with other modules through Chrysler Collision Detection (CCD) bus network. Information related to operation of body systems or features is shared by all modules through CCD bus, and messages are addressed to only be recognized by the module(s) in which the message was intended. This reduces the complexity of vehicle wiring and size of wiring harness. CTM fault messages are accessed through 16-pin Data Link Connector (DLC) using Chrysler's Diagnostic Readout Box (DRBIII(R)) scan tool, or generic scan tool. CTM controls and supports the following features (if equipped)

1. Chime & Warning Indicator System
2. Compass Mini Trip Computer (CMTC)
3. Courtesy Lighting & Illuminated Entry Controls
4. Enhanced Accident Response
5. Mechanical Instrument Cluster (MIC)
6. Power Door Locks & Remote Keyless Entry (RKE)
7. Remote Steering Wheel Switches
8. Speed Sensitive & Intermittent Wipers
9. Vehicle Theft Security System (VTSS)

CONNECTOR IDENTIFICATION

Note. For terminal identification of body control system component harness connectors, use appropriate illustration(s). See CONNECTOR IDENTIFICATION DIRECTORY . Connector terminal numbers may, or may not, be molded into connector faces. However, if connector terminal identification differs from that shown in following illustrations, use wire colors to ensure correct circuit is being tested. See WIRING DIAGRAMS .

CONNECTOR IDENTIFICATION DIRECTORY

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14
