SPECIFICATIONS
| Description | Type | Part Number | Capacities |
|---|
| U.S. | Metric |
| Cooling System |
| (1) Engine Coolant (1.4L Turbo Engine) | MOPAR® Antifreeze/Coolant 10 Year/150, 000 Mile Formula OAT (Organic Additive Technology) meeting the requirements of Chrysler Material Standard MS-12106 | 1 Gallon - 68163848AA (concentrate) 68163849AA (50/50) | 7.2 Quarts | 6.8 Liters |
| (1) Engine Coolant (2.0L and 2.4L Engines) | MOPAR® Antifreeze/Coolant 10 Year/150, 000 Mile Formula OAT (Organic Additive Technology) meeting the requirements of Chrysler Material Standard MS-12106 | 1 Gallon - 68163848AA (concentrate) 68163849AA (50/50) | 7.2 Quarts | 6.8 Liters |
| Engine Oil with Filter |
| Engine Oil (1.4L Turbo Engine) | MOPAR® API Certified SAE 5W-40 synthetic engine oil, meeting the requirements of Chrysler Material Standard MS-10725. | 1 Quart - 05127394PB | 4.0 Quarts | 3.8 Liters |
| (2) Engine Oil (2.0L Engine) | MOPAR® API Certified SAE 0W-20 engine oil, meeting the requirements of Chrysler Material Standard MS-6395. | 1 Quart - 68152004PA | 5.0 Quarts | 4.7 Liters |
| (2) Engine Oil (2.4L Engine) | MOPAR® API Certified SAE 0W-20 engine oil, meeting the requirements of Chrysler Material Standard MS-6395. | 1 Quart - 68152004PA | 5.5 Quarts | 5.2 Liters |
| Engine Oil Filter (1.4L Turbo Engine) | MOPAR® Engine Oil Filter | 68102241AA | N/A | N/A |
| Engine Oil Filter (2.0L and 2.4L Engines) | MOPAR® Engine Oil Filter | 5047769AA | N/A | N/A |
| Fuel (approximate) |
| Fuel Selection (1.4L Turbo Engine) | 91 Octane Unleaded Recommended, 87 Octane or higher Unleaded Acceptable | N/A | 13.2 Gallons | 50 Liters |
| Fuel Selection (2.0L and 2.4L Engines) | 87 Octane Unleaded | N/A | 14.2 Gallons | 54 Liters |
| Fuel Selection (2.4L GT models only) | 87 Octane Unleaded | N/A | 15.8 Gallons | 60 Liters |
| A/C Refrigerant System |
| Refrigerant | R-134a | 82300101AB | 1.25 Pounds | 0.567 Kilograms |
| (1) System fill capacity includes heater and coolant recovery bottle filled to MAX level. (2) If 0W-20 engine oil is not available, SAE 5W-20 API Certified engine oil may be used as a temporary suitable alternative. |
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
| (1) | System fill capacity includes heater and coolant recovery bottle filled to MAX level. |
| (2) | If 0W-20 engine oil is not available, SAE 5W-20 API Certified engine oil may be used as a temporary suitable alternative. |
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
| Description | Part Number | Gap |
|---|
| U.S. | Metric |
| Spark Plugs (1.4L Turbo Engine) | 68070507AB (SIKR9A7) | 0.026 in | 0.65 mm |
| Spark Plugs (2.0L Engine) | SP079888AB (REC10WMPB) | 0.043 in | 1.10 mm |
| Spark Plugs (2.4L Engine) | (REC10WMPB4) | 0.047 in | 1.20 mm |
| Description | Type | Part Number | Capacity |
|---|
| (1) 6F24 Automatic Transaxle | MOPAR® SP-IV Automatic Transmission Fluid | Is available on Star Parts | Factory Fill = 7.1L (7.5 qt.). Service Fill = Measured Level in mm |
| (1) For the 6F24 Automatic Transaxle fluid level inspection. Refer to FLUID, STANDARD PROCEDURES . |
| (1) | For the 6F24 Automatic Transaxle fluid level inspection. Refer to FLUID, STANDARD PROCEDURES . |
| Description | Type | Part Number | Capacity |
|---|
| (1) C635 DDCT Automatic Transaxle | MOPAR® C635 DDCT/MTX Transmission Fluid | Is available on Star Parts | 1.66 L (1.75 qt) |
| (1) For the C635 fluid level inspection. Refer to FLUID, STANDARD PROCEDURE . |
| (1) | For the C635 fluid level inspection. Refer to FLUID, STANDARD PROCEDURE . |
C635 DDCT AUTOMATIC TRANSAXLE
| Description | Type | Part Number | Capacity |
|---|
| (1) C635 Manual Transaxle | MOPAR® C635 DDCT/MTX Transmission Fluid | Is available on Star Parts | 1.7 Liter (1.8 Quarts) |
| (1) For the C635 fluid level inspection. Refer to FLUID, STANDARD PROCEDURE . |
| (1) | For the C635 fluid level inspection. Refer to FLUID, STANDARD PROCEDURE . |
| Description | Type | Part Number | Capacities |
|---|
| U.S. | Metric |
| Chassis Systems | |
| (1) Brake Master Cylinder | MOPAR® Brake Fluid DOT 3, SAE J1703. | 12 oz. Bottle - 04318080AB | N/A | N/A |
| 32 oz. Bottle - 04318081AB |
| (1) Brake/Clutch Master Cylinder |
| (1) If MOPAR® Brake Fluid DOT 3 is not available, then MOPAR® Brake and Clutch Fluid DOT 4 is acceptable. |
| (1) | If MOPAR® Brake Fluid DOT 3 is not available, then MOPAR® Brake and Clutch Fluid DOT 4 is acceptable. |
Scheme 1
The interior fuse panel is part of the Body Control Module (BCM) and is located on the driver's side under the instrument panel.
| CAVITY | MAXI FUSE | MINI FUSE | DESCRIPTION |
|---|
| F12 | | | Spare |
| F13 | | 15 Amp Blue | Left Headlamp |
| F31 | | | Spare |
| F32 | | 10 Amp Red | Interior Lighting/Decklid/Liftgate Release |
| F33 | | 25 Amp Natural | Window Motor - Driver |
| F34 | | 25 Amp Natural | Window Motor - Passenger |
| F36 | | 15 Amp Blue | Intrusion Module |
| F37 | | 10 Amp Red | Instrument Panel Cluster |
| F38 | | 20 Amp Yellow | Door Locks |
| F42 | | | Spare |
| F43 | | 20 Amp Yellow | Windshield Washer Pump |
| F47 | | 5 Amp Tan | Transmission Control Module (TCM) |
| F48 | | 20 Amp Yellow | Spare |
| F49 | | 7.5 Amp Brown | Stop Lamp Switch |
| F50 | | 7.5 Amp Brown | Pneumatic Lumbar Support |
| F51 | | 7.5 Amp Brown | CD/Hands-Free Module - Bluetooth/ Radio Display |
| F53 | | 7.5 Amp Brown | Driver Window Switch/Power Mirrors |
| F89 | | 5 Amp Tan | Trunk Lamp |
| F90 | | 7.5 Amp Brown | Front Fog Lamps - Right |
| F91 | | 7.5 Amp Brown | Front Fog Lamps - Left |
| F92 | | 7.5 Amp Brown | High Beams (Shutters) |
| F93 | | 15 Amp Blue | Right Headlamp |
Scheme 2
An interior power distribution center located driver side under the dash to the side of the steering column opening. This fuse block contains MINI fuses.
| CAVITY | MAXI FUSE | MINI FUSE | DESCRIPTION |
|---|
| F1 | | 20 Amp Yellow | Front Heated Seats - If Equipped |
| F2 | | 20 Amp Yellow | Rear Heated Seats, Heated Steering Wheel - If Equipped |
| F3 | | 10 Amp Red | Park Assist Module, Rear Camera, Left and Right Blind Spot Sensor, Compass - If Equipped |
| F4 | | 15 Amp Blue | Instrument Cluster |
| F5 | | 10 Amp Red | HVAC, Humidity Sensor, In-Car Temperature Sensor, Inside Mirror Assembly |
| F18 | | 15 Amp Blue | Radio |
| F19 | | 10 Amp Red | Fuel Door |
| F20 | | 10 Amp Red | Steering Column Control Module, Switch Bank |
| F21 | | 10 Amp Red | Diagnostic Port |
| F22 | | 10 Amp Red | Universal Garage Door Opener, EOM |
| F23 | | 20 Amp Yellow | Sunroof |
| F24 | | 5 Amp Tan | Run/Accessory Relay |
| F25 | | 5 Amp Tan | Transmission Control Module #4 |
| F26 | | 5 Amp Tan | Stop Lamp Switch |
| F27 | | 10 Amp Red | Pneumatic Lumbar Support |
Scheme 3
Scheme 3: UNDERHOOD FUSES
| F1 - MOD_EPS - 70 Amp MIDI Fuse |
|---|
| F2 - RADIATOR FAN - 60 Amp MIDI Fuse |
| F3 - ALTERNATOR - 200 Amp Mega Fuse |
A Pre Fuse Block is located in the engine compartment on top of the battery. This fuse block contains MIDI and Mega fuses.
Scheme 4
A primary power distribution center is located on the left side of the engine compartment, neat the battery. To access the fuses, remove the two screws, press the release tabs and remove the cover.
The ID number of the electrical component corresponding to each fuse can be found on the back of the cover.
| CAVITY | MAXI FUSE | MINI FUSE | DESCRIPTION |
|---|
| F01 | 70 Amp Tan | | Body Control Module #1 |
| F02 | 60 Amp Blue | | Body Control Module #2 |
| F03 | 30 Amp Green | | Output For Starter Relay #1 |
| F04 | 40 Amp Orange | | ESC Pump Motor |
| F05 | 40 Amp Orange | | Transmission Control Module #1 |
| F06 | 30 Amp Green | | Body Control Module #3 |
| F07 | 40 Amp Orange | | EBL RLY Coil, Blower Motor RLY Coil |
| F09 | | 5 Amp Tan | Radiator Fan |
| F10 | | 10 Amp Red | ORC |
| F11 | | 20 Amp Yellow | Run/Start, Engine Control Module |
| F14 | | 15 Amp Blue | Transmission Control Module #2 |
| F15 | | 15 Amp Blue | Transmission Control Module #3 |
| F16 | | 15 Amp Blue | Engine Control Module, Ignition Coils |
| F17 | | 15 Amp Blue | Brake System Module |
| F18 | | 20 Amp Yellow | Engine Control Module |
| F19 | | 10 Amp Red | A/C Compressor Clutch |
| F20 | | 30 Amp Green | Rear Defroster (EBL) |
| F21 | | 20 Amp Yellow | Fuel Pump |
| F22 | | 10 Amp Red | Occupant Restraint Controller |
| F23 | | 25 Amp White | Brake System Module |
| F24 | | 20 Amp Yellow | Engine Control Module, Fuel Injectors |
| F30 | | 20 Amp Yellow | Power Outlet (Console) |
| F81 | 60 Amp Blue | | Interior PDC Battery Feed, Power Seats |
| F82 | 30 Amp Green | | Amplifier |
| F83 | 40 Amp Orange | | HVAC Blower Motor |
| F84 | | 20 Amp Yellow | Cigar Lighter |
| F85 | | 10 Amp Red | Sunroof, LRSM, Power Outlet (Console), UCI/AUX Port, Cigar Lighter |
| F86 | | 20 Amp Yellow | Spare |
| F87 | | 10 Amp Red | Wastegate, Purge Solenoid, OBD Vent Valve, Oxygen Sensor Heaters |
| F88 | | 10 Amp Red | Heated Outside Mirrors |
| RELAYS |
| CAVITY | DESCRIPTION |
| T02 | Radiator PWM Enable |
| T03 | Automatic Shut Down |
| T05 | A/C Clutch |
| T06 | Not Used |
| T07 | Run |
| T08 | Run/Accessory #1 |
| T09 | Run/Start |
| T10 | Fuel Pump |
| T14 | Body Control Module Starter |
| T17 | Run/Accessory #2 |
| T19 | Electronic Back Light/Heated Mirror |
| T20 | Electronic Control Module/Starter |
| T30 | HVAC Blower Motor |
Scheme 5
Scheme 5: STANDARD PROCEDURE - HOISTING
| 1 - FLOOR JACK |
|---|
| 1 - FRAME CONTACT LIFT (SINGLE POST) |
| 1 - CHASSIS LIFT (DUAL LIFT) |
| 1 - OUTBOARD LIFT (DUAL LIFT) |
| 2 - DRIVE ON HOIST |
Refer to Owner's Manual provided with vehicle for proper emergency jacking procedures.
| WARNING | The hoisting and jack lifting points provided are for a complete vehicle. When the engine or rear suspension is removed from a vehicle, the center of gravity is altered making some hoisting conditions unstable. Properly support or secure vehicle to hoisting device when these conditions exist. Failure to follow these instructions may result in serious or fatal injury. |
| CAUTION | Do not position hoisting device on any suspension component, including the front or rear suspension crossmembers. Do not hoist on the front and rear bumpers, the lower radiator crossmember, or the front engine mount. Do not attempt to raise one entire side of the vehicle by placing a floor jack midway between the front and rear wheels. This practice may result in permanent damage to the body. |
When properly positioned, a floor jack can be used to lift the vehicle and support the raised vehicle with jack stands.
A floor jack or any lifting device must never be used on any part of the underbody other than the described areas.
There are SAE approved triangles in the body indicating where the lifting points are for the vehicle. The arrows are shown in the top figure as callout 1.
