SPECIAL TOOLS

C-4755 - Trim Stick (Originally Shipped In Kit Number(s) 9299, 9299CC, 9299CC, 9300A-CAN.)

Scheme 1

Scheme 1: PROCEDURE STEPS

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11
  1. Remove the spare tire cover.
  2. Disconnect the negative battery cable. (2)
  3. Remove the Power Distribution Center (PDC) by pressing the releasing tabs (1) and pulling the PDC straight up.
  4. Remove the back cover of the PDC (2).
  5. Locate the F981 (RD/BR) circuit (1) going to fuse 18. Refer to the wire schematic.
  6. Measure the appropriate length of wire so that the wire harness will reach the router from the PDC. 1 - SPLICE BAND
  7. Remove one-half (1/2) inch of insulation from each wire that needs to be spliced.
  8. Place a piece of adhesive lined heat shrink tubing on one side of the wire. Make sure the tubing will be long enough to cover and seal the entire repair area.
  9. Place the strands of wire overlapping each other inside of the splice clip (1). 1 - CRIMPING TOOL
  10. Using crimping tool (1), Mopar p/n 05019912AA, crimp the splice clip and wires together. 1 - SOLDER 2 - SPLICE BAND 3 - SOLDERING IRON
  11. Solder (3) the connection (2) together using rosin core type solder (1) only. CAUTION: Do not use acid core solder. 1 - SEALANT 2 - HEAT SHRINK TUBE
  12. Center the heat shrink tubing (2) over the joint and heat using a heat gun. Heat the joint until the tubing is tightly sealed and sealant (1) comes out of both ends of the tubing.
  13. Attach the black wire to the negative battery terminal stud.
  14. Install the PDC back cover, being careful not to pinch any wires between the PDC and the PDC cover.
  15. Install the PDC.
  16. Connect the negative battery cable.
  17. Install the spare tire cover.
  18. Secure the Wi-Fi Router (1) with the supplied fasteners on the back of the passenger rear seat (2). Measure 230 mm (9.1 in.) from the bottom of the seat back (3) to the top of the Wi-Fi Router.
  19. The Wi-Fi Router (3) should be 50 mm (2 in.) from the left edge (1) of the seat back (2).
  20. Route and secure the twisted pair wire harness from the PDC to the Wi-Fi Router along the passenger side trunk.
  21. Connect the twisted pair wire harness to the router.
  22. Verify system operation.
