Driver Door Module (Ddm) - Electrical Diagnostics: Diagnosis Dodge Challenger III рестайлинг

Communication Devices 2 illustrations ~1438 words

DIAGNOSTIC CODE INDEX

DTCDescription
B1852DRIVER WINDOW SWITCH STUCK
B1854DRIVER WINDOW CONTROL CIRCUIT LOW
B1858DRIVER WINDOW POSITION SENSOR POWER SUPPLY LOW
B185ADRIVER WINDOW POSITION SENSOR CIRCUIT PERFORMANCE
B1868DRIVER PASSENGER WINDOW SWITCH CIRCUIT STUCK
B18D5DRIVER DOOR PAWL SWITCH STUCK
B190EDRIVER WINDOW SWITCH CIRCUIT LOW
B190FDRIVER WINDOW SWITCH CIRCUIT HIGH
B1914DRIVER WINDOW CONTROL 2 CIRCUIT LOW
B1DA7SWITCH POWER SUPPLY CIRCUIT LOW
B210DBATTERY VOLTAGE LOW
B210EBATTERY VOLTAGE HIGH
B2218DOOR MODULE INTERNAL
U0141LOST COMMUNICATION WITH IPM (FCM/TIPM)
U0151LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER (ORC)
U0155LOST COMMUNICATION WITH CLUSTER/CCN
U0156LOST COMMUNICATION WITH EOM
U0159LOST COMMUNICATION WITH PARKING ASSIST CONTROL MODULE
U0164LOST COMMUNICATION WITH HVAC CONTROL MODULE
U0168LOST COMMUNICATION WITH VEHICLE SECURITY CONTROL MODULE (WIN)
U0169LOST COMMUNICATION WITH SUNROOF CONTROL MODULE
U0184LOST COMMUNICATION WITH RADIO
U0186LOST COMMUNICATION WITH AUDIO AMPLIFIER
U0195LOST COMMUNICATION WITH SDARS
U0197LOST COMMUNICATION WITH HANDS FREE PHONE MODULE
U0200LOST COMMUNICATION WITH PASSENGER DOOR MODULE
U0208LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE
U0212LOST COMMUNICATION WITH SCM - CAN-B
U1000CAN B BUS (+) CIRCUIT
U1001CAN B BUS (-) CIRCUIT

DIAGNOSTIC CODE INDEX

Scheme 332

Scheme 332: B1852-DRIVER WINDOW SWITCH STUCK
Scheme 332: B1852-DRIVER WINDOW SWITCH STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

DIAGNOSTIC TEST

  1. Replace the Door Module NOTE: Anytime this code is logged, the module must be replaced. Repair Replace the Driver Door Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-489354-S01583902142012072600000) .
  1. CHECK ENGINE DTCs With the scan tool, read ENGINE DTCs Are there any Engine Battery or Charging DTCs present? No Go To 2 . Yes Perform the appropriate diagnostic procedure related to the battery and charging system.
  2. TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase DTCs Start the engine and run for 2 minutes. With the scan tool, read DTCs. Does the scan tool display B210E-BATTERY VOLTAGE HIGH? Yes Replace the Driver Door Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-489354-S01583902142012072600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-489354-S01583902142012072600000) .
  1. VERIFY THAT DTC B2218-DOOR MODULE INTERNAL IS ACTIVE With the scan tool, record and erase DTCs. Cycle the ignition switch off then back on. With the scan tool, read DTCs. Does the DTC B2218 - DOOR MODULE INTERNAL reset? Yes Replace the Driver Door Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-489354-S01583902142012072600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-489354-S01583902142012072600000) .
  1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0141-LOST COMMUNICATION WITH IPM (FCM/TIPM)»(ref-489354-S33505642562012072600000) and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0151-LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER (ORC)»(ref-489354-S12780026062012072600000) and perform the U0151-Lost Communication with Occupant Restraint Controller (ORC) diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0155-LOST COMMUNICATION WITH CLUSTER/CCN»(ref-489354-S42513119582012072600000) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0156-LOST COMMUNICATION WITH EOM (ELECTRONIC OVERHEAD MODULE)»(ref-489354-S42526040262012072600000) and perform the U0156-Lost Communication with EOM diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0159-LOST COMMUNICATION WITH PARKING ASSIST CONTROL MODULE»(ref-489354-S11682586772012072600000) and perform the U0159-Lost Communication with Parking Assist Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0164-LOST COMMUNICATION WITH HVAC CONTROL MODULE»(ref-489354-S31402295372012072600000) and perform the U0164-Lost Communication with HVAC Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0168-LOST COMMUNICATION WITH VEHICLE SECURITY CONTROL MODULE (WIN)»(ref-489354-S18261047282012072600000) and perform the U0168-Lost Communication with Vehicle Security Control Module (WIN) diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0169-LOST COMMUNICATION WITH SUNROOF CONTROL MODULE (SUNR)»(ref-489354-S25551616982012072600000) and perform the U0169-Lost Communication with Sunroof Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0184-LOST COMMUNICATION WITH RADIO»(ref-489354-S40646992672012072600000) and perform the U0184-Lost Communication with Radio diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0186-LOST COMMUNICATION WITH AUDIO AMPLIFIER»(ref-489354-S05550884442012072600000) and perform the U0186-Lost Communication with Audio Amplifier diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0195-LOST COMMUNICATION WITH SDARS»(ref-489364-S01080362782012072600000) and perform the U0195-Lost Communication with SDAR diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0197-LOST COMMUNICATION WITH HANDS FREE PHONE MODULE (HFM)»(ref-489354-S05516118462012072600000) and perform the U0197-Lost Communication with Hands Free Phone Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0200-LOST COMMUNICATION WITH PASSENGER DOOR MODULE»(ref-489364-S14519001382012072600000) and perform the U0200-Lost Communication with Passenger Door Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0208-LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE (HSM)»(ref-489354-S17722643572012072600000) and perform the U0208-Lost Communication with Heated Seat Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0212-LOST COMMUNICATION WITH SCM»(ref-489354-S12016381862012072600000) and perform the U0212-Lost Communication with SCM diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.

Scheme 333

Scheme 333: U1000-CAN B BUS (+) CIRCUIT
Scheme 333: U1000-CAN B BUS (+) CIRCUIT

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
