Emissions Control: Specifications Dodge Challenger III

Emission Applications 4 illustrations ~141 words

TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
EGR Valve to Cylinder Head Bolts - 3.5L3022
EGR Valve to Cylinder Head Bolts - 6.1L2821248
Upper EGR Tube to EGR Valve Bolts - 3.5L1511
Upper EGR Tube to Intake Manifold Bolts - 3.5L653

TORQUE

Scheme 3

Scheme 3: REMOVAL

Scheme 4

Scheme 4

Scheme 5

Scheme 5
  1. Disconnect negative battery cable.
  2. Raise vehicle and support.
  3. Remove the right rear tire.
  4. Remove the inner splash shield.
  5. Disconnect the EVAP line.
  6. Unlock and disconnect electrical connector.
  7. Remove mounting nut.
  8. Slide assembly forward off of rear mounting brackets.
  9. Disconnect vapor lines from EVAP canister.
  10. Squeeze connector and pull.
  11. Make sure that you do not lose the rubber mounts in canister brackets.
  12. Remove mounting nuts from canister.
  13. Remove vapor canister from bracket.

Scheme 6

Scheme 6
  1. Install canister to bracket and tighten nuts.
  2. Connect hoses to vapor canister.
  3. Install rubber isolator in canister brackets.
  4. Slide canister brackets with rubber isolators onto mounting brackets.
  5. Install assembly mounting nut.
  6. Connect electrical connector.
  7. Connect the EVAP line.
  8. Install the inner splash shield.
  9. Install tire.
  10. Lower vehicle.
  11. Connect negative battery cable.
