Power Mirrors: Removal & Installation Dodge Caravan IV

Mirrors 1 illustration ~330 words

INSTALLATION

  1. Install switch to steering column shroud.
  2. Connect wire harness connector.
  3. Install the upper and lower steering column shroud «(Refer to STEERING/COLUMN/LOWER SHROUD - INSTALLATION)»(ref-248900-S28611796402007022700000) .
  4. Connect the battery negative cable.

Scheme 4

Scheme 4: REMOTE SWITCH
  1. Remove power mirror switch. «(Refer to ELECTRICAL/POWER MIRRORS/POWER MIRROR SWITCH - REMOVAL)»(ref-248928-S36936349582007022700000).
  2. Disconnect wiring harness at switch connector.
  3. Using a ohmmeter, test for continuity between the terminals of the switch. (Scheme 4) MIRROR SWITCH TEST - MIRROR SELECT SWITCH IN "LEFT" POSITION Move Button Continuity Between UP PIN 9 - PIN 12, PIN 6 - PIN 11, PIN 9 - PIN 13 LEFT PIN 9 - PIN 7, PIN 6 - PIN 11, PIN 9 - PIN 8 DOWN PIN 9 - PIN 6, PIN 12 - PIN 11, PIN 13 - PIN 11 RIGHT PIN 9 - PIN 6, PIN 7 - PIN 11, PIN 8 - PIN 11 - MIRROR SELECT SWITCH IN "RIGHT" POSITION Move Button Continuity Between UP PIN 9 - PIN 13, PIN 1 - PIN 11, PIN 9 - PIN 12 LEFT PIN 9 - PIN 8, PIN 1 - PIN 11, PIN 9 - PIN 7 DOWN PIN 9 - PIN 1, PIN 13 - PIN 11, PIN 12 - PIN 11 RIGHT PIN 9 - PIN 1, PIN 8 - PIN 11, PIN 7 - PIN 11
  4. If results shown in the table are not obtained, replace the switch.

REMOVAL

  1. Disconnect and isolate the battery negative cable.
  2. Remove instrument panel lower cover.
  3. From behind headlamp switch assembly, depress retaining tabs and push switch from instrument panel.
  4. Disconnect wire connector from power mirror switch.
  5. Disengage lock tabs above and below the mirror switch.
  6. Remove power mirror switch from headlamp switch bezel.
  1. Install power mirror switch to the headlamp switch bezel.
  2. Connect wire connector to the power mirror switch.
  3. Insert headlamp switch assembly into instrument panel.
  4. Install instrument panel lower cover.
  5. Connect battery negative cable.

For service procedures, (Refer to BODY/EXTERIOR/SIDE VIEW MIRROR - REMOVAL) .
