DESCRIPTION
If equipped with power mirrors, the control switch is located on the instrument panel to the left of the headlamp switch.
OPERATION
The power mirrors are connected to battery feed at all times. Each mirror head contains two electric motors, two drive mechanisms, an electric heating element, and the mirror glass. If the vehicle is equipped with the optional memory system, the driver side mirror head also contains both a horizontal and a vertical motor position sensor. One motor and drive controls mirror up-and-down movement, and the other controls right-and-left movement.
An optional driver side outside electrochromic mirror is able to automatically change its reflectance level. This mirror is controlled by the circuitry of the automatic day/night inside rear view mirror. A thin layer of electrochromic material between two pieces of conductive glass make up the face of the mirror. Two photocell sensors on the inside rear view mirror are used to monitor light levels and adjust the reflectance of both the inside and driver side outside mirrors. This change in reflectance helps to reduce the glare of headlamps approaching the vehicle from the rear. (Refer to ELECTRICAL/POWER MIRRORS/AUTOMATIC DAY/NIGHT MIRROR - DESCRIPTION) for more information on this system.
The motors which operate the mirrors are part of the mirror assembly and cannot be serviced separately.
Scheme 1
- Remove Power Mirror Switch. «(Refer to ELECTRICAL/POWER MIRRORS/POWER MIRROR SWITCH - REMOVAL)»(ref-248928-S36936349582007022700000).
- Disconnect wiring harness connector to the power mirror switch and headlamp switch.
- Using two jumper wires: Connect one to a 12-volt source Connect the other to a good body ground Refer to «POWER MIRROR MOTOR TEST»(ref-248928-S32404182692007022700000) table for wire hookups at the switch connector. (Scheme 1) POWER MIRROR MOTOR TEST SWITCH CONNECTOR 12 Volts Ground MIRROR REACTION Right Left PIN 12 PIN 6 - UP PIN 7 PIN 6 - LEFT PIN 6 PIN 12 - DOWN PIN 6 PIN 7 - RIGHT PIN 13 PIN 1 UP - PIN 8 PIN 1 LEFT - PIN 1 PIN 13 DOWN - PIN 1 PIN 8 RIGHT
- If results shown in table are not obtained, check for broken or shorted circuit, or replace mirror assembly as necessary.
An automatic dimming inside day/night rear view mirror and an automatic dimming driver side outside rear view mirror are available factory-installed options on this model. Following is a general description of this optional equipment.
The automatic day/night mirror is able to automatically change its reflectance. A thin layer of electrochromic material between two pieces of conductive glass make up the face of the mirror. Two photocell sensors are used to monitor light levels and adjust the reflectance of the mirror to reduce the glare of headlamps approaching the vehicle from the rear.
For removal procedures, (Refer to BODY/INTERIOR/REAR VIEW MIRROR - REMOVAL) .
The ambient photocell sensor faces forward, to detect the outside light levels. A second sensor faces rearward to detect the light level received through the vehicles back window. When the difference between the two light levels becomes too great (the light level received at the rear of the mirror is much higher than that at the front of the mirror), the mirror begins to darken.
The mirror switch allows the driver a manual control of whether the automatic dimming feature is operational. When AUTO is selected a small Light-Emitting Diode (LED), to the right of the mirror switch, is illuminated. The automatic dimming feature will only operate when the ignition switch is in the On position. The mirror also senses the backup lamp circuit, and will automatically disable its self-dimming feature whenever the transmission gear selector is in the Reverse position.
Note. The mirror always defaults to an ON state upon ignition.
The driver side automatic dimming mirror is standard with the automatic dimming inside mirror. The signal to control the dimming of that mirror is generated by the automatic day/night inside rear view mirror circuitry. That signal is then delivered to the driver side outside rear view mirror on a hard wired circuit.
The automatic day/night mirror cannot be repaired. If faulty or damaged, the entire inside rear view mirror assembly must be replaced.
These vehicles may be equipped with Power Foldaway Mirrors. This feature allows both the driver and passenger side view mirrors to fold inward (retract) on demand. The vehicle has an additional switch located on the steering column that controls the folding function of the mirror assembly. (Scheme 2)
The fold-away side view mirror is attached to the vehicle's door in the same manner as mirrors without the fold-away option. The fold-away mirrors unique option is the internal motor which allows the mirrors to fold inward on demand. The fold-away mirror motor is not serviceable separately and if a motor is found to be faulty the entire side view mirror must be replaced.
Scheme 2
| 1 - POWER FOLDAWAY MIRROR SWITCH |
|---|
| 2 - STEERING COLUMN |
When the mirror retract switch is depressed, both of the side view mirrors will fold inward, Thus making the overall width of the vehicle the smallest possible. This can be helpful were parking space is a absolute minimum.
When the driver's door is opened, only the driver's door mirror will unfold. If the passenger door is opened, both mirrors will unfold.
The power fold away mirror system consists of the following components: mirror switch, side view mirror, relay, wires and fuse. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.
Scheme 3
- Disconnect and isolate the battery negative cable.
- Remove the upper and lower steering column shroud «(Refer to STEERING/COLUMN/LOWER SHROUD - REMOVAL)»(ref-248900-S20031751282007022700000).
- Disconnect electrical harness connector. 1 - STEERING COLUMN SHROUD 2 - POWER FOLDAWAY SWITCH
- Remove switch from steering column shroud. (Scheme 3)
