SPECIFICATIONS - TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|
| Front bumper reinforcement attaching nut | 54 | 40 | |
| Rear bumper reinforcement attaching nut | 27 | 20 | |
SPECIFICATIONS - FRAME DIMENSIONS
Frame dimensions are listed in metric scale. All dimensions are from center to center of Principal Locating Point (PLP), or from center to center of PLP and fastener location.
SPECIFICATIONS - FRAME DIMENSIONS - FOLD-IN-FLOOR SEATS ONLY
SPECIFICATIONS - FRAME DIMENSIONS - FOLD-IN-FLOOR SEATS ONLY
Scheme 1
Scheme 2
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|
| Front Cradle Crossmember to Frame Rail Attaching Bolts (4) | 163 | 120 | |
| Reinforcement Plate to Crossmember Attaching Bolt Size M14 (9) | 153 | 113 | |
| Reinforcement Plate to Crossmember Attaching Bolt Size M12 (1) | 106 | 78 | |
| Reinforcement Plate to Crossmember Attaching Bolt Size M10 (4) | 61 | 45 | |
| Rear Engine Mount to Crossmember Attaching Through Bolt | 68 | 50 | |
| Radiator Support Crossmember Attaching Bolts | 51 | 38 | |
