VEHICLE PREPARATION
Position the vehicle on a frame alignment rack, refer to instructions provided with equipment being used. Adjust the vehicle PLP heights to the specified dimension above the work surface (datum line). Vertical dimensions can be taken from the datum line to the locations indicated were applicable.
| DESCRIPTION | FIGURE |
|---|---|
| CROSSMEMBER DIMENSIONS | (Scheme 18). |
| ENGINE BOX - TOP VIEW | (Scheme 19). |
| ENGINE COMPARTMENT AND FRAME RAIL - SIDE VIEW | (Scheme 20). |
| FULL VEHICLE - BOTTOM VIEW | (Scheme 21). |
INDEX
Scheme 18
Scheme 19
Scheme 20
Scheme 21
TOOL REQUIREMENT FOR M8x1.25 Thread
- 8.3mm (5/16 in.) Drill Bit
- 120° Countersink
- Heli-Coil(R) Tap #4863-8
- Heli-Coil(R) Gage #4624-8
- Heli-Coil(R) Hand Inserting Tool 7751-8
- Needle Nose Pliers - For Removal Of Thread Insert Driving Tang
TOOL REQUIREMENT FOR M10x1.5 Thread
- 10.5mm (25/64 in.) Drill Bit
- 120° Countersink
- Heli-Coil(R) Tap #4863-10
- Heli-Coil(R) Gage #4624-10
- Heli-Coil(R) Hand Inserting Tool 7751-10
- Needle Nose Pliers - For Removal Of Thread Insert Driving Tang
