BATTERY SPECIFICATIONS
| Application & Group | Cold Cranking Amps | Amp Hr. Rating |
|---|
| 3.0L (Group 34) | 500 | 60 |
FLUID CAPACITIES
| Application | (1) Quantity |
|---|
| Automatic Transaxle (Mopar ATF Plus Type 7176) |
| 3-Speed |
| Drain & Refill | 4.0 Qts. (3.8L) |
| Dry Refill | 8.5 Qts. (8.0L) |
| 4-Speed |
| Drain & Refill | 4.0 Qts. (3.8L) |
| Dry Refill | 9.1 Qts. (8.6L) |
| Cooling System (2) | 13.0 Qts. (12.3L) |
| Crankcase (Includes Filter) (3) | 4.5 Qts. (4.3L) |
| Overrunning Clutch (AWD) (Mopar ATF Plus Type 7176) (4) | 12 Ozs. (.35L) |
| Power Steering Fluid (5) | 1.7 Pts. (.8L) |
| Power Transfer Unit (AWD) (SAE 85W-90/API GL-5) | 1.2 Qts. (1.14L) |
| Rear Differential (AWD) (SAE 85W-90/API GL-5) (5) | 2 Qts. (1.9L) |
| (1) Approximate quantity listed. (2) Quantity includes heater and coolant recovery tank. Add 2 qts.(1.9L) if equipped with rear heater. (3) Use engine oil with API SH or SH/CD rating. (4) Overrunning clutch is bolted on front of rear differential, between torque tube for drive shaft and rear differential. Overrunning clutch contains a separate reservoir from rear differential. Ensure fluids are checked at appropriate component, as different types of fluids are used. (5) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (1) | Approximate quantity listed. |
| (2) | Quantity includes heater and coolant recovery tank. Add 2 qts.(1.9L) if equipped with rear heater. |
| (3) | Use engine oil with API SH or SH/CD rating. |
| (4) | Overrunning clutch is bolted on front of rear differential, between torque tube for drive shaft and rear differential. Overrunning clutch contains a separate reservoir from rear differential. Ensure fluids are checked at appropriate component, as different types of fluids are used. |
| (5) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
SPARK PLUG SPECIFICATIONS
| Application | Gap: In. (mm) | Torque: Ft. Lbs. (N.m) |
|---|
| 3.0L | .039-.044 (1.00-1.12) | 20 (27) |
| (1) Check plug gap specification on underhood vehicle emission control label. If spec differs from that listed above, use specification on underhood vehicle emission control label. |
| (1) | Check plug gap specification on underhood vehicle emission control label. If spec differs from that listed above, use specification on underhood vehicle emission control label. |
SPARK PLUG SPECIFICATIONS (1)
Firing Order & Distributor Rotation. Scheme 2
Scheme 2: Firing Order & Distributor Rotation
THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
| Throttle Opening | (1) (2) Volts |
|---|
| At Idle | Greater Than .35 |
| At Full Throttle | Less Than 4.50 |
| (1) Measure voltage at center terminal on throttle position sensor with ignition on. (2) Voltage should increase smoothly when moving throttle from idle to full throttle. |
| (1) | Measure voltage at center terminal on throttle position sensor with ignition on. |
| (2) | Voltage should increase smoothly when moving throttle from idle to full throttle. |
THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
