SPECIAL TOOLS
7700 - Tester, Cooling System (Originally Shipped In Kit Number(s) 7700-A.) 8286 - Refractometer 8875A - Disconnect, Transmission Cooler Line (Originally Shipped In Kit Number(s) 9202, 9328, 9328-CAN, 9329, 9516, 9575.)
Scheme 49
Scheme 50
Scheme 51
Scheme 52
| 1 - POWER STEERING PUMP |
|---|
| 2 - ACCESSORY DRIVE BELT |
| 3 - GENERATOR |
| 4 - CRANKSHAFT PULLEY |
| 5 - LOWER IDLER PULLEY |
| 6 - CRANKSHAFT PULLEY |
| 7 - WATER PUMP PULLEY |
| 8 - ACCESSORY DRIVE BELT TENSIONER |
| 9 - UPPER IDLER PULLEY |
The accessory drive belt (2) is a serpentine type belt that is driven by the crankshaft pulley (6).
The belt drives the A/C compressor, generator (3), power steering pump (1) and water pump (7). Belt tension is maintained by an automatic belt tensioner (8).
Scheme 53
The accessory drive belt on the 2.2L Diesel engine is of the serpentine style. This belt is used to drive the generator, power steering pump, and the A/C compressor.
Scheme 54
| 1 - NORMAL CRACKS ON BELT |
|---|
| 2 - NOT NORMAL CRACKS ON BELT |
When diagnosing serpentine accessory drive belts, small cracks that run across the ribbed surface of the belt from rib to rib (1), are considered normal. These are not a reason to replace the belt. However, cracks running along a rib (not across) (2) are not normal. Any belt with cracks running along a rib must be replaced. Also replace the belt if it has excessive wear, frayed cords or severe glazing.
for further belt diagnosis. Refer to ACCESSORY DRIVE BELT DIAGNOSIS CHART .
