TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Mounting Bolts |
| Dakota 2.5L | 41 (55) |
| Dakota & Durango 4.7L |
| Long Horizontal Bolt | 40 (55) |
| Short Horizontal Bolt | 55 (74) |
| Ram Pickup 5.9L Diesel |
| Generator Mounting Bolt | 18 (24) |
| All Others | 40 (55) |
| Ram Pickup, Ram Van, & Ram Wagon (Gasoline) | 30 (41) |
| INCH Lbs. (N.m) |
| B+ Terminal Nut |
| Except Ram Pickup | 108 (12) |
| Ram Pickup | 75 (8.5) |
Charging System Wiring Diagram (Dakota). Scheme 1
Scheme 1: Charging System Wiring Diagram (Dakota)
Charging System Wiring Diagram (Durango). Scheme 2
Scheme 2: Charging System Wiring Diagram (Durango)
Charging System Wiring Diagram (Ram Pickup - Diesel). Scheme 3
Scheme 3: Charging System Wiring Diagram (Ram Pickup - Diesel)
Charging System Wiring Diagram (Ram Pickup - Gasoline). Scheme 4
Scheme 4: Charging System Wiring Diagram (Ram Pickup - Gasoline)
Charging System Wiring Diagram (Ram Van & Ram Wagon). Scheme 5
Scheme 5: Charging System Wiring Diagram (Ram Van & Ram Wagon)
