SPECIAL TOOLS

10368 - Set, Universal Protective Cap 7700 - Tester, Cooling System (Originally Shipped In Kit Number(s) 7700-A.) 8514 - Pins, Tensioner (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 9506 - Installer, Oil Seal (Originally Shipped In Kit Number(s) 9610, 9970.) 9509 - Installer, Oil Seal (Originally Shipped In Kit Number(s) 9610, 9970.) 9701 - Wedge, Locking (Originally Shipped In Kit Number(s) 9610, 9970.) 9703 - Pin, Tensioner (Originally Shipped In Kit Number(s) 9610, 9970.) 9706 - Installer, Crankshaft Rear Oil Seal (Originally Shipped In Kit Number(s) 9610, 9970.) 9707 - Holder, Vibration Damper (Originally Shipped In Kit Number(s) 9610, 9970.) 9879 - Adapter, Oil Pressure Test (Originally Shipped In Kit Number(s) 9998.) C-3685-A - Bloc-Chek Kit C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.) C-4597 - Socket, Oil Pressure

Scheme 211

Scheme 211: SPECIAL TOOLS

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 223: DESCRIPTION

The engine serial number (1) is located between the oil pan and the bellhousing. The serial number contains engine build date, build location, and displacement.

Example: 8CAP1339710217

WORLD ENGINE
8	C	A	P1	339	7	1	0217
Model Year	Engine Displacement	Engine Build Variation (with oil cooler, turbo, for MMNA)	Engine Plant	Julian Day of Year	Julian Year 2007	Shift	Build Sequence Number
2008	A = 1.8L		P1 = GEMA North
	B = 2.0L		P2 = GEMA South
	C = 2.4L

Scheme 224

Scheme 224: REMOVAL

CAUTION

Do not use an assist tool or excessive force when unlocking the air box lid tabs (1). Excessive force may break the tabs off of the lid.

Scheme 225

Unlock the air box lid tabs and lift the air cleaner housing cover (1).
Pull the cover forward to disengage the rear tabs.
Remove the air filter element (2).

Scheme 226

Scheme 226: INSTALLATION

Install the air filter element (2) into the air cleaner housing.
Install the cover (1) so that the rear tabs insert into the lower air box.
Push down on the cover to engage the front locking tabs.

Scheme 227

Scheme 227: REMOVAL

Remove air cleaner housing retaining bolt (2).
Remove clean air hose from air cleaner housing.
Lift air cleaner housing (1) upwards and remove.

Scheme 228

Scheme 228: INSTALLATION

Position air cleaner housing (1) in place.
Install retaining bolt (2).
Install clean air hose.
