SPECIAL TOOLS

10198 - Holder, Vibration Damper (Originally Shipped In Kit Number(s) 10223.) 10199 - Installer, Crankshaft Front Oil Seal (Originally Shipped In Kit Number(s) 10223.) 10200-1 - Holder, Timing Chain, Left Side 10200-3 - Pin 10202 - Locks, Camshaft/Phaser 10202-1 - Lock, Camshaft/Phaser, Right Side 10202-2 - Lock, Camshaft/Phaser, Left Side 10224 - Adapter, Valve Spring (Originally Shipped In Kit Number(s) 10223.) 10242-1 - Brackets, Engine Lifting, Left Side (Originally Shipped In Kit Number(s) 10223.) 10242-2 - Brackets, Engine Lifting, Right Side (Originally Shipped In Kit Number(s) 10223.) 10255 - Installer, Spark Plug Tube 10256 - Installer, Cam Installer, Cam Sensor/ Spark Plug Tube Seal (Originally Shipped In Kit Number(s) 10256.) 10368 - Set, Universal Protective Cap 10369 - Holder, Timing Chain 6135 - Dolly, Power Train (Originally Shipped In Kit Number(s) 6784C.) 6710A - Cradle, Engine Support (Originally Shipped In Kit Number(s) 6784, 6809.) 6848-3 - Adapter (Originally Shipped In Kit Number(s) 6880, 6881, 6882, 6883.) 7700-A - Tester, Cooling System 8189 - Guide Pins (Originally Shipped In Kit Number(s) 8180, 8180CC, 8263, 8263CC.) 8511 - Remover, Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8514 - Pins, Tensioner (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8875A - Disconnect, Transmission Cooler Line (Originally Shipped In Kit Number(s) 9202, 9328, 9328-CAN, 9329, 9516, 9575.) C-119 - Cylinder Indicator C-3292A - Gauge, Pressure C-3339A - Set, Dial Indicator (Originally Shipped In Kit Number(s) 9202.) C-3422-D - Compressor, Valve Spring C-3685-A - Bloc-Chek Kit C-385 - Compressor, Piston MD998772A - Compressor, Valve Spring (Originally Shipped In Kit Number(s) 8678, 8853, 8854.)

Scheme 499

Scheme 499: SPECIAL TOOLS

Scheme 500

Scheme 501

Scheme 502

Scheme 503

Scheme 504

Scheme 505

Scheme 506

Scheme 507

Scheme 508

Scheme 509

Scheme 510

Scheme 511

Scheme 512

Scheme 513

Scheme 514

Scheme 515

Scheme 516

Scheme 517

Scheme 518

Scheme 519

Scheme 520

Scheme 521

Scheme 522

Scheme 523

Scheme 524

Scheme 525

Scheme 526

Scheme 527

Scheme 527: REMOVAL

Scheme 528

Disconnect the fresh air makeup hose (2) from the air cleaner housing cover.
Loosen the four screws (1) securing the air cleaner housing cover.
Lift the cover and remove the air cleaner element (1). CAUTION: Do not use compressed air to clean out the air cleaner housing without first covering the air inlet to the throttle body. Dirt or foreign objects could enter the intake manifold causing engine damage.
Remove any dirt or debris from the bottom of the air cleaner housing.
