SPECIFICATIONS
| Component | Fluids, Lubricants, and Genuine Parts |
|---|---|
| Engine Coolant | Mopar® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent |
| Engine Oil (2.4 & 2.7 Liter) | Use API Certified engine oil. SAE 5W-20 is recommended. Refer to the engine oil fill cap for the correct SAE grade meeting Chrysler Material Standard MS-6395. |
| Engine Oil (3.5 Liter) | Use API Certified engine oil. SAE 10W-30 is recommended. Refer to the engine oil viscosity chart for the correct SAE grade meeting Chrysler Material Standard MS-6395. |
| Oil Filter (2.4 Liter) | Mopar ® 04884900AB or equivalent. |
| Oil Filter (2.7& 3.5 Liter) | Mopar ® 04884899AB or equivalent. |
| Spark Plugs (2.4 Liter - EXCEPT PZEV) | ZFR5F-11 (Gap.043 in [1.11 mm]) |
| Spark Plugs (2.4 Liter with PZEV,) | ZFR5AP (Gap.031 in [0.80 mm]) |
| Spark Plugs (2.7 Liter) | RE14PMC5 (Gap.050 in [1.27 mm]) |
| Spark Plugs (3.5 Liter) | ZFR5LP-13G (Gap.050 in [1.27 mm]) |
| Fuel Selection (2.4 & 2.7 Liter) | 87 Octane |
| Fuel Selection (2.7 Liter EXCEPT CALIFORNIA EMISSION STATES) | E-85 Ethanol |
| Fuel Selection (3.5 Liter) | 87 to 89 Octane |
ENGINE
| Component | Fluid, Lubricant, or Genuine Part |
|---|---|
| Engine Coolant | Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. |
| Engine Coolant - Diesel Engine | Glysantin G 30-91 |
| Engine Oil - Gasoline Engines (Non ACEA Categories) | Use API Certified SAE 5W-20 engine oil, meeting the requirements of Chrysler Material Standard MS-6395. Refer to your engine oil filler cap for correct SAE grade. SAE 5W-30 engine oil approved to MB 229.31 or MB 229.51 may be used when SAE 5W-20 engine oil is not available. |
| Engine Oil - Gasoline Engines (ACEA Categories) | For countries that use the ACEA European Oil Categories for Service Fill Oils, use engine oils meeting the requirements of ACEA C3, and approved to MB 229.31 or MB 229.51. SAE 5W-30 engine oil approved to MB 229.31 or MB 229.51 may be used when SAE 5W-20 engine oil is not available. |
| Engine Oil - Diesel Engine (ACEA Categories) | Use only Synthetic SAE 5W-30, SAE 0W-40, SAE 5W-40, SAE 10W-40, or SAE 15W-40, ACEA A3/B3, A3/B4, or A3/B4/C3 engine oil. |
| Engine Oil Filter (2.4 Liter) | Mopar ® 04884900AB or equivalent |
| Engine Oil Filter (2.7 Liter) | Mopar ® 05281090 or equivalent |
| Engine Oil Filter (2.0 Liter Diesel) | Mopar ® 68001297AA |
| Spark Plugs (2.4 Liter) | ZFR5F-11 (Gap.043 in [1.11 mm]) |
| Spark Plugs (2.7Liter) | RE14PMC5 (Gap.050 in [1.27 mm]) |
| Fuel Selection - Gasoline Engines | Minimum 91 Research Octane Number (RON) |
| Fuel Selection - Diesel Engine | European low sulfur diesel. Cetane: 50 minimum, Sulfur 50 ppm maximum. (intermittent use of up to 350 ppm sulfur fuel can be tolerated, but emissions performance will degrade). |
ENGINE - EXPORT
| Component | Fluids, Lubricants and Genuine Parts |
|---|---|
| Automatic Transmission | Mopar ® ATF+4 Automatic Transmission Fluid. |
| Brake Master Cylinder | Mopar ® DOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not available, then DOT 4 is acceptable. Use only recommended brake fluids. |
| Power Steering Reservoir | Mopar ® ATF+4 Automatic Transmission Fluid. |
CHASSIS
| Component | Fluids, Lubricants and Genuine Parts. |
|---|---|
| Automatic Transaxle | Mopar ® ATF+4 Automatic Transmission Fluid. |
| Dual Clutch Automatic Transaxle - MPS6 | Castrol BOT-341 |
| Manual Transaxle | Mopar ® ATF+4 MS9602. |
| Brake/Clutch Master Cylinder 1 | Mopar ® DOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable. Use only recommended brake fluids. |
| Power Steering Reservoir | Mopar ® Power Steering Fluid + 4, Mopar ® ATF+4 Automatic Transmission Fluid. |
| Tire Pressure | Refer to label on driver's door. |
| 1 Brake Master Cylinder in vehicles equipped with manual transaxle is shared with the clutch. | |
CHASSIS - EXPORT
| Description | U.S. | Metric |
|---|---|---|
| Fuel (approximate) | ||
| All FWD Engines - (Except 2.4 Liter PZEV) | 16.9 Gallons | 64 Liters |
| 3.5 Liter Engine with AWD (All Wheel Drive) | 17.3 Gallons | 65.5 Liters |
| 2.4 Liter PZEV (Partial Zero Emissions Vehicle) | 18.4 Gallons | 69.7 Liters |
| Engine Oil-With Filter | ||
| 2.4 Liter Engine (SAE 5W-20, API Certified) | 4.5 Quarts | 4.26 Liters |
| 2.7 Liter Engine (SAE 5W-20, API Certified) | 5.5 Quarts | 5.2 Liters |
| 3.5 Liter Engine (SAE 10W-30, API Certified) | 5.5 Quarts | 5.2 Liters |
| Cooling System * | ||
| 2.4 Liter Engine (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent. | 7.7 Quarts. | 7.3 Liters |
| 2.7 Liter Engine (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent. | 9.8 Quarts. | 9.3 Liters |
| 3.5 Liter Engine (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent. | 11.6 Quarts. | 11.0 Liters |
| * Includes heater and coolant recovery bottle filled to MAX level. | ||
| POWER STEERING SYSTEM | ||
| Power steering fluid capacities are dependent on engine/chassis options as well as steering gear/cooler options. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these capacities may vary. Refer to STANDARD PROCEDURE . | ||
| A/C REFRIGERANT SYSTEM | ||
| A/C REFRIGERANT | 1.0 lbs. | 0.454 kg |
| AUTOMATIC TRANSAXLE | ||
| Automatic Transaxle 41TE/41AE- Estimated Service Fill | 4.0 Quarts | 3.8 Liters |
| Automatic Transaxle 41TE/41AE- Overhaul Capacity with Torque Converter Empty | 9.2 Quarts | 8.7 Liters |
| Automatic Transaxle 62TE- Estimated Service Fill | 5.5 Quarts | 5.2 Liters |
| Automatic Transaxle 62TE- Overhaul Capacity with Torque Converter Empty | 9.0 Quarts | 8.5 Liters |
| Dry fill capacity depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. Refer to STANDARD PROCEDURE . Refer to STANDARD PROCEDURE . | ||
| MANUAL TRANSAXLE | ||
| Manual Transaxle - NV T355 | 2.5 - 2.8 Quarts | 2.4 - 2.7 Liters |
| Manual Transaxle - BG6 | 2.1 Quarts | 2.0 Liters |
CAPACITIES
| U.S. | Metric | |
|---|---|---|
| Fuel (approximate) | ||
| All Engines | 16.9 Gallons | 64 Liters |
| Engine Oil-With Filter | ||
| 2.4 Liter Gasoline Engines (Use ACEA A1/B1, A3/B4 or A3/B3; SAE 5W-20 Engine Oil.) | 4.5 Quarts | 4.26 Liters |
| 2.7 Liter Gasoline Engines (Use ACEA A1/B1, A3/B4 or A3/B3; SAE 5W-20 Engine Oil.) | 5.5 Quarts | 5.2 Liters |
| 2.0 Liter Diesel Engines (Use Synthetic: ACEA A3/B3, A3/B4, or A3/B4/C3; SAE 5W-30, SAE 0W-40, SAE 5W-40, SAE 10W-40, or SAE 15W-40 Engine Oil.) | 4.2 Quarts | 4.0 Liters |
| Cooling System * | ||
| 2.4 Liter Gasoline Engines (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. | 7.7 Quarts | 7.3 Liters |
| 2.7 Liter Gasoline Engines (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. | 9.8 Quarts | 9.3 Liters |
| 2.0 Liter Diesel Engines (Glysantin G 30-91 coolant). | 8.2 Quarts | 7.8 Liters |
| * Includes heater and coolant recovery bottle filled to MAX level. | ||
| POWER STEERING SYSTEM | ||
| Power steering fluid capacities are dependent on engine/chassis options as well as steering gear/cooler options. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these capacities may vary. Refer to STANDARD PROCEDURE . | ||
| A/C REFRIGERANT SYSTEM | ||
| A/C REFRIGERANT | 1.0 lbs. | 0.454 kg |
| AUTOMATIC TRANSAXLE | ||
| Automatic Transaxle 41TE/41AE- Estimated Service Fill | 4.0 Quarts | 3.8 Liters |
| Automatic Transaxle 41TE/41AE- Overhaul Capacity with Torque Converter Empty | 9.2 Quarts | 8.7 Liters |
| Automatic Transaxle 62TE- Estimated Service Fill | 5.5 Quarts | 5.2 Liters |
| Automatic Transaxle 62TE- Overhaul Capacity with Torque Converter Empty | 9.0 Quarts | 8.5 Liters |
| Dry fill capacity depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. Refer to STANDARD PROCEDURE . Refer to STANDARD PROCEDURE . | ||
| MANUAL TRANSAXLE | ||
| Manual Transaxle - NV T355 | 2.5 - 2.8 Quarts | 2.4 - 2.7 Liters |
| Manual Transaxle - BG6 | 2.1 Quarts | 2.0 Liters |
CAPACITIES - EXPORT
Scheme 7
A Totally Integrated Power Module is located in the engine compartment near the air cleaner assembly. This center contains cartridge fuses and mini fuses.
| Cavity | Cartridge Fuse | Mini Fuse | Description |
|---|---|---|---|
| 1 | 40 Amp Green | ||
| 2 | 20 Amp Yellow | ||
| 3 | 10 Amp Red | Battery Feed - Center High Mounted Stop Light (CHMSL)/Brake Switch | |
| 4 | 10 Amp Red | Battery Feed - Ignition Switch | |
| 5 | 20 Amp Yellow | Trailer Tow - If Equipped | |
| 6 | 10 Amp Red | Ignition Off Draw (IOD) - Power Mirror Switch/Climate Controls | |
| 7 | 30 Amp Green | Ignition Off Draw (IOD) Sense 1 | |
| 8 | 30 Amp Green | Ignition Off Draw (IOD) Sense 2 | |
| 9 | 40 Amp Green | Battery Feed - Power Seats - if equipped/PZEV Air Pump - if equipped | |
| 10 | 20 Amp Yellow | Battery Feed - Cabin Compartment Node (CCN) | |
| 11 | 15 Amp Lt Blue | Selectable Power Outlet | |
| 12 | 20 Amp Yellow | ||
| 13 | 20 Amp Yellow | ||
| 14 | 10 Amp Red | Ignition Off Draw (IOD) - Cabin Compartment Node (CCN)/ Interior Lighting | |
| 15 | 40 Amp Green | Battery Feed - Radiator Fan Relay | |
| 16 | 15 Amp Lt. Blue | IGN Run/ACC - Cigar Lighter/PWR Sunroof Mod | |
| 17 | 10 Amp Red | Ignition Off Draw (IOD) - Wireless Control Module (WCM)/Clock/Steering Control Module (SCM)/Steering Lock Module | |
| 18 | 40 Amp Green | Battery Feed - Auto Shutdown (ASD) Relay | |
| 19 | 20 Amp Yellow | Ignition Off Draw (IOD) - Power Amp Feed 2 - if equipped | |
| 20 | 15 Amp Lt. Blue | Ignition Off Draw (IOD) - Radio | |
| 21 | 10 Amp Red | Ignition Off Draw (IOD) | |
| 22 | 10 Amp Red | Ignition Run - Climate Controls/Hot Cup Holder - if equipped | |
| 23 | 15 Amp Lt. Blue | Auto Shutdown (ASD) Relay Feed 3 | |
| 24 | 25 Amp Clear | Battery Feed - PWR Sunroof Feed | |
| 25 | 10 Amp Red | Ignition Run - Heated Mirrors - If Equipped | |
| 26 | 15 Amp Lt. Blue | Auto Shutdown (ASD) Relay Feed 2 | |
| 27 | 10 Amp Red | Ignition Run - Occupant Classification Module (OCM)/Occupant Restraint Controller (ORC) | |
| 28 | 10 Amp Red | Ignition Run - Occupant Classification Module (OCM)/Occupant Restraint Controller (ORC) | |
| 29 | Hot Car (No Fuse Required) | ||
| 30 | 20 Amp Yellow | Ignition Run - Heated Seats - If Equipped | |
| 31 | 10 Amp Red | Headlight Washer Relay Control - if equipped | |
| 32 | 30 Amp Pink | Auto Shutdown (ASD) Relay Feed 1 | |
| 33 | 10 Amp Red | Battery Feed - Switch Bank/Diagnostic Link Connector/Powertrain Control Module (PCM) | |
| 34 | 30 Amp Pink | Battery Feed - Anti-Lock Brakes (ABS) Module - if equipped/Electronic Stability Program (ESP) Module - If Equipped | |
| 35 | 40 Amp Green | Battery Feed - Anti-Lock Brakes (ABS) Module - If Equipped/Electronic Stability Program (ESP) Module - If Equipped | |
| 36 | 30 Amp Pink | Battery Feed - Passenger Door Module (PDM)/Driver Door Module (DDM) | |
| 37 | 25 Amp Clear |
| CAUTION | When installing the Totally Integrated Power Module cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Totally Integrated Power Module, and possibly result in an electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
SPECIFICATIONS - EXTERIOR
| LIGHT BULBS - EXTERIOR | Bulb Number |
|---|---|
| Low Beam Headlight | 9006 |
| High Beam Headlight | 9005 |
| Front Park/Turn Signal/Side Marker Light | 3157AK |
| Front Fog Light | 9145//H10 |
| Center High Mounted Stop Light (CHMSL) | W16W (921) |
| Rear Tail/Stop | 3157K |
| Decklid Tail Light | T3.25 |
| Rear Turn Signal | 3757AK |
| Backup Light | 3157K |
| License Light | 168 |
| LIGHT BULBS - EXTERIOR | Bulb Number |
|---|---|
| Low Beam Headlight | 9006 |
| High Beam Headlight | 9005 |
| Front Park/Turn Signal Light | 3457AK |
| Front Side Repeater Light | W5W |
| Front Fog Light | 9145//H10 |
| Center High Mounted Stop Light (CHMSL) | W16W (921) |
| Rear Tail/Stop | 3057P27/7W |
| Rear Turn Signal | 3757APY27/7WK |
| Backup Light | 3157KP27/7W |
| Rear Fog Light | 3057P27/7W |
| License Light | 168 |
REPLACEMENT LIGHT BULBS - EXTERIOR - EXPORT
SPECIFICATIONS - INTERIOR
All the inside bulbs are brass or glass wedge base. Aluminum base bulbs are not approved and should not be used for replacement.
| LIGHT BULBS - INTERIOR | Bulb Number |
|---|---|
| Front Courtesy/Reading Lights | 578/W5W |
| Center Courtesy/Reading Lights | 578/W5W |
| Visor Vanity Lights | A6220 |
| Glove Box Light | 194 |
| Shift Indicator Light | JKLE14140 |
| Rear Compartment (Trunk) Light | 579 |
Note. For lighted switches, see your dealer for replacement instructions.
