Vehicle Data: Overview — Dodge Avenger II (2007-2010)

Scheme 1

Scheme 1: DESCRIPTION

An E-mark Label is located on the rear shut face of the driver's door. The label contains the following information

Date of Manufacture
Month-Day-Hour (MDH)
Vehicle Identification Number (VIN)
Country Codes (1)
Regulation Number (2)
Regulation Amendment Number (4)
Approval Number (3)

DESCRIPTION

The SAE bolt strength grades range from grade 2 to grade 8. The higher the grade number, the greater the bolt strength. Identification is determined by the line marks on the top of each bolt head. The actual bolt strength grade corresponds to the number of line marks plus 2. The most commonly used metric bolt strength classes are 8.9 and 10.9. The metric strength class identification number is imprinted on the head of the bolt. The higher the class number, the greater the bolt strength. Some metric nuts are imprinted with a single-digit strength class on the nut face. Refer to BOLT MARKINGS AND TORQUES - METRIC and BOLT MARKINGS AND TORQUES - U. S. CUSTOMARY .

BOLT MARKINGS	8.8/8.9		10.9		12.9
BOLT DIA.	N.M	FT. LBS.	N.M	FT. LBS.	N.M	FT. LBS.
6	12	105*	14	125*	16	12
8	25	250*	32	23	38	28
10	54	40	60	45	74	55
12	95	70	108	80	135	100
14	155	115	175	130	216	160
16	243	180	324	240	324	240
* Inch Lbs.

BOLT MARKINGS AND TORQUES - METRIC

BOLT MARKINGS	GRADE 5		GRADE 8
BOLT DIA.	N.M	FT. LBS.	N.M	FT. LBS.
1/4 - 20	10	95*	14	125*
1/4 - 28	10	95*	17	150*
5/16 - 18	22	200*	30	270*
5/16 - 24	26	240*	33	300*
3/8 - 16	40	30	55	40
3/8 - 24	47	35	60	45
7/16 - 14	68	50	88	65
7/16 - 20	74	55	95	70
1/2 - 13	101	75	135	100
1/2 - 20	115	85	150	110
9/16 - 12	135	100	182	135
9/16 - 18	155	115	202	150
5/8 - 11	202	150	263	195
5/8 - 18	215	160	284	210
3/4 - 10	230	170	297	220
3/4 - 16	236	175	304	225
7/8 - 14	405	300	540	400
* Inch Lbs.

BOLT MARKINGS AND TORQUES - U. S. CUSTOMARY

Scheme 2

Class	Diameter mm	Pitch mm	Specified torque
			Hexagon head bolt			Hexagon flange bolt
			N.m	Kgf-cm	Ft-lbf	N.m	Kgf-cm	Ft-lbf
4T	6	1	5	55	48 in.-lbf	6	60	52 in.-lbf
	8	1.25	12.5	130	9	14	145	10
	10	1.25	26	260	19	29	290	21
	12	1.25	47	480	35	53	540	39
	14	1.5	74	760	55	84	850	61
	16	1.5	115	1,150	83
5T	6	1	6.5	65	56 in.-lbf	7.5	75	65 in.-lbf
	8	1.25	15.5	160	12	17.5	175	13
	10	1.25	32	330	24	36	360	26
	12	1.25	59	600	43	65	670	48
	14	1.5	91	930	67	100	1,050	76
	16	1.5	140	1,400	101
6T	6	1	8	80	69 in.-lbf	9	90	78 in.-lbf
	8	1.25	19	195	14	21	210	15
	10	1.25	39	400	29	44	440	32
	12	1.25	71	730	53	80	810	59
	14	1.5	110	1,100	80	125	1,250	90
	16	1.5	170	1,750	127
7T	6	1	10,5	110	8	12	120	9
	8	1.25	25	260	19	28	290	21
	10	1.25	52	530	38	58	590	43
	12	1.25	95	970	70	105	1,050	76
	14	1.5	145	1,500	108	165	1,700	123
	16	1.5	230	2,300	166
8T	8	1.25	29	300	22	33	330	24
	10	1.25	61	620	45	68	690	50
	12	1.25	110	1,100	80	120	1,250	90
9T	8	1.25	34	340	25	37	380	27
	10	1.25	70	710	51	78	790	57
	12	1.25	125	1,300	94	140	1,450	105
10T	8	1.25	38	390	28	42	430	31
	10	1.25	78	800	58	88	890	64
	12	1.25	140	1,450	105	155	1,600	116
11T	8	1.25	42	430	31	47	480	35
	10	1.25	87	890	64	97	990	72
	12	1.25	155	1,600	116	175	1,800	130

SPECIFIED TORQUE FOR STANDARD BOLTS

Scheme 3

Scheme 3: DESCRIPTION

A vehicle certification label is attached to the rear shut face of the driver's door. This label indicates date of manufacture (month and year), Gross Vehicle Weight Rating (GVWR), Gross Axle Weight Rating (GAWR) front, Gross Axle Weight Rating (GAWR) rear and the Vehicle Identification Number (VIN). The Month, Day and Hour (MDH) of manufacture is also included.

All communications or inquiries regarding the vehicle should include the Month-Day-Hour and Vehicle Identification Number.

All models have a Vehicle Emission Control Information (VECI) Label. DaimlerChrysler permanently attaches the label in the engine compartment. It cannot be removed without defacing information and destroying the label.

The label contains the vehicle's model year, fuel tank capacity and fuel type. Also states what regulations the vehicle conforms to and if the vehicle is OBD II compliant.

Scheme 4

Scheme 4: DESCRIPTION

The Vehicle Identification Number (VIN) is located on the upper left corner of the instrument panel, near the left windshield pillar. The VIN consists of 17 characters in a combination of letters and numbers that provide specific information about the vehicle. Refer to VIN CODE BREAKDOWN for decoding information.

POSITION	INTERPRETATION	CODE/DESCRIPTION
1	Country of Origin	1 = Manufactured By DaimlerChrysler Corporation.
2	Make	B = Dodge
2	Make	C = Chrysler
3	Vehicle Type	3 = Passenger Car
4	Passenger Safety	A = Front Airbags with Side Airbags
		D = Restraints without Airbags
		E = Front Airbags without Side Airbags
		K = Front Airbags without Side Airbags
		L = Front Airbags with Side Airbags
5	Vehicle Line	C = CHRYSLER Cirrus (FWD) (LHD) Mexico
		C = CHRYSLER Sebring (FWD) (LHD) U.S, Canada, BUX
		4 = CHRYSLER Sebring (FWD) (RHD) BUX
		C = DODGE Avenger (FWD) (LHD) U.S, Canada, Mexico, BUX
		D = CHRYSLER Sebring (AWD) (LHD) U.S, Canada
		D = DODGE Avenger (AWD) (LHD) U.S, Canada
		4 = DODGE Avenger (FWD) (RHD) BUX
6	Series	4 = H (High line)
		5 = P (Premium)
		6 = S (Sport)
		7 = X (Special)
6 - Export	Series	B = 4 Speed Automatic
		N = 5-Speed Manual
		C = 6 Speed Manual
		F = 6 Speed Automatic
7	Body Style	5 = Convertible
7	Body Style	6 = 4 Door Sedan
8	Engine	R = 2.7L 6 Cyl. 24V DOHC Gasoline
		M = 3.5L Six Cylinder 24 Valves DOHC High Output Gasoline
		B = 2.0L Four Cylinder 16 Valves DOHC Dual VVT Gasoline
		K = 2.4L 4 Cyl. 16V DOHC VVT Gasoline
		A = 2.0 L 4 Cyl. 16 V DOHC Diesel
		J = 2.4L I4 Cyl. DUAL VVT PZEV GASOLINE, SALES CODE (EDG)
9	Check Digit	0 through 9 or X
10	Model Year	8 = 2008
11	Plant	N = Sterling Heights Assembly Plant
12 through 17	Sequence Number	6 digit number assigned by assembly plant.
