FRONT SUSPENSION FASTENER TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Ball Joint Nut | 81 + 90° turn | 60 + 90° turn | |
| Brake Caliper Adapter Mounting Bolts | 169 | 125 | |
| Engine Cradle Mounting Bolts | 163 | 120 | |
| Hub And Bearing Mounting Bolts | 65 | 45 | |
| Hub And Bearing Axle Hub Nut | 244 | 180 | |
| Lower Control Arm Frame Bolts | 163 | 120 | |
| Stabilizer Bar Cushion Retainer Bolts | 54 | 40 | |
| Stabilizer Bar Link Nuts | 88 | 65 | |
| Strut Body/Tower Mounting Nuts | 28 | 21 | 250 |
| Strut Clevis-to-Knuckle Nuts | 88 + 90° turn | 65 + 90° turn | |
| Strut Shaft Nut | 100 | 75 | |
| Tie Rod Adjuster Jam Nut | 75 | 55 | |
| Tie Rod Steering Arm Nut | 47 + 180° turn | 35 + 180° turn | |
| Wheel Mounting (Lug) Nuts | 135 | 100 |
Scheme 1
Scheme 2
Scheme 3
REAR SUSPENSION FASTENER TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Brake Caliper Adapter Knuckle Bolts | 115 | 85 | |
| Camber Link Crossmember Bolt | 68 | 50 | |
| Camber Link Knuckle Bolt | 95 | 70 | |
| Compression Link Crossmember Bolt | 68 | 50 | |
| Compression Link Knuckle Bolt | 81 | 60 | |
| Crossmember Mounting Bolts | 163 | 120 | |
| Hub And Bearing Mounting Bolts | 81 | 60 | |
| Hub Nut | 244 | 180 | |
| Shock Absorber Mounting Bolts - Upper | 61 | 45 | |
| Shock Absorber Mounting Bolt Nut - Lower | 102 | 75 | |
| Spring Link Crossmember Bolt | 108 | 80 | |
| Spring Link Knuckle Nut | 129 | 95 | |
| Stabilizer Bar Cushion Retainer Bolts | 61 | 45 | |
| Stabilizer Link Nuts | 61 | 45 | |
| Tension Link Crossmember Bolt | 68 | 50 | |
| Tension Link Knuckle Bolt | 119 | 88 | |
| Toe Link Crossmember Nut | 172 | 127 | |
| Toe Link Knuckle Bolt | 108 | 80 |
