Suspension System: Adjustments Chrysler Pacifica CS

PRE-WHEEL ALIGNMENT INSPECTION

Before any attempt is made to change or correct the wheel alignment, the following inspection and necessary corrections must be made to ensure proper alignment.

1. Verify that the fuel tank is full of fuel. If the tank is not full, the reduction in weight will affect the curb height of the vehicle and the alignment angles.
2. The passenger and luggage compartments of the vehicle should be free of any load that is not factory equipment.
3. Check the tires on the vehicle. All tires must be the same size and in good condition with approximately the same amount of tread wear. Inflate all the tires to the recommended air pressure.
4. Check the front wheel and tire assemblies for excessive radial runout.
5. Inspect lower ball joints and all steering linkage for looseness, binding, wear or damage. Repair as necessary.
6. Check suspension fasteners for proper torque and retighten as necessary.
7. Inspect all suspension component rubber bushings for signs of wear or deterioration. Replace any faulty bushings or components before aligning the vehicle.
8. Check the vehicle's curb height to verify it is within specifications. «(Refer to SUSPENSION/WHEEL ALIGNMENT - STANDARD PROCEDURE - CURB HEIGHT MEASUREMENT)»(ref-245426-S19121663772006110200000)

WHEEL ALIGNMENT SETUP

1. Position the vehicle on an alignment rack.
2. Install all required alignment equipment on the vehicle per the alignment equipment manufacturer's instructions. On this vehicle, a four-wheel alignment is recommended. NOTE: Prior to reading the vehicle's alignment readouts, the front and rear of vehicle should be jounced. Induce jounce (rear first, then front) by grasping the center of the bumper and jouncing each end of vehicle an equal number of times. The bumper should always be released when vehicle is at the bottom of the jounce cycle.
3. Read the vehicle's current front and rear alignment settings. Compare the vehicle's current alignment settings to the vehicle specifications for camber, caster and toe-in. «(Refer to SUSPENSION/WHEEL ALIGNMENT - SPECIFICATIONS)»(ref-245426-S03297586692006110200000)
4. If front camber and caster are not within specifications, proceed to CAMBER AND CASTER below. If caster and camber are within specifications, proceed to TOE which can be found following CAMBER AND CASTER. Rear camber and caster are not adjustable. If found not to be within specifications, reinspect for damaged suspension or body components and replace as necessary. If rear toe is not within specifications, adjust rear toe before proceeding to adjust front toe.

CAMBER ADJUSTMENT BOLT PACKAGE INSTALLATION

The camber adjustment bolt package contains 2 flange bolts, 2 cam bolts, 2 dog bone washers, and 4 nuts. This package services both sides of the vehicle. Use the package to attach the strut clevis bracket to the steering knuckle after the strut clevis bracket has been modified. To install and adjust the camber adjustment bolt package, follow the procedure below.

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. Raise the vehicle until its tires are not supporting the weight of the vehicle.
2. Remove the front tire and wheel assemblies. CAUTION: When removing the steering knuckle from the strut clevis bracket, do not put a strain on the brake flex hose. Also, do not let the weight of the steering knuckle assembly be supported by the brake flex hose when removed from the strut assembly. If necessary use a wire hanger to support the steering knuckle assembly or if required remove the brake flex hose from the caliper assembly. CAUTION: The knuckle to strut assembly attaching bolt shanks are serrated and must not be turned during removal. Remove the nuts while holding the bolts stationary.
3. Remove the top and bottom strut clevis bracket-to-steering knuckle attaching bolts and discard. (Scheme 13) Separate the steering knuckle from the strut clevis bracket and position steering knuckle so it is out of the way of the strut. 1 - STRUT CLEVIS BRACKET 2 - ATTACHING BOLTS 3 - TIE ROD END 4 - ROTOR 5 - STEERING KNUCKLE CAUTION: When slotting the bottom mounting hole on the strut clevis bracket, do not enlarge the hole beyond the indentations on the sides of the strut clevis bracket. (Scheme 14)
4. Using an appropriate grinder and grinding wheel, slot the bottom hole in both sides of the strut clevis bracket. (Scheme 14) 1 - UPPER STRUT TO STEERING KNUCKLE ATTACHING HOLE 2 - CAMBER ADJUSTMENT SLOT INDENTATION AREA ON CLEVIS BRACKET 3 - LOWER STRUT TO STEERING KNUCKLE ATTACHING HOLE 4 - STRUT CLEVIS BRACKET CAUTION: After slotting the strut clevis bracket hole, do not install the original attaching bolts when assembling the steering knuckle to the strut assembly. Only the flange bolts, cam bolts, and dog bone washers from the service package must be used to attach the steering knuckle to the strut after the mounting hole is slotted. NOTE: The strut clevis-to-knuckle bolts are installed differently on each side of the vehicle. Left-hand-side bolts are installed from vehicle rear to front. see scheme 91 Right-hand-side bolts are installed from vehicle front to rear. see scheme 92 1 - STRUT 2 - BOLT 3 - NUT 1 - STRUT 2 - BOLT 3 - NUT
5. Position the knuckle back into the strut clevis bracket. Using the direction indicated in the above note, install a flanged bolt from the service package into the upper mounting hole. Using the direction indicated in the above note, install a cam bolt into the bottom mounting hole. (Scheme 15) 1 - STEERING KNUCKLE 2 - FLANGED BOLT IN TOP HOLE 3 - CAM BOLT IN BOTTOM HOLE 4 - STRUT CLEVIS BRACKET
6. Install a dog bone washer on the steering knuckle to strut clevis bracket attaching bolts, then install the nuts onto the bolts from the service package. (Scheme 16) Tighten the bolts just enough to hold the steering knuckle in position when adjusting camber, while still allowing the steering knuckle to move in clevis bracket. 1 - STEERING KNUCKLE 2 - DOG BONE WASHER 3 - STRUT CLEVIS BRACKET 4 - ATTACHING NUTS
7. Repeat the procedure to the other side strut clevis bracket.
8. Reinstall both front tire and wheel assemblies and tighten to specifications.
9. Lower the vehicle. Jounce the front and rear of vehicle an equal amount of times.
10. Adjust front camber to the preferred setting by rotating the lower eccentric cam bolt against the cam stop areas on the strut clevis bracket. (Scheme 17) When camber is set, tighten the upper strut clevis bracket bolt and lower cam bolt. Again jounce front and rear of vehicle an equal amount of times and verify front camber setting. Torque both front strut to steering knuckle attaching bolts to 88 N.m (65 ft. lbs.) plus an additional 1/4 (90°) turn after the required torque is met. 1 - STEERING KNUCKLE 2 - CLEVIS BRACKET CAM STOP AREAS 3 - LOWER ECCENTRIC CAMBER ADJUSTMENT BOLT
11. If the toe readings obtained are not within the required specification range, adjust toe to meet the preferred specification setting. Proceed to TOE below to set the vehicle's toe.

WHEEL ALIGNMENT

Note. All specifications are given in degrees.

Note. All wheel alignments are to be set at curb height. (Refer to SUSPENSION/WHEEL ALIGNMENT - STANDARD PROCEDURE)
