Engine Cooling System & Automatic Transmission Cooling System: Specifications Chrysler Pacifica CS

Accessory Drive Belts 5 illustrations

TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Accessory Drive Belt Tensioner Assembly -Bolt28250
Engine Coolant Temperature Sensor760
Generator & A/C Compressor Drive Belt Tensioner Assembly -Bolt5440
Coolant Outlet Connector/Thermostat Housing-Bolts28250
Water Pump12105
Water Pump Inlet Tube -Bolts12105
Water Pump Inlet Tube -Bolts28250
Water Pump Pulley -Bolts28250
Radiator to A/C Condenser-Screws545
Radiator Fan-Screws545
Radiator Mounting (Upper Bracket)-Nuts12105

Scheme 1

Scheme 1: COOLING SYSTEM
Scheme 1: COOLING SYSTEM

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: REMOVAL
Scheme 5: REMOVAL
  1. Raise vehicle on hoist.
  2. Remove the drive belt shield.
  3. Remove the drive belt «(Refer to COOLING/ACCESSORY DRIVE/DRIVE BELTS - REMOVAL)»(ref-245448-S38168346922006110200000).
  4. Remove the belt tensioner. (Scheme 5) 1 - BELT TENSIONER 2 - BOLT
