Audio System & Video System: Other Chrysler Pacifica CS

Entertainment Systems 4 illustrations ~552 words

WARNING

WARNINGTHIS VEHICLE CONTAINS MERCURY ADDED DEVICES ADDED BY THE MANUFACTURER: REAR SEAT VIDEO DISPLAY. REMOVE DEVICES BEFORE VEHICLE DISPOSAL. UPON REMOVAL OF DEVICES, PLEASE REUSE, RECYCLE, OR DISPOSE OF AS HAZARDOUS WASTE.

INTERMEZZO

  1. Remove the rear floor stowage tray.
  2. Remove the three mounting fasteners. (Scheme 15)
  3. Disconnect wire harness connectors and remove amplifier. (Scheme 15)

Scheme 15

Scheme 15
Scheme 15

BASE

  1. Connect electrical harness connectors and position amplifier.
  2. Install and tighten mounting fasteners.
  3. Close door covering jack and amplifier.
  4. Raise seat into position.
  5. Connect battery negative cable.
  1. Connect electrical harness connectors and install amplifier.
  2. Install and tighten mounting fasteners.
  3. Install the rear floor stowage tray «(Refer to BODY/INTERIOR/REAR FLOOR STOWAGE TRAY - INSTALLATION)»(ref-245423-S35627395362006110200000) .
  4. Connect the battery negative cable.

Scheme 16

Scheme 16: REMOVAL
Scheme 16: REMOVAL

Scheme 17

Scheme 17
Scheme 17
  1. Disconnect and isolate the battery negative cable.
  2. Remove right side A-pillar trim «(Refer to BODY/INTERIOR/A-PILLAR TRIM - REMOVAL)»(ref-245423-S42474878462006110200000).
  3. Remove headliner to access antenna cable «(Refer to BODY/INTERIOR/HEADLINER - REMOVAL)»(ref-245423-S08364243672006110200000).
  4. Disconnect electrical harness connector and antenna from antenna module. (Scheme 16)
  5. Remove antenna cable from roof panel.
  6. Under the right side of the instrument panel, disconnect the electrical harness connector and antenna cable from the instrument panel antenna cable. (Scheme 17)
  7. Remove antenna cable from vehicle.

INFINITY

The Infinity speaker system includes seven speakers in five locations. One 8.8 centimeter (3.5 inch) speaker located in the center of the instrument panel. One 16.5 centimeter (6.5 inch) speaker and one 2.5 centimeter (1 inch) tweeter is located in each front door. There is also one 16.5 centimeter (6.5 inch) diameter speaker located in each rear door.

INFINITY INTERMEZZO

The optional Infinity Intermezzo speaker system features eight speakers in six locations. One 8.8 centimeter (3.5 inch) speaker located in the center of the instrument panel. One 16.5 centimeter (6.5 inch) speaker and one 2.5 centimeter (1 inch) tweeter is located in each front door. There is also one 16.5 centimeter (6.5 inch) diameter speaker located in each rear door. The premium speaker system also includes a 20 centimeter (8 inch) subwoofer located in the rear of the vehicle.

SUBWOOFER

  1. Disconnect and isolate the battery negative cable.
  2. Using a trim stick (Special tool C-4755) or equivalent, carefully pry at the rear of the speaker grille and remove.
  3. Remove mounting fasteners.
  4. Disconnect wire harness connectors and remove speaker.

Scheme 18

Scheme 18: TWEETER
Scheme 18: TWEETER
  1. Disconnect and isolate the battery negative cable.
  2. Remove the front door trim panel «(Refer to BODY/DOOR - FRONT/TRIM PANEL - REMOVAL)»(ref-245423-S16680146352006110200000).
  3. Remove mounting fasteners.
  4. Disconnect wire harness connector and remove speaker. (Scheme 18)

FRONT DOOR SPEAKER

  1. Connect electrical harness connector and position speaker to door.
  2. Install mounting fasteners. Tighten to 3 N.m (28 in. lbs.).
  3. Install front door trim panel «(Refer to BODY/DOOR - FRONT/TRIM PANEL - INSTALLATION)»(ref-245423-S26865939162006110200000) .
  4. Connect battery negative cable.

INSTRUMENT PANEL SPEAKER

  1. Connect electrical harness connector and position speaker to instrument panel.
  2. Install mounting fasteners. Tighten to 3 N.m (28 in. lbs.).
  3. Install speaker grill.
  4. Connect battery negative cable.

REAR DOOR SPEAKER

  1. Connect electrical harness connector and position speaker to door.
  2. Install mounting fasteners. Tighten to 3 N.m (28 in. lbs.).
  3. Install rear door trim panel «(Refer to BODY/DOORS - REAR/TRIM PANEL - INSTALLATION)»(ref-245423-S19646409282006110200000) .
  4. Connect battery negative cable.
  1. Connect wire harness connectors and install speaker.
  2. Install mounting fasteners. Tighten to 3 N.m (28 in. lbs.).
  3. Install speaker grille.
  4. Connect battery negative cable.

TWEETER

  1. Install tweeter to door trim panel.
  2. Install mounting fasteners. Tighten to 3 N.m (28 in. lbs.).
  3. Install front door trim panel «(Refer to BODY/DOOR - FRONT/TRIM PANEL - INSTALLATION)»(ref-245423-S26865939162006110200000) .
  4. Connect battery negative cable.
