Audio System & Video System: Removal & Installation Chrysler Pacifica CS

Entertainment Systems 2 illustrations ~872 words

INSTALLATION

  1. Position antenna cable in vehicle.
  2. Install antenna cable to roof panel.
  3. Connect electrical harness connector and antenna to antenna module.
  4. Route cable under instrument panel. Connect electrical harness connector and antenna cable to instrument panel cable and connector.
  5. Install headliner «(Refer to BODY/INTERIOR/HEADLINER - INSTALLATION)»(ref-245423-S31913720812006110200000) .
  6. Install A-pillar trim «(Refer to BODY/INTERIOR/A-PILLAR TRIM - INSTALLATION)»(ref-245423-S35806670822006110200000) .
  7. Connect battery negative cable.
  1. Install the antenna module and the mounting fastener. Tighten to 8.5 N.m (75 in. lbs.).
  2. Connect the antenna connector to the quarter glass.
  3. Connect the antenna lead and electrical connector to the antenna module.
  4. Install headliner «(Refer to BODY/INTERIOR/HEADLINER - INSTALLATION)»(ref-245423-S31913720812006110200000) .
  5. Connect the battery negative cable.
  1. Insert wire harness through hole in roof panel. Press antenna into position until both retainers snap into place.
  2. Install and tighten mounting fastener.
  3. Connect antenna cable connectors to antenna.
  4. Install headliner.
  5. Connect battery negative cable.
  1. Connect the wire connector to the CD/DVD changer.
  2. Insert the CD/DVD changer into the instrument panel. NOTE: Use care when inserting CD/DVD changer so that cable is not pinched or trapped against instrument panel.
  3. Install CD/DVD changer mounting fasteners. Tighten to 2 N.m (22 in. lbs.).
  4. Install instrument panel center bezel «(Refer to BODY/INSTRUMENT PANEL/INSTRUMENT PANEL CENTER BEZEL - INSTALLATION)»(ref-245423-S12488567262006110200000) .
  5. Connect the battery negative cable.

Scheme 13

Scheme 13: REMOVAL
Scheme 13: REMOVAL
WARNINGON VEHICLES EQUIPPED WITH AIRBAGS, REFER TO RESTRAINTS BEFORE ATTEMPTING ANY STEERING WHEEL, STEERING COLUMN, OR INSTRUMENT PANEL COMPONENT DIAGNOSIS OR SERVICE. FAILURE TO TAKE THE PROPER PRECAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT AND POSSIBLE PERSONAL INJURY.
  1. Disconnect and isolate the battery negative cable.
  2. Remove glove box.
  3. Disconnect instrument panel antenna cable from antenna cable.
  4. Disconnect cable hanger clip from HVAC unit.
  5. Remove radio «(Refer to ELECTRICAL/AUDIO/RADIO - REMOVAL)»(ref-245447-S19212888072006110200000).
  6. Disconnect the antenna cable by pulling the locking antenna connector away from the radio. (Scheme 13)
  7. Remove cable from vehicle.
  1. Install instrument panel antenna cable to vehicle.
  2. Connect cable to back of radio.
  3. Install radio «(Refer to ELECTRICAL/AUDIO/RADIO - INSTALLATION)»(ref-245447-S02988664882006110200000) .
  4. Connect cable hanger clip to HVAC unit.
  5. Connect instrument panel antenna cable to antenna cable.
  6. Install glove box.
  7. Connect the battery negative cable.
  1. Connect wire harness connector and antenna cable to back of radio.
  2. Position radio into instrument panel.
  3. Install mounting screws. Tighten to 2 N.m (22 in. lbs.).
  4. Install instrument panel center bezel «(Refer to BODY/INSTRUMENT PANEL/INSTRUMENT PANEL CENTER BEZEL - INSTALLATION)»(ref-245423-S12488567262006110200000) .
  5. Connect battery negative cable.
  1. Position ground strap and install mounting fasteners.
  2. Connect battery negative cable.

REMOVAL

Note. If the owner's satellite service was active before the satellite receiver was replaced the new satellite receiver will have to be activated. The existing satellite receiver will have to be deactivated before the replacement satellite receiver can be activated. To activate Sirius satellite radio service, call Sirius at their toll-free number. Please have the following information available when activating a system: Electronic Serial Number / Sirius Identification Number (ESN/SID) of the unit to be replaced ESN/SID of the replacement receiver Vehicle Owner's name and address VIN The ESN/SID number can be obtained through the radio display by following the steps in the satellite radio owners manual. The vehicle must be outside with the audio system powered on, in the satellite radio mode, to receive the activation signal.

Scheme 14

Scheme 14: REMOVAL
Scheme 14: REMOVAL
  1. Disconnect and isolate the battery negative cable.
  2. Lift the lid on the rear storage bin.
  3. Depress the inboard retaining tab on the module cover and pull up. (Scheme 14)
  4. Disconnect electrical harness connectors.
  5. Disconnect antenna harness connectors.
  6. Remove mounting fasteners and module.

Note. If the owner's satellite service was active before the satellite receiver was replaced the new satellite receiver will have to be activated. The existing satellite receiver will have to be deactivated before the replacement satellite receiver can be activated. To activate Sirius satellite radio service, call Sirius at their toll-free number. Please have the following information available when activating a system: Electronic Serial Number / Sirius Identification Number (ESN/SID) of the unit to be replaced ESN/SID of the replacement receiver Vehicle Owner's name and address VIN The ESN/SID number can be obtained through the radio display by following the steps in the satellite radio owners manual. The vehicle must be outside with the audio system powered on, in the satellite radio mode, to receive the activation signal.

  1. Position module to cover.
  2. Install and tighten mounting fasteners.
  3. Connect antenna harness connectors.
  4. Connect electrical harness connectors.
  5. Snap cover into place.
  6. Connect battery negative cable.
WARNINGON VEHICLES EQUIPPED WITH AIRBAGS, REFER TO RESTRAINTS BEFORE ATTEMPTING ANY STEERING WHEEL, STEERING COLUMN, OR INSTRUMENT PANEL COMPONENT DIAGNOSIS OR SERVICE. FAILURE TO TAKE THE PROPER PRECAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT AND POSSIBLE PERSONAL INJURY.
  1. Disconnect and isolate the battery negative cable.
  2. Remove the driver side airbag «(Refer to ELECTRICAL/RESTRAINTS/DRIVER AIRBAG - REMOVAL)»(ref-245421-S05442982652006110200000) .
  3. Remove the steering wheel «(Refer to STEERING/COLUMN/STEERING WHEEL - REMOVAL)»(ref-245433-S29364099082006110200000) .
  4. Unplug the wire harness connector from the remote radio switch (s).
  5. Remove steering wheel rear cover.
  6. Remove the remote radio switch from the steering wheel by depressing tabs on each side of each switch.

Note. The right remote radio switch back is white in color. The left switch back is black in color. The right/left remote radio switch orientation is with the steering wheel installed, and driver in drivers seat.

WARNINGON VEHICLES EQUIPPED WITH AIRBAGS, REFER TO RESTRAINTS BEFORE ATTEMPTING ANY STEERING WHEEL, STEERING COLUMN, OR INSTRUMENT PANEL COMPONENT DIAGNOSIS OR SERVICE. FAILURE TO TAKE THE PROPER PRECAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT AND POSSIBLE PERSONAL INJURY.
  1. Install remote radio switch to the steering wheel.
  2. Install steering wheel rear cover.
  3. Connect the wire harness to the remote radio switch.
  4. Install the steering wheel «(Refer to STEERING/COLUMN/STEERING WHEEL - INSTALLATION)»(ref-245433-S27856817162006110200000) .
  5. Install the driver side airbag «(Refer to ELECTRICAL/RESTRAINTS/DRIVER AIRBAG - INSTALLATION)»(ref-245421-S41927602382006110200000) .
  6. Connect the battery negative cable.
  1. Connect wire harness connector and place video screen into position.
  2. Install mounting fasteners. Tighten to 5 N.m (47 in. lbs.).
  3. Connect the battery negative cable.

More articles — Audio System & Video System
