BATTERY SPECIFICATIONS
| Application & Group | Cold Cranking Amps |
|---|
| Avenger & Sebring Coupe |
| 2.0L |
| A/T (Group 86) | 525 |
| M/T (Group 86) | 430 |
| 2.5L (Group 86) | 525 |
| Breeze, Cirrus & Stratus (Group 75) | 510 |
| Concorde, Intrepid, LHS & 300M |
| 2.7L (Group 34) | 600 |
| 3.2L & 3.5L (Group 34) | 685 |
| Neon (Group 58) | 450 |
| Sebring Convertible (Group 75) | 510 |
FLUID CAPACITIES (AVENGER & SEBRING COUPE)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 2.0L & 2.5L | 4.5 Qts. (4.3L) |
| Cooling System (3) | 7.4 Qts. (7.0L) |
| Automatic Transaxle (4) |
| Drain & Refill | (5) 4.0 Qts. (3.8L) |
| Dry Refill | 9.1 Qts. (8.6L) |
| Manual Transaxle (6) | 2.1 Qts. (1.9L) |
| Power Steering Fluid (4) | 1.9 Pts. (.9L) |
| (1) Approximate quantity listed. (2) Use an API engine oil that is certified for gasoline engines on all engines. (3) Quantity includes heater and coolant recovery tank. (4) Mopar ATF Plus Type 7176 (5) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. (6) Use only Mopar MS9417 manual transaxle fluid. |
| (1) | Approximate quantity listed. |
| (2) | Use an API engine oil that is certified for gasoline engines on all engines. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Mopar ATF Plus Type 7176 |
| (5) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (6) | Use only Mopar MS9417 manual transaxle fluid. |
FLUID CAPACITIES (AVENGER & SEBRING COUPE)
FLUID CAPACITIES (BREEZE, CIRRUS & STRATUS)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| Breeze |
| 2.0L | 4.5 Qts. (4.3L) |
| 2.4L | 5.0 Qts. (4.7L) |
| Cirrus |
| 2.5L | 4.5 Qts. (4.3L) |
| Stratus |
| 2.0L | 4.5 Qts. (4.3L) |
| 2.4L | 5.0 Qts. (4.7L) |
| 2.5L | 4.5 Qts. (4.3L) |
| Cooling System (3) |
| Breeze |
| 2.0L | 8.5 Qts. (8.0L) |
| 2.4L | 9.0 Qts. (8.5L) |
| Cirrus |
| 2.5L | 10.5 Qts. (10.0L) |
| Stratus |
| 2.0L | 8.5 Qts. (8.0L) |
| 2.4L | 9.0 Qts. (8.5L) |
| 2.5L | 10.5 Qts. (10.0L) |
| Automatic Transaxle (Mopar ATF Plus Type 7176) |
| Drain & Refill | (4) 4.0 Qts. (3.8L) |
| Dry Refill | 9.1 Qts. (8.6L) |
| Manual Transaxle (5) |
| Breeze & Stratus | 2.2 Qts. (2.1L) |
| Power Steering Fluid (6) | (7) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines. (3) Quantity includes heater and coolant recovery tank. (4) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. (5) Use only Mopar MS9417 manual transaxle fluid. (6) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. (7) Capacity is not available from manufacturer. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (5) | Use only Mopar MS9417 manual transaxle fluid. |
| (6) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (7) | Capacity is not available from manufacturer. |
FLUID CAPACITIES (BREEZE, CIRRUS & STRATUS)
FLUID CAPACITIES (CONCORDE, INTREPID, LHS & 300M)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 2.7L, 3.2L & 3.5L | 5.0 Qts. (4.7L) |
| Cooling System (3) |
| 2.7L, 3.2L & 3.5L | 9.4 Qts. (8.9L) |
| Automatic Transaxle (Mopar ATF Plus Type 7176) |
| Drain & Refill | (4) 4.5 Qts. (4.3L) |
| Dry Refill | 9.9 Qts. (9.4L) |
| Differential (5) | 1.0 Qt. (.95L) |
| Power Steering Fluid (6) | (7) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines. (3) Quantity includes heater and coolant recovery tank. (4) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/4" above the bottom hole on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. (5) Differential has a separate sump from the automatic transaxle. Use Mopar Fuel Savings 75W-90 petroleum based hypoid gear oil. DO NOT use synthetic gear oil in differential. (6) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. (7) Capacity is not available from manufacturer. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/4" above the bottom hole on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (5) | Differential has a separate sump from the automatic transaxle. Use Mopar Fuel Savings 75W-90 petroleum based hypoid gear oil. DO NOT use synthetic gear oil in differential. |
| (6) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (7) | Capacity is not available from manufacturer. |
FLUID CAPACITIES (CONCORDE, INTREPID, LHS & 300M)
FLUID CAPACITIES (NEON)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 2.0L DOHC & SOHC | 4.5 Qts. (4.3L) |
| Cooling System (3) |
| 2.0L DOHC & SOHC |
| With A/C | 7.0 Qts. (6.5L) |
| Without A/C | 6.5 Qts. (6.1L) |
| Automatic Transaxle (Mopar ATF Plus Type 7176) |
| Drain & Refill | (4) 4.0 Qts. (3.8L) |
| Dry Refill | 8.9 Qts. (8.4L) |
| Manual Transaxle (5) | 2.1 Qts. (1.9L) |
| Power Steering Fluid (6) | 1.0 Qt. (.95L) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines. (3) Quantity includes heater and coolant recovery tank. (4) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. (5) Use only Mopar MS9417 manual transaxle fluid. (6) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (5) | Use only Mopar MS9417 manual transaxle fluid. |
| (6) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
FLUID CAPACITIES (SEBRING CONVERTIBLE)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 2.4L | 5.0 Qts. (4.7L) |
| 2.5L | 4.5 Qts. (4.3L) |
| Cooling System (3) |
| 2.4L | 9.0 Qts. (8.5L) |
| 2.5L | 10.5 Qts. (10.0L) |
| Automatic Transaxle (Mopar ATF Plus Type 7176) |
| Drain & Refill | (4) 4.0 Qts. (3.8L) |
| Dry Refill | 9.1 Qts. (8.6L) |
| Power Steering Fluid (5) | (6) |
| (1) Approximate quantity listed. (2) Use an API engine oil that is certified for gasoline engines on all engines. (3) Quantity includes heater and coolant recovery tank. (4) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. (5) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. (6) Capacity is not available from manufacturer. |
| (1) | Approximate quantity listed. |
| (2) | Use an API engine oil that is certified for gasoline engines on all engines. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (5) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (6) | Capacity is not available from manufacturer. |
FLUID CAPACITIES (SEBRING CONVERTIBLE)
4-CYLINDER COMPRESSION SPECIFICATIONS
| Application | Specification |
|---|
| Compression Ratio |
| Avenger & Sebring Coupe |
| 2.0L | 9.6:1 |
| Breeze & Stratus |
| 2.0L | 9.8:1 |
| 2.4L | 9.4:1 |
| Neon |
| 2.0L DOHC | 9.6:1 |
| 2.0L SOHC | 9.8:1 |
| Sebring Convertible |
| 2.4L | 9.4:1 |
| Normal Compression Pressure |
| Avenger & Sebring Coupe |
| 2.0L | 170-225 psi (12-16 kg/cm 2 ) |
| Breeze & Stratus |
| 2.0L & 2.4L | 170-225 psi (12-16 kg/cm 2 ) |
| Neon |
| 2.0L DOHC & SOHC | 170-225 psi (12-16 kg/cm 2 ) |
| Sebring Convertible |
| 2.4L | 170-225 psi (12-16 kg/cm 2 ) |
| Minimum Compression Pressure |
| Avenger & Sebring Coupe |
| 2.0L | 100 psi (7 kg/cm 2) ) |
| Breeze & Stratus |
| 2.0L & 2.4L | 100 psi (7 kg/cm 2) ) |
| Neon |
| 2.0L DOHC & SOHC | 100 psi (7 kg/cm 2) ) |
| Sebring Convertible |
| 2.4L | 100 psi (7 kg/cm 2) ) |
| Maximum Variation Between Cylinders |
| All Models | (1) |
| (1) Maximum variation between cylinders is 25 percent. |
| (1) | Maximum variation between cylinders is 25 percent. |
4-CYLINDER COMPRESSION SPECIFICATIONS
V6 COMPRESSION SPECIFICATIONS
| Application | Specification |
|---|
| Compression Ratio |
| Avenger & Sebring Coupe |
| 2.5L |
| Calif. Emission Vehicles | 9.0:1 |
| Except Calif. Emission Vehicles | 9.4:1 |
| Cirrus & Stratus |
| 2.5L | 9.4:1 |
| Concorde, Intrepid, LHS & 300M |
| 2.7L | 9.7:1 |
| 3.2L & 3.5L | 9.5:1 |
| Sebring Convertible |
| 2.5L | 9.4:1 |
| Normal Compression Pressure |
| Avenger & Sebring Coupe |
| 2.5L |
| Calif. Emission Vehicles | 202 psi (14 kg/cm 2 ) |
| Except Calif. Emission Vehicles | 211 psi (15 kg/cm 2 ) |
| Cirrus & Stratus |
| 2.5L | 178 psi (13 kg/cm 2 ) |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | (1) |
| Sebring Convertible |
| 2.5L | 178 psi (13 kg/cm 2 ) |
| Minimum Compression Pressure |
| Avenger & Sebring Coupe |
| 2.5L |
| Calif. Emission Vehicles | 154 psi (11 kg/cm 2 ) |
| Except Calif. Emission Vehicles | 192 psi (13 kg/cm 2 ) |
| Cirrus & Stratus |
| 2.5L | 100 psi (7 kg/cm 2) ) |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | 100 psi (7 kg/cm 2) ) |
| Sebring Convertible |
| 2.5L | 100 psi (7 kg/cm 2) ) |
| Maximum Variation Between Cylinders |
| Avenger & Sebring Coupe |
| 2.5L | 14 psi (1 kg/cm 2 ) |
| Cirrus & Stratus |
| 2.5L | (2) |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | (2) |
| Sebring Convertible |
| 2.5L | (2) |
| (1) Information is not available from manufacturer. (2) Maximum variation between cylinders is 25 percent. |
| (1) | Information is not available from manufacturer. |
| (2) | Maximum variation between cylinders is 25 percent. |
V6 COMPRESSION SPECIFICATIONS
4-CYLINDER SPARK PLUG SPECIFICATIONS
| Application | Gap In. (mm) | Torque Ft. Lbs. (N.m) |
|---|
| Avenger & Sebring Coupe |
| 2.0L | .048-.053 (1.22-1.35) | 20 (27) |
| Breeze & Stratus |
| 2.0L | .033-.038 (.84-.97) | 20 (27) |
| 2.4L | .048-.053 (1.22-1.35) | 20 (27) |
| Neon |
| 2.0L DOHC & SOHC | .033-.038 (.84-.97) | 20 (27) |
| Sebring Convertible |
| 2.4L | .048-.053 (1.22-1.35) | 20 (27) |
| (1) Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
| (1) | Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
4-CYLINDER SPARK PLUG SPECIFICATIONS (1)
V6 SPARK PLUG SPECIFICATIONS
| Application | Gap In. (mm) | Torque Ft. Lbs. (N.m) |
|---|
| Avenger & Sebring Coupe |
| 2.5L | .039-.043 (1.00-1.10) | 18 (24) |
| Cirrus & Stratus |
| 2.5L | .038-.043 (.97-1.10) | 20 (27) |
| Concorde, Intrepid, LHS & 300M |
| 2.7L | .048-.058 (1.22-1.47) | 13 (18) |
| 3.2L & 3.5L | .048-.053 (1.22-1.35) | 20 (27) |
| Sebring Convertible |
| 2.5L | .038-.043 (.97-1.10) | 20 (27) |
| (1) Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
| (1) | Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
V6 SPARK PLUG SPECIFICATIONS (1)
Engine Firing Order (2.0L & 2.4L - Avenger, Breeze, Neon, Sebring Convertible, Sebring Coupe & Stratus). Scheme 1
Scheme 1: Engine Firing Order (2.0L & 2.4L - Avenger, Breeze, Neon, Sebring Convertible, Sebring Coupe & Stratus)
Scheme 2
Scheme 2: Engine Firing Order (2.5L - Avenger, Cirrus, Sebring Convertible, Sebring Coupe & Stratus)
Scheme 3
Scheme 3: Engine Firing Order (2.7L, 3.2L & 3.5L - Concorde, Intrepid, LHS & 300M)
4-CYLINDER THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED SPECIFICATIONS
| Application | RPM |
|---|
| Avenger & Sebring Coupe |
| 2.0L (1) |
| 1000 Miles Or Less | (2) 450-1100 |
| More Than 1000 Miles | (2) 500-1100 |
| Breeze & Stratus |
| 2.0L & 2.4L (1) |
| 1000 Miles Or Less | (2) 550-1300 |
| More Than 1000 Miles | (2) 600-1300 |
| Neon |
| 2.0L (DOHC & SOHC) (1) |
| 1000 Miles Or Less | (2) 550-1300 |
| More Than 1000 Miles | (2) 600-1300 |
| Sebring Convertible |
| 2.4L (1) |
| 1000 Miles Or Less | (2) 550-1300 |
| More Than 1000 Miles | (2) 600-1300 |
| (1) Specification listed in accordance with vehicle mileage. (2) Specification listed with Air Metering Fitting (6457) installed. |
| (1) | Specification listed in accordance with vehicle mileage. |
| (2) | Specification listed with Air Metering Fitting (6457) installed. |
4-CYLINDER THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED SPECIFICATIONS
V6 THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED SPECIFICATIONS
| Application | RPM |
|---|
| Avenger & Sebring Coupe |
| 2.5L (1) |
| 1000 Miles Or Less | (2) 450-1100 |
| More Than 1000 Miles | (2) 500-1100 |
| Cirrus & Stratus |
| 2.5L (1) |
| 1000 Miles Or Less | (2) 450-1100 |
| More Than 1000 Miles | (2) 500-1100 |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | (2) 350-700 |
| Sebring Convertible |
| 2.5L (1) |
| 1000 Miles Or Less | (2) 450-1100 |
| More Than 1000 Miles | (2) 500-1100 |
| (1) Specification listed in accordance with vehicle mileage. (2) Specification listed with Air Metering Fitting (6457) installed. |
| (1) | Specification listed in accordance with vehicle mileage. |
| (2) | Specification listed with Air Metering Fitting (6457) installed. |
V6 THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED SPECIFICATIONS
4-CYLINDER THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
| Application & Throttle Opening | (1) (2) Volts |
|---|
| Avenger & Sebring Coupe |
| 2.0L | (3) |
| Breeze & Stratus |
| 2.0L & 2.4L |
| At Idle | Greater Than .6 |
| At Full Throttle | Less Than 4.5 |
| Neon |
| 2.0L DOHC & SOHC |
| At Idle | .38-1.20 |
| At Full Throttle | 3.1-4.4 |
| Sebring Convertible |
| 2.4L |
| At Idle | Greater Than .6 |
| At Full Throttle | Less Than 4.5 |
| (1) Measure voltage at center terminal on throttle position sensor with ignition on. (2) Voltage should increase smoothly when moving th from idle to full throttle. (3) Information is not available from manufacturer. |
| (1) | Measure voltage at center terminal on throttle position sensor with ignition on. |
| (2) | Voltage should increase smoothly when moving th from idle to full throttle. |
| (3) | Information is not available from manufacturer. |
4-CYLINDER THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
V6 THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
| Application & Throttle Opening | (1) (2) Volts |
|---|
| Avenger & Sebring Coupe |
| 2.5L | (3) |
| Cirrus & Stratus |
| 2.5L |
| At Idle | Greater Than .6 |
| At Full Throttle | Less Than 4.5 |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L |
| At Idle | Greater Than .6 |
| At Full Throttle | Less Than 4.5 |
| Sebring Convertible |
| 2.5L |
| At Idle | Greater Than .6 |
| At Full Throttle | Less Than 4.5 |
| (1) Measure voltage at center terminal on throttle position sensor with ignition on. (2) Voltage should smoothly increase when moving throttle from idle to full throttle. (3) Using scan tool, reading should be 400 mV (at idle) to 3800 mV (at full throttle). |
| (1) | Measure voltage at center terminal on throttle position sensor with ignition on. |
| (2) | Voltage should smoothly increase when moving throttle from idle to full throttle. |
| (3) | Using scan tool, reading should be 400 mV (at idle) to 3800 mV (at full throttle). |
V6 THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
