Lighting Systems - Interior - Service Information: Specifications Chrysler Crossfire I

Interior/illumination Lights 4 illustrations ~132 words

SPECIFICATIONS - INTERIOR LAMPS

CAUTIONDo not use bulbs other than those listed in BULB APPLICATION TABLE . Damage to lamp can result.
LAMPBULB
Cargo LampC5W
Cluster Illumination12/2W 1K
12/1.5W
Courtesy LampC5W
Glove Box LampC5W
Heater Switch IlluminationLED
Shift Lever Assembly Switch IlluminationLED

BULB APPLICATION TABLE

Scheme 21

Scheme 21: REMOVAL
Scheme 21: REMOVAL

Scheme 22

Scheme 22
Scheme 22
  1. Disconnect the negative battery cable.
  2. Remove the cargo lamp unit (1) from the interior trim panel. «(Refer to ELECTRICAL/LAMPS/LIGHTING - INTERIOR/CARGO LAMP UNIT - REMOVAL)»(ref-250672-S18606268202007031500000) .
  3. Remove the bulb (1) from the cargo lamp unit (2).

Scheme 23

Scheme 23: INSTALLATION
Scheme 23: INSTALLATION
  1. Insert the bulb (1) into the cargo lamp unit (2).
  2. Install the cargo lamp unit (2) to the cargo area interior trim panel (3). «(Refer to ELECTRICAL/LAMPS/LIGHTING - INTERIOR/CARGO LAMP UNIT - INSTALLATION)»(ref-250672-S32762643212007031500000) .
  3. Connect the negative battery cable.

Scheme 24

Scheme 24
Scheme 24
  1. Disconnect the negative battery cable.
  2. Gently pry the cargo lamp unit (1) away from the cargo area interior trim panel (2).
  3. Disconnect the cargo lamp unit harness connector (1) and remove from the vehicle.
