1. Connect the harness connector (1) to the cargo lamp unit.
2. Install the cargo lamp unit to the cargo area interior trim panel (2).
3. Connect the negative battery cable.

Scheme 32

1. Remove the courtesy lamp switch/unit from the roof frame. «(Refer to ELECTRICAL/LAMPS/LIGHTING - INTERIOR/COURTESY LAMP SWITCH - REMOVAL)»(ref-250672-S29924813822007031500000) .
2. Rotate the lamp socket (1) counterclockwise in the courtesy lamp switch/unit and remove.
3. Remove the bulb from the lamp socket.

Scheme 33

1. Insert the bulb into the lamp socket.
2. Install the lamp socket into the courtesy lamp switch/unit by rotating clockwise.
3. Install the courtesy lamp switch/unit to the roof frame. «(Refer to ELECTRICAL/LAMPS/LIGHTING - INTERIOR/COURTESY LAMP SWITCH - INSTALLATION)»(ref-250672-S20173258152007031500000) .

Scheme 34

With the courtesy lamp defeat switch in the "O" position (1), the courtesy lamps are prevented from illuminating when the doors are opened. With the courtesy lamp defeat switch in the "-" position, the courtesy lamps illuminate when the doors are opened, then fade to off approximately 8 seconds after the last door is closed (unless the courtesy lamp switch is depressed). If a door remains unclosed, the lamps will remain on for approximately 5 minutes. At this time the Body Control Module will interrupt the ground path to conserve battery power. The courtesy lamp defeat switch is an integrated part of the courtesy lamp unit assembly and cannot be adjusted or repaired. If faulty, worn, or damaged, the entire assembly must be replaced. For complete courtesy lamp unit removal procedures, refer to REMOVAL .

Scheme 35

The courtesy lamps (1) provide overhead interior illumination when the doors are opened and the courtesy lamp defeat switch (3) is in the "-" position, or when the courtesy lamp switch (2) is pressed. The courtesy lamp defeat switch (3) can prevent the courtesy lamps operation when the doors are opened if the "O" position is selected. The courtesy lamp switch/unit cannot be adjusted or repaired. If faulty, worn, or damaged, the entire assembly must be replaced. For complete courtesy lamp switch/unit removal procedures, refer to REMOVAL .

INSTALLATION - LIFTGATE AJAR SWITCH

The liftgate ajar switch is an integral part of the liftgate handle assembly. For complete liftgate handle installation procedures, (Refer to BODY/DECKLID/HATCH/LIFTGATE/TAILGATE/EXTERIOR HANDLE - INSTALLATION) .

REMOVAL

Scheme 36

1. Remove the glove box lamp/switch assembly. «(Refer to ELECTRICAL/LAMPS/LIGHTING - INTERIOR/GLOVE BOX LAMP/SWITCH - REMOVAL)»(ref-250672-S05946465742007031500000) .
2. Press the bulb retaining arm aside and remove the bulb (1) from the glove box lamp/switch (2).

Scheme 37

1. Press the bulb retaining arm (2) aside and install the bulb (1) into the glove box lamp/switch assembly.
2. Install the glove box lamp/switch assembly. «(Refer to ELECTRICAL/LAMPS/LIGHTING - INTERIOR/GLOVE BOX LAMP/SWITCH - INSTALLATION)»(ref-250672-S27664003922007031500000) .

Scheme 38

The glove box lamp/switch (1) is a self-contained set of switches, lamp, and housing assembly that provides illumination into the glove box compartment whenever the glove box door is opened. It is located behind the glove box door at the top of the liner, just to the left of the latch striker.

Scheme 39

1. Disconnect the negative battery cable.
2. Open the glove box door and depress the lens retaining clips with a trim stick (1). Gently pry the glove box lamp/switch (2) from the glove box liner (3).
3. Disconnect the glove box lamp/switch harness connector and remove the glove box lamp/switch (2) from the vehicle.

Scheme 40

1. Connect the glove box lamp/switch harness connector (1).
2. Insert the glove box lamp/switch (2) into the opening in the glove box liner and close the glove box door.
3. Connect the negative battery cable.

Scheme 41

The Heater Switch (3) is illuminated with LEDs whenever the headlamps or marker lamps are on. The lamp brightness is adjustable with the dimmer switch located in the Instrument Cluster. The heater switch LEDs cannot be adjusted or repaired. If faulty or damaged, the entire Heater Switch Assembly must be replaced as a unit. For complete Heater Switch removal procedures, (Refer to HEATING & AIR CONDITIONING/CONTROLS/HEATER CONTROL - REMOVAL) .

Scheme 42

The transmission range indicator is illuminated with LEDs whenever the headlamps or marker lamps are on. The lamp brightness is adjustable with the dimmer switch located in the instrument cluster. The transmission range indicator LEDs cannot be adjusted or repaired. If faulty or damaged, the entire transmission range indicator assembly must be replaced as a unit. For complete transmission range indicator removal procedures, (Refer to TRANSMISSION/TRANSAXLE/AUTOMATIC - NAG1/SHIFT MECHANISM - REMOVAL) .

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. Remove the cover on the center console. «(Refer to BODY/INTERIOR/CENTER CONSOLE - REMOVAL)»(ref-250612-S17954963242007031500000) .
2. Remove the screws (1-3) attaching the ashtray (2) to the center console.
3. Press the ashtray housing (1) to the left and remove it toward the right (arrows).
4. Disconnect the ashtray harness connector for the courtesy lamp on the back of the ashtray (1).
5. Remove the ashtray lamp from the ashtray harness connector.

1. Install the ashtray lamp into the ashtray lamp harness connector.
2. Connect the ashtray lamp harness connector to the ashtray (1).
3. Install the ashtray housing (1) to the right and push it toward the left.
4. Install the screws (1-3) attaching the ashtray (2) to the center console.
5. Install the cover (1) on the center console. «(Refer to BODY/INTERIOR/CENTER CONSOLE - INSTALLATION)»(ref-250612-S32158713072007031500000) .
