OPERATION

Non-switched power is supplied through Fuse 9 in the Underhood Accessory Fuse Block, and ground is provided by the Body Control Module. Regardless of the ignition switch position, the courtesy lamps illuminate when either door is opened if the courtesy lamp defeat switch is in the "-" position; or the courtesy lamp switch is pressed. The courtesy lamps will fade off approximately 8 seconds after the last door is closed. If a door remains unclosed, the lamps will remain on for approximately 5 minutes. At this time the Body Control Module will interrupt the ground path to conserve battery power.

When the courtesy lamp switch is pressed, the courtesy lamps are provided a direct path to ground and will remain illuminated until the switch is pressed again.

Scheme 25

Scheme 26

1. Disconnect the negative battery cable.
2. Using a trim stick (1), gently pry down and away from the courtesy lamp switch/unit body (2) to release the lens cover.
3. Remove the retaining screws.
4. Using a trim stick, gently pry and lower the courtesy lamp switch/unit from the headliner opening.
5. Disconnect the courtesy lamp switch/unit harness connector and remove from the vehicle.

Scheme 27

1. Connect the courtesy lamp switch/unit harness connector (1) and align into the headliner opening.
2. Install the retaining screws and secure.
3. Install the lens cover into the courtesy lamp switch/unit body.
4. Connect the negative battery cable.

Scheme 28

The dimmer switch (3) is an integrated part of the Instrument Cluster and is located at the left side of the speedometer. It controls the brightness of the adjustable interior illumination when rotated to the left or right. The dimmer switch cannot be repaired. If it is found faulty or damaged, the entire Instrument Cluster must be replaced. For complete Instrument Cluster removal procedures, refer to REMOVAL .

DESCRIPTION

There are three door ajar switches, one at each door and one in the liftgate latch. The door switches are located in the B-pillar directly below the latch striker plate, and the liftgate switch is integral to the liftgate latch assembly. A door or body harness connector with a service loop connects each switch to the vehicle electrical system. The door ajar switches cannot be adjusted or repaired, and if faulty or damaged, the switch itself or the liftgate latch must be replaced as an assembly. For complete door ajar switch removal procedures, see REMOVAL .

The door ajar switches are actuated by either door, or the liftgate being opened. When either door or the liftgate is closed and properly latched, its ajar switch is open. When either door or the liftgate is partially latched, its ajar switch is closed. The ajar switches are connected via a harness connector to a body ground and the Central Locking Pump/Security System Module.

Scheme 29

1. Disconnect the negative battery cable.
2. Using a trim stick, press and release the retaining tab (1) at the top of the door ajar switch.
3. Pull the top of the door ajar switch out and downward away from the B-pillar (2), then disconnect the door ajar switch harness connector.

Scheme 30

The liftgate ajar switch (1) is an integral part of the liftgate handle assembly and cannot be adjusted or repaired. If faulty, worn, or damaged, the entire liftgate handle assembly must be replaced. For complete liftgate handle removal procedures, (Refer to BODY/DECKLID/HATCH/LIFTGATE/TAILGATE/EXTERIOR HANDLE - REMOVAL) .

Scheme 31

1. Connect the door ajar switch harness connector (1).
2. Install the lower edge of the door ajar switch into the B-pillar opening (2) first, then rotate upward until fully seated.
3. Connect the negative battery cable.

The Glove Box Lamp/Switch contains two separate switches; one for control of the illumination, and the other to sense the glove box door position. Power is supplied through Fuse 31 in the Underhood Accessory Fuse Block for the lamp illumination switch. The Central Locking Pump/Security System Module receives a ground signal from the second switch when the glove box is opened. Neither of these switches can be adjusted or repaired. If faulty, worn, or damaged, the entire Glove Box Lamp/Switch assembly must be replaced. For complete Glove Box Lamp/Switch removal procedures, refer to REMOVAL .
