- Remove the air cleaner and duct assembly. (Scheme 10) Drain the coolant until the coolant level is below the thermostat. See «COOLING SYSTEM BLEEDING»(ref-97376-S23037647092001050300000).
- Remove the crossover exhaust pipe. (Scheme 11) Remove the radiator hose from the thermostat housing.
- Remove the thermostat housing bolts and clean any sealer from the bolt threads. (Scheme 12) Remove the thermostat housing and gasket.
- Remove the thermostat. Inspect and clean the mating surfaces.
- Install the thermostat housing and gasket. Install RTV sealer (GM P/N 1052366) to the thermostat housing bolt threads. Install the thermostat housing bolts. See «TORQUE SPECIFICATIONS»(ref-97376-S22960383202001050300000).
- To complete installation, reverse removal procedure. Fill the cooling system. Inspect the cooling system for leaks. Repair as necessary.
