Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Air Deflector Screws | 6 N.m | 53 lb in |
| Diagonal Brace Front Bolts | 14 N.m | 124 lb in |
| Diagonal Brace Rear Bolt | 47 N.m | 35 lb ft |
| Front Fender Lower Bracket Nut | 6 N.m | 53 lb in |
| Front Fender Lower Front Bolts | 8 N.m | 71 lb in |
| Front Fender Lower Rear Bolts | 8 N.m | 71 lb in |
| Front Fender Rear Bolts | 8 N.m | 71 lb in |
| Front Fender Upper Bolts | 8 N.m | 71 lb in |
| Front Wheelhouse Liner Screws | 2 N.m | 18 lb in |
| Headlamp and Front End Fascia Mounting Panel Bolts | 12 N.m | 106 lb in |
| Headlamp and Front End Fascia Mounting Panel Outer Bracket Bolts | 12 N.m | 106 lb in |
| Hood Hinge to Hood Bolts | 25 N.m | 18 lb ft |
| Hood Hinge to Upper Fender Rail Bolts | 25 N.m | 18 lb ft |
| Hood Hold Open Rod Bracket Bolt | 10 N.m | 89 lb in |
| Hood Primary and Secondary Latch Nuts | 12 N.m | 106 lb in |
| Hood Primary Latch Bolts | 12 N.m | 106 lb in |
| Hood Release Handle Screws | 2 N.m | 18 lb in |
Fastener Tightening Specifications
Scheme 16
| Callout | Component Name |
|---|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Hood Front Bumper Replacement | |
| 1 | Bumper, Hood Front (Qty: 6) |
| Hood Adjuster Front Bumper Replacement | |
| 2 | Bumper, Hood Adjuster Front (Qty: 2) Tip: Adjust hood bumpers as necessary by turning up or down. |
Bumper, Adjuster Replacement - Hood (Chevrolet)
Scheme 17
| Callout | Component Name |
|---|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Hood Front Bumper Replacement | |
| 1 | Bumper, Hood Front (Qty: 6) |
| Hood Adjuster Front Bumper Replacement | |
| 2 | Bumper, Hood Adjuster Front (Qty: 2) Tip: Adjust hood bumpers as necessary by turning up or down. |
Bumper, Adjuster Replacement - Hood (Pontiac)
Scheme 18
| Callout | Component Name |
|---|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Hood Front Bumper Replacement | |
| 1 | Bumper, Hood Front (Qty: 6) |
| Hood Adjuster Front Bumper Replacement | |
| 2 | Bumper, Hood Adjuster Front (Qty: 2) Tip: Adjust hood bumpers as necessary by turning up or down. |
Bumper, Adjuster Replacement - Hood (Buick)
Scheme 19
| Callout | Component Name |
|---|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Hood Insulator Replacement | |
| 1 | Retainer, Hood Insulator (Qty: 4) |
| 2 | Insulator Assembly, Hood |
| Hood Rear Outer Seal Replacement | |
| 3 | Seal Assembly, Hood Rear Outer (Qty: 2) |
| Hood Rear Center Seal Replacement | |
| 4 | Seal Assembly, Hood Rear Center |
Insulator, Seal Replacement - Hood (Chevrolet)
Scheme 20
| Callout | Component Name |
|---|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Hood Insulator Replacement | |
| 1 | Retainer, Hood Insulator (Qty: 4) |
| 2 | Insulator Assembly, Hood |
| Hood Rear Outer Seal Replacement | |
| 3 | Seal Assembly, Hood Rear Outer (Qty: 2) |
| Hood Rear Center Seal Replacement | |
| 4 | Seal Assembly, Hood Rear Center |
Insulator, Seal Replacement - Hood (Pontiac)
Scheme 21
| Callout | Component Name |
|---|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Hood Insulator Replacement | |
| 1 | Retainer, Hood Insulator (Qty: 4) |
| 2 | Insulator Assembly, Hood |
| Hood Rear Outer Seal Replacement | |
| 3 | Seal Assembly, Hood Rear Outer (Qty: 2) |
| Hood Rear Center Seal Replacement | |
| 4 | Seal Assembly, Hood Rear Center |
Insulator, Seal Replacement - Hood (Buick)
