Steering Wheel Control Switch Assembly - Upper Left (STW)
| Connector Part Information OEM: 50-57-9405 Service: Service by Harness - See Part Catalog Description: 5-Way F Molex (BK) |
|---|
| Terminal Part Information Pins: 1-3, 5 Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Steering Wheel Control Switch Assembly - Upper Left (STW) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | L-GN | 1101 | 12-Volt Reference Jumper |
| 2 | BN | 230 | Instrument Panel Lamps Dimming Control |
| 3 | BK | 2250 | Ground |
| 4 | Not Used | ||
| 5 | L-GN | 1011 | Remote Radio Control Signal |
Steering Wheel Control Switch Assembly - Upper Left (STW) Connector Terminal Identification
Scheme 5
| Connector Part Information OEM: 50-57-9406 Service: Service by Harness - See Part Catalog Description: 6-Way F Molex (BK) |
|---|
| Terminal Part Information Pins: 1-3, 5-6 Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Steering Wheel Control Switch Assembly - Upper Right (STW) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | WH | 2283 | 12-Volt Reference |
| 2 | L-GN | 1101 | 12-Volt Reference Jumper |
| 3 | BN | 230 | Instrument Panel Lamps Dimming Control |
| 4 | Not Used | ||
| 5 | BK | 2250 | Ground |
| 6 | L-GN | 1011 | Remote Radio Control Signal |
Steering Wheel Control Switch Assembly - Upper Right (STW) Connector Terminal Identification
