Engine Mechanical - 4.8L, 5.3L & 6.0L: Specifications Chevrolet Suburban X

Mechanical 51 illustrations ~283 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Air Cleaner Outlet Duct Clamp7 N.m62 lb in
Air Conditioning Belt Tensioner Bolt50 N.m37 lb ft
Battery Cable Channel Bolt12 N.m106 lb in
Camshaft Retainer Bolts25 N.m18 lb ft
Camshaft Sensor Bolt25 N.m18 lb ft
Camshaft Sprocket Bolts35 N.m26 lb ft
Connecting Rod Bolts - First Pass20 N.m15 lb ft
Connecting Rod Bolts - Final Pass75 degrees
Coolant Temperature Gage Sensor20 N.m15 lb ft
Crankshaft Balancer Bolt - Installation Pass - to Ensure the Balancer is Completely Installed330 N.m240 lb ft
Crankshaft Balancer Bolt - First Pass - Install a NEW Bolt After the Installation Pass and Tighten as Described in the First and Final Passes50 N.m37 lb ft
Crankshaft Balancer Bolt - Final Pass140 degrees
Crankshaft Bearing Cap Bolts - Inner Bolts - First Pass in Sequence20 N.m15 lb ft
Crankshaft Bearing Cap Bolts - Inner Bolts - Final Pass in Sequence80 degrees
Crankshaft Bearing Cap Bolts - Outer Bolts - First Pass in Sequence 20 N.m15 lb ft
Crankshaft Bearing Cap Bolts - Outer Bolts - Final Pass in Sequence51 degrees
Crankshaft Bearing Cap Side Bolts25 N.m18 lb ft
Crankshaft Oil Deflector Nuts25 N.m18 lb ft
Crankshaft Position Sensor Bolt25 N.m18 lb ft
Crossbar Bolt100 N.m74 lb ft
Cylinder Head Bolts - First Pass all M11 Bolts in Sequence30 N.m22 lb ft
Cylinder Head Bolts - Second Pass all M11 Bolts in Sequence90 degrees
Cylinder Head Bolts - Final Pass all M11 Bolts in Sequence - Excluding the Medium Length Bolts at the Front and Rear of Each Cylinder Head90 degrees
Cylinder Head Bolts - Final Pass M11 Medium Length Bolts at Front and Rear of Each Cylinder Head in Sequence50 degrees
Cylinder Head Bolts - M8 Inner Bolts in Sequence30 N.m22 lb ft
Cylinder Head Coolant Plug20 N.m15 lb ft
Differential Carrier Lower Mounting Bolt/Nut100 N.m74 lb ft
Drive Belt Idler Pulley Bolt50 N.m37 lb ft
Drive Belt Tensioner Bolt50 N.m37 lb ft
Engine Block Coolant Drain Plugs60 N.m44 lb ft
Engine Block Heater40 N.m30 lb ft
Engine Block Oil Gallery Plugs60 N.m44 lb ft
Engine Coolant Air Bleed Pipe and Cover Bolts12 N.m106 lb in
Engine Flywheel Bolts - First Pass20 N.m15 lb ft
Engine Flywheel Bolts - Second Pass50 N.m37 lb ft
Engine Flywheel Bolts - Final Pass100 N.m74 lb ft
Engine Front Cover Bolts25 N.m18 lb ft
Engine Harness Ground Bolt - Right Rear16 N.m12 lb ft
Engine Harness Ground Bolt-to-Block25 N.m18 lb ft
Engine Mount Bolt-to-Engine Bracket50 N.m37 lb ft
Engine Mount Frame Bracket Through Bolt75 N.m55 lb ft
Engine Mount Frame Side Mount Bolt65 N.m50 lb ft
Engine Mount-to-Engine Bracket Bolt50 N.m37 lb ft
Engine Rear Cover Bolts25 N.m18 lb ft
Engine Service Lift Bracket M10 Bolts50 N.m37 lb ft
Engine Service Lift Bracket M8 Bolt25 N.m18 lb ft
Engine Shield Bolt20 N.m15 lb ft
Engine Valley Cover Bolts25 N.m18 lb ft
Engine Wiring Harness Bracket Nut5 N.m44 lb in
Evaporative Emission (EVAP) Purge Solenoid Bolt10 N.m89 lb in
Exhaust Manifold Bolts - First Pass15 N.m11 lb ft
Exhaust Manifold Bolts - Final Pass25 N.m18 lb ft
Exhaust Manifold Heat Shield Bolts9 N.m80 lb in
Fuel Rail Bolts10 N.m89 lb in
Fuel Rail Cover Bolt9 N.m80 lb in
Fuel Rail Crossover Tube Bolts3.8 N.m34 lb in
Fuel Rail Stop Bracket Bolt50 N.m37 lb ft
Generator Bracket Bolt50 N.m37 lb ft
Generator Cable Nut9 N.m80 lb in
Heater Hose Bracket Nut9 N.m80 lb in
Hood Hinge Bolt25 N.m18 lb ft
Ignition Coil-to-Bracket Bolts8 N.m71 lb in
Ignition Coil Bracket-to-Valve Rocker Arm Cover Bolts12 N.m106 lb in
Inner Axle Housing Nut100 N.m74 lb ft
Intake Manifold Bolts - First Pass in Sequence5 N.m44 lb in
Intake Manifold Bolts - Final Pass in Sequence10 N.m89 lb in
Intake Manifold Sight Shield Bolts10 N.m89 lb in
Intake Manifold Sight Shield Bracket Bolts5 N.m45 lb in
Intake Manifold Sight Shield Retainer Bolt5 N.m44 lb in
Intake Manifold Wiring Harness Stud10 N.m89 lb in
Knock Sensors20 N.m15 lb ft
Oil Filter30 N.m22 lb ft
Oil Filter Fitting55 N.m40 lb ft
Oil Level Indicator Tube Bolt25 N.m18 lb ft
Oil Level Sensor13 N.m115 lb in
Oil Pan Baffle Bolts12 N.m106 lb in
Oil Pan Closeout Cover Bolt - Left Side9 N.m80 lb in
Oil Pan Closeout Cover Bolt - Right Side9 N.m80 lb in
Oil Pan Cover Bolts12 N.m106 lb in
Oil Pan Drain Plug25 N.m18 lb ft
Oil Pan M8 Bolts - Oil Pan-to-Engine Block and Oil Pan-to-Front Cover25 N.m18 lb ft
Oil Pan M6 Bolts - Oil Pan-to-Rear Cover12 N.m106 lb in
Oil Pan Skid Plate Bolt20 N.m15 lb ft
Oil Pressure Sensor20 N.m15 lb ft
Oil Pump-to-Engine Block Bolts25 N.m18 lb ft
Oil Pump Cover Bolts12 N.m106 lb in
Oil Pump Relief Valve Plug12 N.m106 lb in
Oil Pump Screen Nuts25 N.m18 lb ft
Oil Pump Screen-to-Oil Pump Bolt12 N.m106 lb in
Positive Battery Cable Clip Bolt9 N.m80 lb in
Power Steering Pump Rear Bolt50 N.m37 lb ft
Spark Plugs - New Cylinder Heads20 N.m15 lb ft
Spark Plugs - All Subsequent Installations15 N.m11 lb ft
Throttle Body Nuts10 N.m89 lb in
Throttle Body Studs6 N.m53 lb in
Torque Converter Bolt - 4L60-E/4L65-E Transmissions63 N.m47 lb ft
Torque Converter Bolt - 4L80-E/4L85-E Transmissions60 N.m44 lb ft
Transmission Bolt/Stud50 N.m37 lb ft
Transmission Cover Bolt12 N.m106 lb in
Transmission Oil Level Indicator Tube Nut18 N.m13 lb ft
Valve Lifter Guide Bolts12 N.m106 lb in
Valve Rocker Arm Bolts30 N.m22 lb ft
Valve Rocker Arm Cover Bolts12 N.m106 lb in
Water Inlet Housing Bolts15 N.m11 lb ft
Water Pump Bolts - First Pass15 N.m11 lb ft
Water Pump Bolts - Final Pass30 N.m22 lb ft
Water Pump Cover Bolts15 N.m11 lb ft

ENGINE MECHANICAL (4.8L, 5.3L AND 6.0L) FASTENER TIGHTENING SPECIFICATIONS

Scheme 22

Scheme 22: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (LR4 VIN V)
Scheme 22: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (LR4 VIN V)

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (LM7 VIN T)
Scheme 26: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (LM7 VIN T)

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (L59 VIN Z)
Scheme 30: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (L59 VIN Z)

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (LQ4 VIN U)
Scheme 34: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (LQ4 VIN U)

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (LQ9 VIN N)
Scheme 38: Engine Mechanical (4.8L, 5.3L, And 6.0L) Specifications (LQ9 VIN N)

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42: Sealers, Adhesives And Lubricants
Scheme 42: Sealers, Adhesives And Lubricants

Scheme 43

Scheme 43: Engine Block-Front View
Scheme 43: Engine Block-Front View

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45: Engine Block-Rear View
Scheme 45: Engine Block-Rear View

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47: Engine Block-Left Side View
Scheme 47: Engine Block-Left Side View

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50: Engine Block-Right Side View
Scheme 50: Engine Block-Right Side View

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53: Engine Block-Bottom View
Scheme 53: Engine Block-Bottom View

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56: Engine Block-Top View
Scheme 56: Engine Block-Top View

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58: Cylinder Head-Top View
Scheme 58: Cylinder Head-Top View

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60: Cylinder Head-End View
Scheme 60: Cylinder Head-End View

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62: Cylinder Head-Exhaust Manifold Deck View
Scheme 62: Cylinder Head-Exhaust Manifold Deck View

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64: Cylinder Head-Intake Manifold Deck View
Scheme 64: Cylinder Head-Intake Manifold Deck View

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66: Disassembled Views
Scheme 66: Disassembled Views

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72: Engine Identification
Scheme 72: Engine Identification

The vehicle identification number (VIN) is located on the left side rear of the engine block (1) and is typically a nine digit number stamped or laser-etched onto the engine at the vehicle assembly plant.

  1. The first digit identifies the division.
  2. The second digit identifies the model year.
  3. The third digit identifies the assembly plant.
  4. The fourth through ninth digits are the last six digits of the VIN.

Torque Values and/or Fastener Tightening Strategies

  1. All fasteners and threaded holes on the 4.8/5.3/6.0 liter engines utilize metric threads.
  2. Cylinder head, connecting rod, crankshaft balancer, and main bearing cap bolts now apply a torque angle strategy.
  3. Certain fasteners should not be reused. Bolts, studs, or other fasteners that must be replaced will be called out in the specific service procedure.
  4. Refer to «Fastener Tightening Specifications»(ref-180687-S32234360842005101000000) and «Thread Repair Specifications»(ref-180687-S30773923622005072800000)

Changed Engine Specifications

Engine specification tables content and format have been communized.
