HVAC Systems - Automatic: Overview Chevrolet Suburban X

Test Description

The numbers below refer to the step numbers on the diagnostic table.

Scheme 60

Scheme 61

1. 3. Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
2. 5. Determine if the Rear Seat Audio (RSA) Control Module, HVAC Control Module, Body Control Module or Powertrain Control Module have set DTCs which may affect HVAC operation are present.
3. 6. The presence of DTCs which begin with "U", except U1500, indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed. Be sure to diagnose all other "U" codes before diagnosing a U1500.
4. 7. Answer Yes if the first three characters of the DTC name begins with B10; regardless of the last two characters.

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

The number below refers to the step number on the diagnostic table.

Scheme 71

1. 2. Verifies that the condition that set the DTC is present.

The number below refers to the step number on the diagnostic table.

Scheme 72

1. 2. Verifies that the condition that set the DTC is present.

The numbers below refers to the step numbers on the diagnostic table.

Scheme 73

Scheme 74

1. 2. Verifies that the temperature displayed is not within the calibrated range.
2. 3. Tests for the proper operation of the circuit in the high voltage range.
3. 4. Tests for the proper operation of the circuit in the low voltage range. If the fuse in the jumper opens when you perform this test, the signal circuit is shorted to voltage.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 75

Scheme 76

1. 2. Verifies that the temperature displayed is not within the calibrated range.
2. 3. Tests for the proper operation of the circuit in the high voltage range.
3. 4. Tests for the proper operation of the circuit in the low voltage range. If the fuse in the jumper opens when you perform this test, the signal circuit is shorted to voltage.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 77

Scheme 78

1. 2. Verifies that the value displayed is within the specified range.
2. 3. Tests for the proper operation of the circuit in the high voltage range.
3. 4. Tests for the proper operation of the circuit in the low voltage range. If the fuse in the jumper opens when you perform this test, the signal circuit is shorted to voltage.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 79

Scheme 80

Scheme 81

1. 3. At least two of the DTCs must be set as current DTC to ensure correct diagnosis. If only one DTC is present then the answer is No.
2. 5. Tests for the proper operation of the circuit in the low voltage range.
3. 6. Tests for the proper operation of the circuit in the high voltage range. If the jumper fuse opens when you perform this test, the circuit is shorted to ground.
4. 7. Tests for a short to voltage in the 5-volt reference circuit.
5. 8. Tests for a high resistance or for an open in the low reference circuit.
6. 9. This step tests for an open on the low reference circuit that is common to all of the actuators. Choose the easiest HVAC door actuator that set a DTC to start the diagnosis.
7. 10. Disconnecting each actuator, one at a time, isolates the disconnected actuators signal circuit from the 5-volt reference circuit that is common to all the actuators.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 82

Scheme 83

1. 2. Determines if the HVAC door actuator is stalled.
2. 3. Applies control circuit voltage to the input of the HVAC door actuator.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 84

Scheme 85

1. 2. Determines if the auxiliary HVAC door actuator is stalled.
2. 3. Applies control circuit voltages to the input of the auxiliary HVAC door actuator.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 86

Scheme 87

Scheme 88

1. 2. Ensure to observe the correct parameter for each DTC. Aux. Temp Dr. Position is for the auxiliary air temperature actuator. Mode Door Actual is for the auxiliary mode actuator.
2. 4. Tests for the proper operation of the circuit in the low voltage range.
3. 5. Tests for the proper operation of the circuit in the high voltage range. If the jumper fuse opens when you perform this test, the circuit is shorted to ground.
4. 6. Tests for a short to voltage in the 5-volt reference circuit.
5. 7. Tests for a high resistance or for an open in the low reference circuit.
6. 13. The voltage will vary between 0-5 volts during normal operation. Ensure to observe the actuator driveshaft and the volt meter when jumping the control circuit with 5-volt reference and the ground circuits. The actuator and the auxiliary HVAC control module connectors must be connected during this step.

The number below refers to the step number on the diagnostic table.

Scheme 89

1. 2. Verifies that the condition that set the DTC is present.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 90

Scheme 91

Scheme 92

1. 3. Tests for the proper operation of the circuit in the low voltage range.
2. 4. Tests for the proper operation of the circuit in the high voltage range. If the fuse in the jumper opens when you perform this test, the signal circuit is shorted to ground.
3. 5. Tests for a short to voltage in the 5-volt reference circuit.
4. 6. Tests for a high resistance or an open in the low reference circuit.

Important: The following steps must be completed before using the symptom tables.

1. Perform the «DIAGNOSTIC SYSTEM CHECK - HVAC SYSTEMS - AUTOMATIC»(ref-180629-S11846431532005072800000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control module(s) can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to the following information: «AIR DELIVERY DESCRIPTION AND OPERATION»(ref-180629-S02491897352005072800000) «AIR TEMPERATURE DESCRIPTION AND OPERATION»(ref-180629-S08202505842005072800000)

The numbers below refer to the step numbers on the diagnostic table.

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

1. 2. The A/C compressor relay output is disabled if engine coolant temperature is above 121°C (250°F). The engine coolant indicator will illuminate at this temperature.
2. 3. This step ensures that the HVAC control module is receiving an input from the A/C switch.
3. 4. These actions will enable the A/C compressor to operate.
4. 5. This test ensures that there is sufficient refrigerant in the A/C system. The specific values come from the A/C System Performance Test in Heating, Ventilation and Air Conditioning.
5. 7. The A/C low pressure switch parameter is out of range when the HVAC control module interprets the signal being below 151 kPa (22 psi).
6. 8. This action will simulate a closed switch condition. If the Pressure Cycle Switch parameter reads Low Pressure then there is a circuit condition or a condition with the HVAC control module.
7. 11. The A/C compressor relay output from the powertrain control module (PCM) is disabled if the A/C high side system pressure is interpreted to be higher than 2958 kPa (429 psi).

The number below refers to the step number on the diagnostic table.

Scheme 98

Scheme 99

1. 2. These actions will disable the HVAC control module output to powertrain control module (PCM).

The number below refers to the step number on the diagnostic table.

Scheme 100

1. 4. The blower motor parameter must be commanded ON before an OFF command will function.

Scheme 101

Scheme 102

Scheme 103

Scheme 104

1. 2. This step verifies that the HVAC control module Fan Up Switch parameter matches the requested state of the blower motor switch.
2. 3. This step verifies that the HVAC control module Fan Down Switch parameter matches the requested state of the blower motor switch.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 105

Scheme 106

Scheme 107

1. 2. This step tests for auxiliary blower motor operation in the OFF setting.
2. 3. The Blower Motor Test parameter must be commanded ON before an OFF command will function.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 108

Scheme 109

Scheme 110

Scheme 111

1. 8. This step verifies that the auxiliary HVAC control module is commanding the auxiliary blower motor to operate at HI speed to reflect the requested speed of the front auxiliary HVAC control assembly. The scan tool should display a value greater than 50 percent.
2. 11. This step tests for an internal fault of the RSA control module, or the auxiliary HVAC control module. If the Rear HVAC Fan Speed parameter changes as the fan switch speed changes then replace the auxiliary HVAC control module. If the Rear HVAC Fan Speed parameter does not change replace the RSA control module.
3. 12. This step verifies that the front auxiliary HVAC control assembly receives a 5 V reference and ground from the auxiliary HVAC control module. If all 3 parameters are at 0 when the auxiliary fan HIGH speed is requested then proceed to step 13.
4. 15. This step verifies that the auxiliary HVAC control module is commanding the auxiliary blower motor to operate at HI speed to reflect the requested speed of the front auxiliary HVAC control assembly. If the Blower Switch Pos. parameter is 15 and the auxiliary blower motor is not on HIGH then replace the auxiliary HVAC control module.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 112

Scheme 113

Scheme 114

1. 1. Ensure to perform the HVAC diagnostic system check. If DTCs B0434, DTC B3764 and the auxiliary blower motor is always on, then the 5 volt reference circuit of the auxiliary HVAC door actuators is pulled low to ground. The DTC diagnostic must be performed to ensure circuit is tested.
2. 5. This step tests for an internal failure of the rear seat audio (RSA) control module, or the auxiliary HVAC control module.
3. 6. This step tests the 5 volt reference supplied by the auxiliary blower motor control processor.
4. 7. This step tests for an internal failure of the front auxiliary HVAC control assembly.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

1. 6. The ambient air temperature must be above 5°C (40°F) in order for this A/C compressor test to be run.
2. 8. This step ensures that the lower air temperature sensors operate properly. The LH and RH Heater Duct Actual parameter count values should lower as the air temperature of the ducts get warmer. If there is a high resistance in either of the air temperature sensors circuits or the sensor itself then the count value of the effected sensor would remain high.
3. 9. This step ensures that the upper air temperature sensors operate properly. The LH and RH AC Duct Actual parameter count values should lower as the air temperature of the ducts get warmer. If there is a high resistance in either of the air temperature sensors circuits or the sensor itself then the count value of the effected sensor would remain high.
4. 11. This action ensures that the internal fan of the inside air temperature sensor assembly is providing air flow across the internal sensor.
5. 14. Use the following table to determine that the recorded scan tool values are within range for the recorded probe temperatures of the J 43600.

The number below refers to the step number in the diagnostic table.

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

1. 8. This step ensures that the lower air temperature sensors operate properly. The LH and RH Heater Duct Actual parameter count values should lower as the air temperature of the ducts get warmer. If there is a high resistance in either of the air temperature sensors circuits or the sensor itself then the count value of the effected sensor would remain high.
2. 9. This step ensures that the upper air temperature sensors operate properly. The LH and RH AC Duct Actual parameter count values should lower as the air temperature of the ducts get warmer. If there is a high resistance in either of the air temperature sensors circuits or the sensor itself then the count value of the effected sensor would remain high.
3. 11. This action ensures that the internal fan of the inside air temperature sensor assembly is providing air flow across the internal sensor.
4. 15. Use the following table to determine that the recorded scan tool values are within range for the recorded probe temperatures.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

1. 2. This step ensures that the primary HVAC system is functioning properly.
2. 3. The DTCs listed could set if a calibration of the actuators is performed.
3. 6. If the condition does not occur when a A/C request has been made then you must bypass the A/C compressor and cooling system diagnostic information.
4. 9. This step ensures that the front auxiliary control assembly is providing an auxiliary air temperature input to the auxiliary HVAC control module.
5. 10. This step ensures that the rear seat audio control is providing an auxiliary air temperature input to the auxiliary HVAC control module.
6. 12. When taking a temperature reading allow for a 3°C (5°F) temperature variance.
7. 15. When the front auxiliary HVAC control assembly is disconnected, and there is no fault on auxiliary air temperature switch control circuit, the scan tool will read a high count value for the Air Temp. Switch Pos. parameter. A short to ground on circuit will have low count value.

The numbers below refer to the step numbers on the diagnostic table.

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

1. 2. This step ensures that the primary HVAC system is functioning properly.
2. 3. The DTCs listed could set if a calibration of the actuators is performed.
3. 6. If the condition does not occur when a heating request has been made then you must bypass the A/C compressor and cooling system diagnostic information.
4. 9. This step ensures that the front auxiliary control assembly is providing an auxiliary air temperature input to the auxiliary HVAC control module.
5. 10. This step ensures that the rear seat audio control is providing an auxiliary air temperature input to the auxiliary HVAC control module.
6. 12. When taking temperature reading allow for a 3°C (5°F) temperature variance.
7. 15. When the front auxiliary HVAC control assembly is disconnected, and there is no fault on auxiliary air temperature switch control circuit, the scan tool will read a high count value for the Air Temp. Switch Pos. parameter. A short to ground on circuit will have low count value.

Scheme 137

1. The condition may be intermittent. Refer to TESTING FOR INTERMITTENT AND POOR CONNECTIONS in Wiring Systems.
2. Inspect the air delivery system for the following conditions: A dirty HVAC air filter, if applicable An obstruction to the airflow Air leaks Misaligned air ducts Broken or binding linkages or doors

The number(s) below refer to the step number(s) on the diagnostic table.

Scheme 138

Scheme 139

1. 3. This step tests for auxiliary blower motor that does not operate from the front auxiliary HVAC control assembly regardless of the desired blower motor speed.
2. 4. This step tests for a auxiliary blower motor that operates, yet does not accurately respond to the desired blower motor speed from the front auxiliary HVAC control assembly.
3. 5. This step tests for an inoperative auxiliary mode actuator in one mode position(s) or in the wrong mode position(s) from the front auxiliary HVAC control module.
4. 6. This step tests for an inoperative auxiliary mode actuator in one mode position(s) or in the wrong mode position(s) from the console HVAC control module.

Scheme 140

Re-Calibrating Actuators

When replacing the HVAC control module it will be necessary to allow the HVAC control module to perform a re-calibration process. When installing the HVAC control module be sure to perform the following

Important: Do not adjust any controls on the HVAC control module while the HVAC control module is calibrating. If interrupted improper HVAC performance will result.

1. Place the ignition switch to the OFF position.
2. Disconnect the scan tool.
3. Install the HVAC control module.
4. Re-connect all previously disconnected components.
5. Start the vehicle.
6. Wait 40 seconds for the HVAC control module to re-calibrate.
7. Verify that no DTCs have set as current DTCs.

When replacing the motor assembly it will be necessary to allow the HVAC control module to perform a re-calibration process. When installing the motor assembly be sure to perform one of the following

Important: Do not adjust any controls on the HVAC control module while the HVAC control module is calibrating. If interrupted improper HVAC performance will result.

Air Delivery Description and Operation

The air delivery description and operation is divided into 7 areas

1. HVAC Control Components
2. Air Speed
3. Auxiliary Air Speed
4. Air Delivery
5. Auxiliary Air Delivery
6. Recirculation Operation
7. Automatic Operation

Recirculation Operation

The HVAC control module controls the air intake through the recirculation actuator. The recirculation switch closes the recirculation door in order to circulate the air within the vehicle. The outside air switch opens the recirculation door in order to route outside air into the vehicle. Regardless of the blower motor switch position, recirculation is available only in the panel and bi-level mode switch positions. Including the OFF position. The mode switch must be placed in either the panel or bi-level position before the blower motor switch is placed in the OFF position. In order to reduce windshield fogging, outside air is circulated when the mode switch is in the defrost or defog positions. If the recirculation switch is pressed into the ON position when the mode switch is in an unavailable mode position, then the recirculation switch LED will flash 3 times. If the HVAC control module detects a fault with the recirculation door the HVAC control module will try to drive the actuator for a predetermined amount of time, to outside air, which is the defaulted position for the recirculation actuator.

Automatic Operation

In automatic operation, the HVAC control module will maintain the comfort level inside of the vehicle by controlling the A/C compressor clutch, the blower motor, the air temperature actuators, mode actuator and recirculation.

To place the HVAC system in Automatic mode, the following is required

1. The Auto switch must be activated
2. The air temperature switch must be in any other position other than full hot or full cold position

Once the desired temperature is reached, the blower motor, mode, recirculation and temperature actuators will automatically be adjusted to maintain the temperature selected. The HVAC control module performs the following functions to maintain the desired air temperature

1. Monitor the following sensors: Inside air temperature sensor Ambient Air Temperature Sensor Lower Left Air Temperature Sensor Lower Right Air Temperature Sensor Upper Left Air Temperature Sensor Upper Right Air Temperature Sensor
2. Regulate blower motor speed
3. Position the air temperature actuator
4. Position the mode actuator
5. Position the recirculation actuator
6. Request A/C operation

Air Temperature Description and Operation

The air temperature controls are divided into 7 areas

1. HVAC Control Components
2. Heating and A/C Operation
3. Auxiliary Heating and A/C Operation
4. Automatic Operation
5. Auxiliary Automatic Operation
6. Engine Coolant
7. A/C Cycle

Heating and A/C Operation

The purpose of the heating and A/C system is to provide heated and cooled air to the interior of the vehicle. The A/C system will also remove humidity from the interior and reduce windshield fogging. The vehicle operator can determine the passenger compartment temperature by adjusting the air temperature switch. The vehicle passenger can offset the passenger temperature as much as 16.7°C (30°F). Regardless of the temperature setting, the following can effect the rate that the HVAC system can achieve the desired temperature

1. Recirculation actuator setting
2. Difference between inside and desired temperature
3. Difference between ambient and desired temperature
4. Blower motor speed setting
5. Mode setting
6. Auxiliary HVAC settings

The control module makes the following actions when automatic operation is not selected, and an air temperature setting is selected

1. When the air temperature switch is placed in the warmest position, the control module commands the air temperature door to divert maximum air past the heater core.
2. When the air temperature switch is placed in the coldest position, the control module commands the air temperature door to direct air to bypass the heater core.
3. When the air temperature switch is placed between the warmest and coldest positions, the control module monitors the following sensor inputs to determine the air temperature door position that diverts the appropriate amount of air past the heater core in order to achieve the desired temperature: Sunload Duct temperatures Ambient temperature Inside temperature

The A/C system can be engaged by either pressing the A/C switch or during automatic operation. The HVAC control module sends a class 2 message to the PCM for A/C compressor engagement. The PCM will provide a ground for the A/C compressor relay enabling it to close its internal contacts to send battery voltage to the A/C compressor clutch coil. The A/C compressor diode will prevent a voltage spike, resulting from the collapse of the magnetic field of the coil, from entering the vehicle electrical system when the compressor is disengaged.

The following conditions must be met in order for the A/C compressor clutch to turn on

1. Ambient air temperature above 4°C (40°F)
2. A/C low pressure switch signal circuit is grounded
3. A/C refrigerant pressure sensor parameter is less than 2957 kPa (429 psi)
4. PCM receives an A/C request from the HVAC control module
5. Engine coolant temperature (ECT) is less than 121°C (250°F)
6. The engine rpm is more than 550 rpm
7. The throttle position is less than 100%

The HVAC control module monitors the A/C low pressure switch signal circuit. If the voltage signal on this circuit has no voltage drop the module will interpret this condition as a low pressure, disabling the A/C request. The A/C low pressure switch will open its internal contacts at 151 kPa (22 psi). Then close the contacts at 275 kPa (40 psi) to resume A/C operation. This switch assists in cycling the A/C compressor and prevents A/C compressor operation if system has a low refrigerant level.

The PCM monitors the A/C refrigerant pressure sensor signal circuit. The voltage signal on this circuit is proportional to the refrigerant pressure inside the A/C high side pressure line. As the pressure inside the line increases, so does the voltage signal. If the pressure is above 2957 kPa (429 psi), the A/C compressor output is disabled. When the pressure lowers to 1578 kPa (229 psi), the PCM enables the compressor to operate.

The sensor information is used by the PCM to determine the following

1. The A/C high side pressure
2. An A/C system load on the engine
3. An excessive A/C high side pressure
4. The heat load at the A/C condenser

Once engaged, the compressor clutch will be disengaged for the following conditions

1. Ambient air temperature is less than 4°C (40°F)
2. Throttle position is 100%
3. The A/C low pressure switch is open
4. A/C high side pressure is more than 2957 kPa (429 psi)
5. A/C low side pressure is less than 151 kPa (22 psi)
6. Engine coolant temperature (ECT) is more than 121°C (250°F)
7. Engine speed is more than 5500 rpm
8. Transmission shift
9. PCM detects excessive torque load
10. PCM detects insufficient idle quality
11. PCM detects a hard launch condition

Auxiliary Heating and A/C Operation

There are 2 separate controls for the auxiliary HVAC system. There is the front auxiliary HVAC control assembly and the rear seat audio control module. These 2 components provide passenger inputs to the auxiliary HVAC control module. The auxiliary HVAC control module, which is mounted on the auxiliary HVAC case, controls all functions of the auxiliary HVAC system. If the front auxiliary HVAC control assembly is in any other position than OFF or AUX, then the auxiliary HVAC control module will use inputs from the front auxiliary HVAC control assembly. If the system is in the AUX position then the auxiliary HVAC control module will use inputs from the rear seat audio control module. If the front auxiliary blower motor switch is in the OFF position, then the auxiliary HVAC control module does not respond to input. The auxiliary HVAC control module can not request A/C operation from the PCM.

Placing the auxiliary air temperature switch to the warmest position diverts most of the airflow through the heater core, which increases the outlet air temperature. Placing the auxiliary air temperature switch to the coolest position diverts most of the airflow around the heater core, which decreases the outlet air temperature.

In automatic operation, the HVAC control module will maintain the comfort level inside of the vehicle by controlling the A/C compressor clutch, the blower motor, the air temperature actuators, mode actuator and recirculation.

To place the HVAC system in Automatic mode, the following is required

1. The Auto switch must be activated
2. The air temperature switch must be in any other position other than full hot or full cold position

Once the desired temperature is reached, the blower motor, mode, recirculation and temperature actuators will automatically be adjusted to maintain the temperature selected. The HVAC control module performs the following functions to maintain the desired air temperature

1. Monitor the following sensors: Inside Air Temperature Sensor Ambient Air Temperature Sensor Lower Left Air Temperature Sensor Lower Right Air Temperature Sensor Upper Left Air Temperature Sensor Upper Right Air Temperature Sensor
2. Regulate blower motor speed
3. Position the air temperature actuator
4. Position the mode actuator
5. Position the recirculation actuator
6. Request A/C operation

Auxiliary Automatic Operation

In automatic operation, the auxiliary HVAC control module will maintain the comfort level inside of the vehicle by controlling the auxiliary blower motor, the auxiliary air temperature actuator and the auxiliary mode actuator.

To place the auxiliary HVAC system in Automatic mode, the following is required

1. The auxiliary blower motor switch on the front HVAC control assembly must be in the Auto position.
2. The auxiliary mode switch on the front HVAC control assembly must be in the Auto position.
3. The auxiliary air temperature switch must be in any other position other than full hot or full cold position.

Once the desired temperature is reached, the auxiliary blower motor, auxiliary mode and auxiliary temperature actuator will automatically be adjusted to maintain the temperature selected. The auxiliary HVAC control module performs the following functions to maintain the desired air temperature

1. Monitor the following sensors: Inside Air Temperature Sensor-Auxiliary Upper Air Temperature Sensor-Auxiliary Lower Air Temperature Sensor-Auxiliary
2. Regulate auxiliary blower motor speed
3. Position the auxiliary air temperature actuator
4. Position the auxiliary mode actuator
