HVAC Systems - Automatic: Specifications Chevrolet Suburban X

Automatic HVAC System 59 illustrations ~133 words

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Auxiliary Air Temperature Actuator Screws	1.6 N.m	14 lb in
Auxiliary Blower Motor Processor Screws	1.6 N.m	14 lb in
Auxiliary HVAC Control Module Screws	1.6 N.m	14 lb in
Auxiliary Mode Actuator Screws	1.6 N.m	14 lb in
Blower Motor Control Processor Screws	1.6 N.m	14 lb in
Center Console Duct Screws	1.6 N.m	14 lb in
HVAC Control Module Screws	1.9 N.m	17 lb in
Left Air Temperature Actuator Screws	2 N.m	18 lb in
Mode Actuator Screws	1.6 N.m	14 lb in
Overhead Console Screws	2 N.m	18 lb in
Recirculation Actuator Screws	1.6 N.m	14 lb in
Right Air Temperature Actuator Screws	2 N.m	18 lb in

HVAC Systems - Automatic Fastener Tightening Specifications

Scheme 1

Scheme 1: Sensor Resistance Table (Primary HVAC)

Scheme 1: Sensor Resistance Table (Primary HVAC)

Scheme 2

Scheme 2: Sensor Resistance Table (Auxiliary HVAC)

Scheme 2: Sensor Resistance Table (Auxiliary HVAC)

Scheme 3

Scheme 3: Sensor Resistance Table - Auxiliary HVAC

Scheme 3: Sensor Resistance Table - Auxiliary HVAC

Scheme 4

Scheme 4

Scheme 4

Scheme 5

Scheme 5: Schematic and Routing Diagrams

Scheme 5: Schematic and Routing Diagrams

Scheme 6

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 14

Scheme 15

Scheme 15: HVAC Component Views

Scheme 15: HVAC Component Views

Scheme 16

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 23

Scheme 24

Scheme 24

Scheme 24

Scheme 25

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 28

Scheme 29

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Scheme 30

Scheme 31

Scheme 31: HVAC Connector End Views

Scheme 31: HVAC Connector End Views

Scheme 32

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 34

Scheme 35

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 36

Scheme 37

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 38

Scheme 39

Scheme 39

Scheme 39

Scheme 40

Scheme 40

Scheme 40

Scheme 41

Scheme 41

Scheme 41

Scheme 42

Scheme 42

Scheme 42

Scheme 43

Scheme 43

Scheme 43

Scheme 44

Scheme 44

Scheme 44

Scheme 45

Scheme 45

Scheme 45

Scheme 46

Scheme 46

Scheme 46

Scheme 47

Scheme 47

Scheme 47

Scheme 48

Scheme 48

Scheme 48

Scheme 49

Scheme 49

Scheme 49

Scheme 50

Scheme 50

Scheme 50

Scheme 51

Scheme 51

Scheme 51

Scheme 52

Scheme 52

Scheme 52

Scheme 53

Scheme 53

Scheme 53

Scheme 54

Scheme 54

Scheme 54

Scheme 55

Scheme 55

Scheme 55

Scheme 56

Scheme 56

Scheme 56

Scheme 57

Scheme 57

Scheme 57

Scheme 58

Scheme 58

Scheme 58

Scheme 59

Scheme 59

Scheme 59
