Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Horn Contact Plate Screws | 5.5 N.m | 49 lb in |
| HVAC Floor Duct Mounting Screw | 1.9 N.m | 17 lb in |
| Ignition Lock Cylinder Case Screws | 7 N.m | 62 lb in |
| Intermediate Shaft to the Steering Column Pinch Bolt | 50 N.m | 37 lb ft |
| Intermediate Shaft to the Steering Gear Pinch Bolt | 50 N.m | 37 lb ft |
| Steering Column Electrical Connector Screw | 6 N.m | 53 lb in |
| Steering Column Mounting Nuts | 27 N.m | 20 lb ft |
| Steering Column Trim Cover Screws Lower | 3.5 N.m | 31 lb in |
| Steering Column Trim Cover Screws Upper | 1 N.m | 9 lb in |
| Steering Wheel Nut | 41 N.m | 30 lb ft |
| Steering Wheel Shroud Screws | 2 N.m | 18 lb in |
| Turn Signal Multifunction Switch Screws Side | 7 N.m | 62 lb in |
| Turn Signal Multifunction Switch Screws Top | 3 N.m | 27 lb in |
| Upper Intermediate Shaft to Lower Intermediate Shaft Pinch Bolt | 50 N.m | 37 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Column/Ignition Lock Schematics
Scheme 2
Scheme 2: Steering Column Disassembled View
| Callout | Component Name |
|---|
| 1 | Upper Trim Cover |
| 2 | Lower Trim Cover |
| 3 | Steering Column Closeout Trim Cover |
| 4 | Retaining Ring |
| 5 | SIR Coil |
| 6 | Wave Washer |
| 7 | Bearing Retainer |
| 8 | Cam Orientation Plate |
| 9 | Shaft Lock Shield Assembly |
| 10 | Turn Signal Cancel Cam Assembly |
| 11 | Upper Bearing Spring |
| 12 | Upper Bearing Inner Race Seat |
| 13 | Wire Harness Strap |
| 14 | Inner Race |
| 15 | Signal Switch Housing |
| 16 | Pan Head Tapping Screws |
| 17 | Turn Signal and Multifunction Switch Assembly |
| 18 | Steering Column Tilt Head Assembly |
| 19 | Pan Head Tapping Screws |
| 20 | TORX® Head Screw |
| 21 | Ignition Lock Cylinder Case |
| 22 | Theft Deterrent Control Module |
| 23 | Ignition Switch Assembly |
| 24 | Spring Guide |
| 25 | Tilt Spring |
| 26 | Theft Deterrent Control Module Electric Park Lock |
| 27 | Steering Shaft Assembly |
| 28 | Tilt Bumper |
| 29 | Pivot Pins |
| 30 | Steering Column Support Assembly |
| 31 | Coil Wire Harness Assembly |
| 32 | Coil Wire Harness Assembly (Export) |
Scheme 3
Scheme 3: Steering Wheel and Column Component Views
| Callout | Component Name |
|---|
| 1 | Ignition Switch |
| 2 | Passlock Sensor |
| 3 | Ignition Key Alarm Switch |
| 4 | Ignition Lock Cylinder Control Solenoid |
| 5 | Steering Column |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Remote Control Door Lock Receiver (RCDLR) |
| 2 | Remote Control Door Lock Receiver (RCDLR) Connector |
| 3 | Body Control Module (BCM) |
| 4 | Automatic Transmission Shift Lock Actuator Connector |
| 5 | Automatic Transmission Shift Lock Actuator |
| 6 | Park Brake Switch |
| 7 | Park Brake Switch Connector |
